The document discusses the Net::LDAP Perl module, which allows developers to interact with LDAP directories from Perl applications. It provides an overview of the LDAP protocol and standards, describes how to connect to an LDAP server and perform common operations like searching, adding, modifying and deleting entries using Net::LDAP. It also gives examples of using Net::LDAP in applications like Apache session storage and identity management software.

1. Net::LDAP
Clément OUDOT
FOSDEM 2014

2. Clément::OUDOT
Work
10
Free software
2

3. Table::of::contents
●
●
●
LDAP protocol
Net::LDAP
Usage examples
3

4. LDAP
4

5. LDAP::protocol
●
●
●
●
●
●
Defined by standards (RFC)
LDAPv2 in 1995, LDAPv3 in 1997
TCP/IP, LBER, ASN1
9 core operations, and extended
operations
Schema define object classes, attributes,
syntaxes and matching rules
Data organized hierarchically (tree)
5

6. Directory::Information::Tree
dc=linid,dc=org
ou=people
uid=coudot
ou=structures
ou=groups
cn=admin
6

7. Entry::Attribute::Value
Entry
Attribute
Attribute
Attribute
Attribute
Attribute
Value
Value
Value

8. LDIF
●
LDAP Data Interchange Format
dn: uid=coudot,ou=users,dc=example,dc=com
objectClass: inetOrgPerson
objectClass: organizationalPerson
objectClass: person
objectClass: top
uid: coudot
mail: coudot@linagora.com
cn: Clément OUDOT
sn: OUDOY
givenName: Clément

9. Tips::Devel::LDAP
●
●
●
●
●
●
●
LDAP is a connected protocol: 1 connection,
several operations
For each operation, a return code: test it!
LDAPS is deprecated, use startTLS
Use LDAPv3
Say hello! (BIND)
Say goodbye! (UNBIND)
Use search parameters to improve
performances

10. Net::LDAP
10

11. A module with modules
●
●
●
●
●
●
●
Net::LDAP: main module
Net::LDAP::LDIF: manipulate LDIF files
Net::LDAP::RFC: list of RFC (POD)
Net::LDAP::Schema: parse schema
Net::LDAP::Extensions::*
Net::LDAP::Control::*
And many others...
11

12. Credits
●
●
●
Graham Barr <gbarr@pobox.com>
Peter Marschall <peter@adpm.de>
Chris Ridd <chris.ridd@isode.com>
12

13. Create a connection
●
●
●
Create a new Net::LDAP object
Specify host, port, scheme
Other options:
●
dsebug
●
IO::Socket options
●
async
●
version (v3 is the default)
●
onerror
13

14. Authentication
●
●
●
●
Bind with a DN and a password
Bind anonymously
Bind with SASL
Client certificate with startTLS
14

15. Search
●
You need to provide:
●
●
Scope
●
Filter
●
●
Base
Attributes
Search can return 0 entries and be
successful
15

16. Entry
●
●
Entries object are returned by search or
generated from LDIF, or generated from
scratch
Methods to:
●
browse attributes and values
●
to add/modify/delete values
●
export to LDIF
16

17. Add and delete
●
Add method parameters:
●
●
●
Net::LDAP::Entry
DN and list of attributes
Delete method parameters:
●
Net::LDAP::Entry
●
DN
17

18. Modification
●
●
Add, replace, delete values
Modification applies to one entry:
●
●
●
Net::LDAP::Entry
DN
To rename/move an entry, use moddn:
●
Define a new RDN
●
Define a new superior
18

19. Password::Policy
●
●
Password policy controls password quality
at modification, and prevent brute force
attack at authentication
Net::LDAP::Control::PasswordPolicy:
●
Sent by client
●
Sent back by server
19

20. Usage::examples
20

21. Apache::Session::LDAP
●
●
●
Implements Apache::Session interface
Store sessions as entries in LDAP
See also
Apache::Session::Browseable::LDAP for
indexed sessions
21

22. Scripts
●
Provided by LDAP Tool Box project:
●
Monitoring scripts:
–
–
Check OpenLDAP syncrepl status
–
●
Check LDAP response time
Check OpenLDAP monitor data
Data manipulation:
–
CSV to LDIF or LDIF to LDIF
–
Convert data from SUN/Oracle to OpenLDAP
22

23. LemonLDAP::NG
●
●
●
●
●
●
●
WebSSO, Access Control and Identity
Federation free software
Authentication against LDAP
Password modification in LDAP
Session storage in LDAP
Configuration storage in LDAP
Notification storage in LDAP
Implements Password Policy
23

24. Almost the end...
24

25. Thanks
●
Special thanks to:
●
●
Company LINAGORA
●
●
FOSDEM and their organizers
All Perl developers
Keep in touch:
●
Twitter: @clementoudot
●
IRC: KPTN #linagora@freenode
●
Web: http://coudot.blogs.linagora.com
25

26. Questions?
26

27. Thanks for your attention
http://www.linid.org
Logiciels et services Open Source
80 rue Roque de Fillol l 92800 PUTEAUX
Tel : 0810 251 251 l Fax : +33 1 46 96 63 64
www.linagora.com
