Short history of database systems from DBMS, RDBMS to NoSQL solutions. Introduction to SQL query support of Azure DocumentDB and integrating DocumentDB with simple Java application from Maven repository.

1. NOSQL & DOCUMENTEDB
SONER ALTIN

2. @kahve
• Soner ALTIN
• BizDev @T2
• soner.in
• Organise hackathons
(t2hackathon.com)
• Strong interest in Led Zeppelin
• soneraltin@me.com /
soner.altin@t2.com.tr

3. HISTORY OF DBMS AND RDBMS
Database management systems first appeared on the scene in 1960 as
computers began to grow in power and speed. In the middle of 1960, there
were several commercial applications in the market that were capable of
producing “navigational” databases. These navigational databases
maintained records that could only be processed sequentially, which
required a lot of computer resources and time.
Relational database management systems were first suggested by
Edgar Codd in the 1970s. Because navigational databases could not
be “searched”, Edgar Codd suggested another model that could be
followed to construct a database. This was the relational model that
allowed users to “search” it for data. It included the integration of the
navigational model, along with a tabular and hierarchical model.
60’s 70’s 80’s 90’s 00’s

4. A relational database is a
digital database whose
organization is based on the
relational model of data

5. RDMBS 40 YEARS!
1. A simple way of representing data/ business models
2. An easy-to-use language to retrieve and query that data
(SQL)
3. Bulletproof data integrity and security built right into the
database without having to rely on application rules and
logic.

6. ACCESS AND STORAGE
▸ It is generally easier to access data that is stored in a relational
database. This is because the data in a relational database follows
a mathematical model for categorization. Also, once we open a
relational database, each and every element of that database
becomes accessible, which is not always the case with a normal
database (the data elements may need to be accessed
individually).
▸ Relational databases are harder to construct, but they are better
structured and more secure. They follow the ACID (atomicity,
consistency, isolation and durability) model when storing data.
The relational database system will also impose certain
regulations and conditions that may not allow you to manipulate
data in a way that destabilizes the integrity of the system.

7. PERSISTENCE
REPORTING
TRANSACTIONS
SQL
INTEGRATION

8. 3V - VOLUME VARIETY VELOCITY
▸ Five years ago, Amazon found that every 100ms of latency cost them 1% of sales. Google
discovered that a half-second increase in search latency dropped traffic by 20%.
▸ The volume of required data handling today is skyrocketing. Facebook houses 1.5 PB (Peta Bytes)
of uploaded photos. Google processes 20PB of data each day. Every 60 seconds over 204 million
emails are exchanged, 3,600 photos are shared on Instagram and 2 million search queries are
processed by Google. RDBMSs struggle in the face of such huge data volumes and RDBMS
solutions capable of handling such volumes are extremely expensive.
▸ Big Data also demands collection of an extremely wide variety of data types, but RDBMSs have
inflexible schemas. The problem is that Big Data primarily comprises semi-structured data, such as
social media sentiment analysis and text mining data, while RDBMSs are more suitable for
structured data, such as weblog, sensor and financial data.
▸ In addition, Big Data is accumulated at a very high velocity. Since RDBMSs are designed for steady
data retention, rather than for rapid growth, using RDBMSs for Big Data is prohibitively expensive.
60’s 70’s 80’s 90’s 00’s 10’s

9. TODAY
▸ Developers are working with applications that
create massive volumes of new, rapidly changing
data types — structured, semi-structured,
unstructured and polymorphic data.
▸ Long gone is the twelve-to-eighteen month
waterfall development cycle. Now small teams
work in agile sprints, iterating quickly and
pushing code every week or two, some even
multiple times every day.
▸ Applications that once served a finite audience
are now delivered as services that must be
always-on, accessible from many different
devices and scaled globally to millions of users.
▸ Organizations are now turning to scale-out
architectures using open source software,
commodity servers and cloud computing instead
of large monolithic servers and storage
infrastructure.

10. Structured Unstructured Semi-structured
Pre-defined God knows Pre-defined
Relational Non-relational So so
Constant Flexible Easy to change
RDBMS HDFS *
CRM, Travel, Phone
numbers
Web, Video, Music, Photo Tagging, Comments
%5 %15 %80
No need to scale
horizontally
Fully scalable Fully scalable

11. /*
* Copyright 2007 Yusuke Yamamoto
*/
/**
* A data interface representing one single status of a user.
*
* @author Yusuke Yamamoto - yusuke at mac.com
*/
public interface Status extends Comparable<Status>, TwitterResponse,
EntitySupport, java.io.Serializable {
Date getCreatedAt();
long getId();
String getText();
String getSource();
boolean isTruncated();
long getInReplyToStatusId();
long getInReplyToUserId();
String getInReplyToScreenName();
GeoLocation getGeoLocation();
Place getPlace();
boolean isFavorited();
boolean isRetweeted();
int getFavoriteCount();
User getUser();
boolean isRetweet();
Status getRetweetedStatus();
long[] getContributors();
int getRetweetCount();
boolean isRetweetedByMe();
long getCurrentUserRetweetId();
boolean isPossiblySensitive();
String getLang();
Scopes getScopes();
String[] getWithheldInCountries();
long getQuotedStatusId();
Status getQuotedStatus();
}
/*
* Copyright 2007 Yusuke Yamamoto
*/
/**
* A data interface representing Basic user information element
*
* @author Yusuke Yamamoto - yusuke at mac.com
*/
public interface User extends Comparable<User>, TwitterResponse, java.io.Seria
long getId();
String getName();
String getScreenName();
String getLocation();
String getDescription();
boolean isContributorsEnabled();
String getProfileImageURL();
String getBiggerProfileImageURL();
String getMiniProfileImageURL();
String getOriginalProfileImageURL();
String getProfileImageURLHttps();
String getBiggerProfileImageURLHttps();
String getMiniProfileImageURLHttps();
String getOriginalProfileImageURLHttps();
boolean isDefaultProfileImage();
String getURL();
boolean isProtected();
int getFollowersCount();
Status getStatus();
String getProfileBackgroundColor();
String getProfileTextColor();
String getProfileLinkColor();
String getProfileSidebarFillColor();
String getProfileSidebarBorderColor();
boolean isProfileUseBackgroundImage();
boolean isDefaultProfile();
boolean isShowAllInlineMedia();
int getFriendsCount();
Date getCreatedAt();
int getFavouritesCount();
int getUtcOffset();
String getTimeZone();
String getProfileBackgroundImageURL();
String getProfileBackgroundImageUrlHttps();
String getProfileBannerURL();
String getProfileBannerRetinaURL();
String getProfileBannerIPadURL();
String getProfileBannerIPadRetinaURL();
String getProfileBannerMobileURL();
String getProfileBannerMobileRetinaURL();
boolean isProfileBackgroundTiled();
String getLang();
int getStatusesCount();
boolean isGeoEnabled();
boolean isVerified();
boolean isTranslator();
int getListedCount();
boolean isFollowRequestSent();
URLEntity[] getDescriptionURLEntities();
URLEntity getURLEntity();
String[] getWithheldInCountries();
}}

12. /*
* Copyright 2007 Yusuke Yamamoto
*/
/**
* A data interface representing one single URL entity.
* @author Mocel - mocel at guma.jp
*/
public interface URLEntity extends TweetEntity, java.io.Serializable {
String getText();
String getURL();
String getExpandedURL();
String getDisplayURL();
int getStart();
int getEnd();
}
/**
* @author Yusuke Yamamoto - yusuke at mac.com
*/
public interface Place extends TwitterResponse, Comparable<Place>,
java.io.Serializable {
String getName();
String getStreetAddress();
String getCountryCode();
String getId();
String getCountry();
String getPlaceType();
String getURL();
String getFullName();
String getBoundingBoxType();
GeoLocation[][] getBoundingBoxCoordinates();
String getGeometryType();
GeoLocation[][] getGeometryCoordinates();
Place[] getContainedWithIn();
}
https://dev.twitter.com/rest/reference/get/statuses/retweets_of_me

13. SCALABILITY

14. NON
RELATIONAL
Provides a mechanism for
storage and retrieval of
data which is modeled in
means other than the
tabular relations used in
relational databases

15. REQUIREMENTS
▸ over 425 million unique users
▸ store 20 TB of JSON document
data
▸ available globally to serve all
markets
▸ store for 40+ apps / device
combinations
▸ under 15 ms writes and single
digits ms reads

16. CONTROL OVER
AVAILABILITY
HORIZONTAL
SCALABILITY
SIMPLICITY OF
DESIGN
BIG DATA
REAL TIME
APPLICATIONS
EASIER
DEVELOPMENT

17. SCALABILITY VS FUNCTIONALITY
scalability&performance
depth of functionality
rmdbs
nosql
memcached
key/value store

18. ECONOMICS
The goal of a business, of course, is to make
money, and that’s accomplished by
providing more for less. NoSQL databases
drastically reduce the need for insanely big
machines. Typically, they use clusters of
cheap commodity servers to manage
exploding data and transaction volumes. The
cost-per-gigabyte or transaction/second for
NoSQL can be considerably lower than the
cost for RDBMSs, thereby dramatically
reducing the cost of data processing and
storage. Another area of key savings is in
manpower. By lowering administrative costs
one can free up developers to code new
features that will generate more revenue.

19. bit.ly/fowler-schemaless

20. SCHEMALESS - DATA UPDATE
The documents stored in the database can
have varying sets of fields, with different
types for each field. One could have the
following objects in a single collection:
{ name : “Joe”, x : 3.3, y : [1,2,3] }
{ name : “Kate”, x : “abc” }
{ q : 456 }
Of course, when using the database for real
problems, the data does have a fairly
consistent structure. Something like the
following would be more common:
{ name : “Joe”, age : 30, interests : ‘football’ }
{ name : “Kate”, age : 25 }
One of the great benefits of dynamic objects is
that schema migrations become very easy.
With a traditional RDBMS, releases of code
might contain data migration scripts. Further,
each release should have a reverse migration
script in case a rollback is necessary. ALTER
TABLE operations can be very slow and result
in scheduled downtime.
With a schemaless database, 90% of the time
adjustments to the database become
transparent and automatic. For example, if we
wish to add GPA to the student objects, we add
the attribute, resave, and all is well – if we look
up an existing student and reference GPA, we
just get back null. Further, if we roll back our
code, the new GPA fields in the existing objects
are unlikely to cause problems if our code was
well written.

21. NOSQL
data model performance scalability flexibility complexity
column high high moderate low
document high variable high low
key-value high high high none
graph variable variable high high

22. NOSQL TYPES
data model examples
column Cassandra, HBase
document
DocumentDB, MongoDB,
ElasticSearch
key-value Redis, MemcacheDB
graph Neo4J, OrientDB

23. fully featured RDBMS
transactional processing
rich query
managed as a service
elastic scale
internet accessible http/rest
schema-free data model
arbitrary data formats

24. schema free
query
Relational and hierarchical query of application defined JSON data. Support for
SQL queries with transforms, projections and inline evaluation of user defined
JavaScript functions (UDFs). Automatic and consistent indexing of all
properties.
JavaScript as a
modern T-SQL
Transactional execution of application defined stored procedures and triggers
directly against database collections. Native JavaScript support eliminating the
impedance mismatch between application and database schema.
tunable
consistency
Well defined consistency levels to achieve optimal tradeoff between consistency and
performance. Four distinct consistency levels for queries and read – Strong,
Bounded-Staleness, Session and Eventual. Granular control over consistency,
availability and latency
fully
managed
Simple to provision and access databases without managing VM or cluster
infrastructure. Operated with 99.95% availability and automatically backed up to
prevent against regional failures
{ }

26. PRICING
DocumentDB collections are available in the Standard service tier. Collections are
billable entities, each billed hourly, based on the performance level assigned to
the collection. Collections are set to one of three performance levels – S1, S2 or
S3. You can also dynamically change the performance level of a collection – for
example, create an S1 collection, scale up to S3 then back to S2.

27. TUNABLE CONSISTENCY
type latency performance
strong high low
bounded staleness moderate moderate
session low for session fast for session
eventual low fast

28. RAPID DEVELOPMENT
No setup cost
Auto scale
High available
No configuration management cost
Integration with all Azure services
SDK support for JavaScript, Java, Node.js, Python, and .NET.

29. PREPARATION

30. CONFIGURATION

31. QUERIES
{
"id": "AndersenFamily",
"lastName": "Andersen",
"parents": [
{ "firstName": "Thomas" },
{ "firstName": "Mary Kay"}
],
"children": [
{
"firstName": "Henriette Thaulow", "gender": "female", "grade": 5,
"pets": [{ "givenName": "Fluffy" }]
}
],
"address": { "state": "WA", "county": "King", "city": "seattle" },
"creationDate": 1431620472,
"isRegistered": true
}
{
"id": "WakefieldFamily",
"parents": [
{ "familyName": "Wakefield", "givenName": "Robin" },
{ "familyName": "Miller", "givenName": "Ben" }
],
"children": [
{
"familyName": "Merriam",
"givenName": "Jesse",
"gender": "female", "grade": 1,
"pets": [
{ "givenName": "Goofy" },
{ "givenName": "Shadow" }
]
},
{
"familyName": "Miller",
"givenName": "Lisa",
"gender": "female",
"grade": 8 }
],
"address": { "state": "NY", "county": "Manhattan", "city": "NY" },
"creationDate": 1431620462,
"isRegistered": false
}

32. QUERIES
{
"id": "AndersenFamily",
"lastName": "Andersen",
"parents": [
{ "firstName": "Thomas" },
{ "firstName": "Mary Kay"}
],
"children": [
{
"firstName": "Henriette Thaulow", "gender": "female", "grade": 5,
"pets": [{ "givenName": "Fluffy" }]
}
],
"address": { "state": "WA", "county": "King", "city": "seattle" },
"creationDate": 1431620472,
"isRegistered": true
}
* Operator
SELECT *
FROM Families f
WHERE f.id = "AndersenFamily"
[{
"Family": {
"Name": "WakefieldFamily",
"City": "NY"
}
}]
Where
SELECT {"Name":f.id, "City":f.address.city} AS Family
FROM Families f
WHERE f.address.city = f.address.state
[
{ "givenName": "Jesse" },
{ "givenName": "Lisa"}
]
Join
SELECT c.givenName
FROM Families f
JOIN c IN f.children
WHERE f.id = 'WakefieldFamily'
ORDER BY f.address.city ASC

33. QUERIES [{
"$1": {
"state": "WA",
"city": "seattle"
},
"$2": {
"name": "AndersenFamily"
}
}]
Nested properties
SELECT { "state": f.address.state, "city": f.address.city },
{ "name": f.id }
FROM Families f
WHERE f.id = "AndersenFamily"
[
{
"AreFromSameCityState": false
},
{
"AreFromSameCityState": true
}
]
Scalar expression
SELECT f.address.city = f.address.state AS AreFromSameCityState
FROM Families f
ORDER BY
SELECT f.id, f.address.city
FROM Families f
ORDER BY f.address.city
[
{
"id": "WakefieldFamily",
"city": "NY"
},
{
"id": "AndersenFamily",
"city": "Seattle"
}
]

34. QUERIES
{
"Type": "Stratovolcano",
"Status": "Tephrochronology",
"Location": {
"type": "Point",
"coordinates": [
-121.49,
46.206
]
}
}
Geospatial WITH_IN
SELECT v.Type, v.Status, v.Location
FROM volcanoes v
WHERE ST_WITHIN(v.Location,
{ "type": "Polygon", "coordinates": [[
[-124.63, 48.36], [-123.87, 46.14],
[-122.23, 45.54], [-119.17, 45.95],
[-116.92, 45.96], [-116.99, 49.00],
[-123.05, 49.02], [-123.15, 48.31],
[-124.63, 48.36]]]}
)
Geospatial ST_DISTANCE
SELECT v.Elevation, v.Type, v.Region, v["Volcano Name"]
FROM volcanoes v
WHERE ST_DISTANCE(v.Location, {
"type": "Point",
"coordinates": [-122.19, 47.36]
}) < 100 * 1000
AND v.Type = "Stratovolcano"
AND v["Last Known Eruption"] =
"Last known eruption from 1800-1899, inclusive"
{
"Elevation": 4392,
"Type": "Stratovolcano",
"Region": "US-Washington",
"Volcano Name": "Rainier"
}

35. LET’S TRY
SOME QUERIES

36. JAVA SPRING APP
TWITTER STREAMING APP

37. MICROSERVICE
TWITTER STREAMING APP

38. <DEPENDENCY>
<GROUPID>COM.MICROSOFT.AZURE</GROUPID>
<ARTIFACTID>AZURE-DOCUMENTDB</ARTIFACTID>
<VERSION>1.5.1</VERSION>
</DEPENDENCY>
BIT.LY/DEVNOT-CODE

39. WE’RE HIRING
C# & JAVA DEVELOPERS
SONER.ALTIN@T2.COM.TR

40. DEMO
