How to choose between SharePoint lists, SQL Azure, Microsoft Dataverse with Doctor Flow and Isa
- 1. 29TH NOVEMBER – 1ST DECEMBER 2021 Isabelle Van Campenhoudt Serge Luca Power Platform Associates HOW TO CHOOSE BETWEEN SHAREPOINT LISTS, SQL AZURE, MICROSOFT DATAVERSE
- 2. ♡ DIAMOND AND PLATINUM SPONSORS ♡
- 3. Isabelle Van Campenhoudt Data Platform MVP, Brussels Consultant, Speaker Trainer, Community Leader SQL server since 1999 SharePoint BI & Power BI since it starts Blog: theSQLGrrrl.wordpress.com ivc@shareql.com Twitter: @theSQLgrrrl SQL BI Tuning Architecture Coffee making
- 4. Doctor Flow aka “Serge Luca” Business Application MVP, Brussels MVP 15th year Business Apps, Office 365 Solution architect Creator of the open-source Power Platform BPM Toolkit Author of “Power Automate in a day” Blog: sergeluca.wordpress.com sergeluca@shareql.com Twitter: @sergeluca
- 5. Agenda Power Platform overview What you really need to know about Dataverse Dataverse versus SQL, SharePoint [Go-No Features] Dataverse versus SQL, SharePoint [Cherry on the cake features] Conclusions
- 7. Overview of the Power Platform
- 8. In our Power Platform+ governance check list :
- 9. Connectors • More than 480 connectors • Connectors to • Dataverse • SQL server (cloud and on premises) • SharePoint (cloud and on premises)
- 10. Where to start Advice : if you have existing data somewhere, keep it where it is • There are connectors • On premises : use the on- premises data gateway The question is : what should I chose if I start from scratch ?
- 11. Go–No Go features Storage Performance Real time Api calls/ connection RPO/RTO Price Document storage & management Transactions Silos Power Apps Portal Model driven apps Complex relational model AI Builder Security Field level security Security : record sharing/row level security
- 12. What your really need to know about Dataverse
- 13. Microsoft Dataverse – what´s in the box? API
- 14. It is much more than a database • Storage • Application Server • Back-end of Dynamics 365 2 configurations • Dataverse Not free • Dataverse for Teams "Free" with Microsoft 365 Limitations
- 15. Dataverse Compute Storage oData web api Dataverse. . . Runs on Azure
- 16. Dataverse Compute Eventing + Extensibility Storage Dataverse. . . Extends with Azure
- 18. How can we use Dataverse Create an environment Create a table Secure the table (who can do what) Call the oData Web api Directly or indirectly (connectors)
- 19. Call the Dataverse oData Web api directly
- 20. Call Dataverse by using the Dataverse connector
- 21. 1 table in Dataverse = 1 table in Azure SQL
- 22. FetchXML = the SQL language of Dataverse https://docs.microsoft.com/en-us/powerapps/developer/data- platform/use-fetchxml-left-outer-join-query-records-not-in
- 26. Price : you get what you pay for Each end user interacting with DV Or SQL must have a premium license Power Apps Per app license: 1 app 1000 employees x4,20€/month x 12 months = 50.400 €/Year Power Apps Per user license: Unlimited apps 1000 employees x16,20€/month x 12 months = 194.400 €/year Pay as you go : 8,20€/month/employee/used application in the month Azure SQL SharePoint Dataverse Dataverse for Teams Each end user must pay: Premium + Storage M365 License Premium M365 License
- 27. Dataverse storage price Dataverse storage • Database • Logs • Files Premium Licences give storage • Power Apps per user: 10 GB Db, 20 GB Files, 2 GB logs Buy add-ons to have more storage • 2 GB • 1 millions rows
- 28. Saas/Paas Azure SQL SharePoint Dataverse Dataverse for Teams PaaS SaaS SaaS SaaS
- 29. Storage capacity Azure SQL • SQL • “unlimited” SharePoint • meta model on top of SQL & Azure Blob storage • “unlimited” (30 M/List) Dataverse • SQL, Cosmos DB, Azure Blob Storage • “unlimited” Dataverse for Teams • SQL, Cosmos DB, Azure Blob Storage • 1 M rows, 2 GB
- 30. Business continuity Azure SQL SharePoint Dataverse Dataverse for Teams SLA:99,99% RPO 5-10 min RTO <12h PITR 1-365 geo replication and LTR 10 years SLA:99,9% SLA Backups every 12 hours Records retention : 90 days retention (Recycle Bin) SLA :99,9% RPO :5-10 min Backups expires after 7 days SLA :99,9% RPO :5-10 min Backups expires after 7 days Third party tools can be purchased to extend the backup retention period (Dataverse and SP) SLA= Service Level Agrement RTO = Recovery Time Objective RPO = Recovery Point Objective LTR = Long Term Rention PITR =Point in Time Restore 99,9% = 8h45 downtime a year 99,99% = 58 minutes a year
- 31. Performance & throttling Azure SQL SharePoint Dataverse Dataverse for Teams Performance Very high Average Very high Very high Api calls/ connection 3000/60sec 600/60 sec 1200/60 sec 1200/60 sec
- 32. Extensibility Azure SQL SharePoint Dataverse Dataverse for Teams Extensibility Trigger, Stored proc, Power Automate Power Automate SharePoint Framework Workflows, plugins, rollups, Power Automate, jobs Power Automate, Power Fx in the DB
- 33. DEMO
- 34. Extensibility in Dataverse : Rollup fields
- 35. Extensibility in Dataverse : Power Automate
- 36. Extensibility in Dataverse for Teams Power Fx Formulas in the Database
- 37. Security Azure SQL SharePoint Dataverse Dataverse for Teams Role Based Security **** **** ***** *** Record Sharing Yes Yes Yes No Field Level Security Yes No Yes No Hierarchy No No Yes No
- 38. Security roles in Dataverse • When a record is created, defines who can • Create • Read • Modify (Write) • Own (Assign) • Share with someone else
- 39. HR (Manager) Sales Org (Power Platform Associates) HR Belgium HR China User 2 User 3 User 1
- 40. Hierarchical security : based on hierarchy
- 41. Hierarchical security : based on position
- 42. Dataverse for Teams Security
- 43. Transactions Azure SQL SharePoint Dataverse Dataverse for Teams Transactions Yes No Yes Yes
- 44. Transactions
- 45. Applications that require Dataverse Power Apps Portal Model Driven Apps AI Builder Dataverse (not DV4T!)
- 46. Applications requiring Dataverse Azure SQL SharePoint Power Apps Portal Via Power Automate Via Power Automate Model Driven Apps Via Power Automate Via Power Automate AI Builder No No
- 47. Cherry on the cake
- 48. Dataflows Azure Data Lake Synapse Any data source Any data source Dynamics 365 Apps Power Apps Power Automate Power Virtual Agent Power BI Standard dataflows ( V1 & V2) Analytical dataflows Dataverse Copy Combine Transform Refresh (Power Query Online)
- 49. Dataflow integration Dataverse connectors Dataverse for Teams connectors
- 50. Off-line support Azure SQL SharePoint Dataverse Dataverse for Teams Off-line To be implemented in client app To be implemented in client app Out of the box No
- 51. Dataverse relevance search Entities can be indexed + crawled and be searched The internal engine is Azure Cognitive Search Document in entities can be indexed too The (Apache) Lucerne query syntax can be used • Fuzzy search, proximity search,… • https://docs.microsoft.com/en-us/azure/search/query-lucene- syntax
- 52. Auditing Auditing at the environment level Auditing at the table level Auditing at the field level
- 53. Activity logging
- 54. Conclusions
- 55. Conclusions Keep your data where it is You cannot be wrong by using SQL Azure In most case Dataverse is a great SaaS solution It gives you many Dynamics 365 features You can combine You can upgrade from DV4T to DV SQL/SharePoint/Dataverse Dataverse for Teams and SharePoint Dataverse is not a toy
- 56. thank you questions? BLOG URL TWITTER HANDLE
Editor's Notes
- What is truly Dataverse? Not a toy , not a new Access What are the criteria to choose the solution or defend your choice Understanding the criteria implications--- the devil is in the details Find out what can potentially block your project “NoGo” Conclusions
- Language used in Power Apps = Power Fx Language used in Power Automate = Logic Apps + Power Fx in 2022
- 17
- 18
- https://org0b5d1649.crm4.dynamics.com/api/data/v9.1/shareql_expenseses
- Animations are ok
- Show sql server
- https://docs.microsoft.com/en-us/powerapps/developer/data-platform/use-fetchxml-left-outer-join-query-records-not-in
- https://docs.microsoft.com/en-us/power-platform/admin/business-continuity-disaster-recovery TODO ISA : expliquer En Azure SQL, quelles sont les options qui permettent quasiment d’être en SaaS ? Les options automatiques sont typiquement Paas: mise a jours, aavailability, monitoring auditing et scalability. Parc ontre il n’y a pas d’aide particulière à “l’interieur” de l’outil Ca requiert donc une connaissance de SQL dev– mais pas trop d’admin ou en tout cas c’est vachement allege Voir: https://docs.microsoft.com/en-us/azure/azure-sql/database/sql-database-paas-overview Outils:
- SharePoint meta model = several SP list combined in one SQL Table -> more contention TODO serge check dataverse max size
- SharePoint meta model = several SP list combined in one SQL Table -> more contention TODO serge demo
- SharePoint meta model = several SP list combined in one SQL Table -> more contention TODO serge demo
- SharePoint meta model = several SP list combined in one SQL Table -> more contention TODO serge demo
- SharePoint meta model = several SP list combined in one SQL Table -> more contention
- If we define a security role with ‘Business unit’ and we apply this role to HR. People of HR won’t see the data generated by people from HR Belgium and HR China If we define a security role with ‘Parent child Business uni’t and we apply this role to HR.
- If we define a security role with ‘Business unit’ and we apply this role to HR. People of HR won’t see the data generated by people from HR Belgium and HR China If we define a security role with ‘Parent child Business uni’t and we apply this role to HR.
- SharePoint meta model = several SP list combined in one SQL Table -> more contention
- SharePoint meta model = several SP list combined in one SQL Table -> more contention
- https://docs.microsoft.com/en-us/power-query/dataflows/dataflows-teams
- There is an api and the first thing that happens when we hit this api is to trigger the security layer
- Staffing, culture
