1. Bill of Quantities
ITEM DESCRIPTION UNIT RATE QTY AMOUNT
(RM)
Roof And Roof Structure
Steel Structure
Framing, fabricated, weldable steel: hot rolled:
structural steel sections and bolted site
connections.
A Framing and fabrication in 200x200 columns. tonne 2
B Framing and fabrication in 294x200mm beams. tonne 4
C Framing and fabrication in 100x100mm beams. tonne 1
D Framinga and fabricated in 150x50 purlins. tonne 5
Framing, fabricated holding down bolt assemblies
welded on and setting in concrete base with all
necessary fittings
E 20mm diameters m.s. bolts No 12
Framing, fabricated bolts assemblies welded on
column, beam and purlin with all necessary
fittings
F 16mm diameters m.s. bolts No 96
G 20mm diameters m.s. bolts No 72
H 250mmx250mmx20mm thick base plate No 6
I 360mmx200mmx20mm thick plate No 6
J 350mmx250mmx20mm thick plate No 6
K 135mmx120mmx200mmx10mm thick bracket /
angle No 48
Surface Treatment
L Apply one coat zinc chromate primer and oen coat
of two pack epoxy zinc phosphate primer.
To steelworks structure m² 163
TO COLLECTION :
