This document discusses how to write memory efficient code. It begins by explaining that memory is not as cheap as it used to be and often becomes saturated first. The document recommends measuring wasted memory by capturing heap dumps in production and analyzing them with HeapHero. Examples of memory inefficiencies discussed include duplicate strings, inefficient collections, duplicate objects, boxed numbers, and object overhead. Strategies provided to optimize memory usage include using String interning, avoiding unnecessary object creation, using collection capacities correctly, and reducing object nesting. The presentation aims to help developers reduce computing costs and garbage collection pauses through optimizing memory usage.

1. How to memory efficient Code?
Ram Lakshmanan
Architect – GCeasy.io, fastThread.io, HeapHero.io
Confoo 2019

2. Do I need to care about memory?
It’s very cheap!
1970s
1 Byte = 1 $
2019
FRACTION OF COST

3. Here is my case: Memory is not cheap!
Memory saturates first.
Other resources are
partially/under utilized.
3. Storage
4. Network
1. CPU
2. Memory

4. Do you know how much memory applications wastes?
30 – 90%

5. You can't optimize, what you can't
measure
A famous saying

6. How to measure wasted memory?
Step 1: Capture Heap dumps in production*
https://blog.heaphero.io/2017/10/13/how-to-capture-java-heap-dumps-7-options/
Step 2: Analyze with HeapHero: https://heaphero.io
Reports amount of memory wasted, code triggering it, recommendations to fix.
* - if possible

7. Analyze real-world example

8. String Duplication

9. What is duplicate String?
String s1 = new String("Hello World");
String s2 = new String("Hello World");
System.out.println(s1.equals(s2)); // prints 'true'
System.out.println((s1 == s2)); // prints 'false'

10. Solution 1: intern()
String s1 = new String("Hello World").intern();
String s2 = new String("Hello World").intern();
System.out.println(s1.equals(s2)); // prints 'true'
System.out.println((s1 == s2)); // prints 'true'
>>> s1 = intern(’Hello World')
Java
Python

11. How intern() works?
“Hello World”
s1
s2
String pool
String s1 = new String("Hello World").intern();
String s2 = new String("Hello World").intern();

12. Solution 2: UseStringDeduplication
• -XX:+UseStringDeduplication
• Works only with
• G1 GC algorithm
• Java 8 update 20
• Real life case study:
https://blog.gceasy.io/2018/07/17/disappointing-story-on-memory-
optimization/
Long lived objects (-XX:StringDeduplicationAgeThreshold=3)
• Check GC pause time impact

13. Solution 3: Use String literals
public static final String HELLO_WORLD = “Hello World”;

14. Solution 4: Avoid creating strings
In DB store data as primitive types:
user
id
Name …. country
1 Joe Libson …. Canada
2 Nathan Ray …. Canada
3 Chris Mang …. USA
4 Erik Pilz …. USA
5 Lakshmi
Singh
…. India
user
id
Name …. country
1 Joe Libson …. 2
2 Nathan Ray …. 2
3 Chris Mang …. 1
4 Erik Pilz …. 1
5 Lakshmi
Singh
…. 124

15. Inefficiency in collections

16. Inefficiency in Collections
List<User> users = new ArrayList<>();
users.add(user);
2 54 6 7 8 1093
wasted
11
ArrayList underlyingly maintains
Object[]
initial capacity = 10

17. 1 2 54 6 7 8 1093
Inefficiency in Collections
wasted
List<User> users = new ArrayList<>();
for (int counter = 1; counter <= 11; ++counter) {
users.add(user);
}
1 2 54 6 7 8 1093 11 12 1514 17 18 201913 16
1 2 54 6 7 8 93 11 12 1514 17 18 201913 16 21 22 2524 26 27 28 2923 31 32 3534 37 38 403933 3630
wasted
10
for (int counter = 1; counter <= 21; ++counter) {
users.add(user);
}

18. Recommendation 1: use capacity
new ArrayList<>(3);
new ArrayList<>();

19. Recommendation 2: lazy initialization
private List<User> users = new ArrayList<>();
public void addUser(User user) {
users.add(user);
}
private List<User> users;
public void addUser(User user) {
if (users == null) {
users = new ArrayList<>();
}
users.add(user);
}

20. Recommendation 3: avoid clear()
List<User> users = new ArrayList<>();
users = null;
List<User> users = new ArrayList<>();
users.clear();

21. Let’s understand overhead of an
Object

22. Object overhead
public class User {
private String name;
private int age;
private float weight;
}
new User();
Object Header
name
age
weight
12 bytes
4 bytes
4 bytes
4 bytes
Fixed overhead
1. Virtual method invocation
2. ‘synchronized’ object lock
3. Garbage collection
4. Object book keeping
24 bytes

23. Boxed numbers: java.lang.Integer
• int: 4 bytes
• java.lang.Integer: 16 bytes
Data is 4 bytes, object overhead is 12 bytes

24. Yesterday’s key note: 2 instance variables/class
public class User {
private int field1;
private int field2;
private int field3;
:
private int field10;
}
public class User {
private Object1 obj1;
private Object2 obj2;
}
public class Object1 {
private int field1;
private Object3 obj3;
}
public class Object2 {
private int field2;
private Object4 obj4;
}
public class Object3 {
private int field3;
private Object5 obj5;
}
public class Object4 {
private int field4;
private Object6 obj6;
}52 bytes
i.e. 12 bytes header + (10 ints* 4 bytes) public class Object5 {
private int field5;
private Object6 obj7;
}
public class Object6 {
private int field6;
private Object3 obj8;
}
public class Object7 {
private int field7;
private Object4 obj9;
}
public class Object8 {
private int field8;
private int field9;
}
public class Object9 {
private int field10;
}
196 bytes (~4x more needed)
= 10 object headers * 12 + (10 ints * 4 bytes)
+ (9 object references * 4)

25. How all memory is wasted?
1. Duplicate Strings: https://heaphero.io/heap-recommendations/duplicate-strings.html
2. Wrong memory size settings
3. Inefficient Collections: http://heaphero.io/heap-recommendations/inefficient-collections.html
4. Duplicate Objects: https://heaphero.io/heap-recommendations/duplicate-objects.html
5. Duplicate arrays: https://heaphero.io/heap-recommendations/duplicate-primitive-arrays.html
6. Inefficient arrays: https://heaphero.io/heap-recommendations/inefficient-primitive-arrays.html
7. Objects waiting for finalization: https://heaphero.io/heap-recommendations/objects-waiting-
finalization.html
8. Boxed numbers: https://heaphero.io/heap-recommendations/boxed-numbers.html
9. Object Headers: https://heaphero.io/heap-recommendations/object-headers.html

26. Reduce computing cost
Better Response time
Reduce Garbage Collection Pause Time
Optimizing memory

27. Fascinating to read

28. Thank you!!
ram@tier1app.com
Ram Lakshmanan
@tier1app
https://www.linkedin.com/company/gceasy
Any Questions
Deck will be published in:
http://blog.heaphero.io
