HBase Replication
Wellington Chevreuil

2. © Cloudera, Inc. All rights reserved.
Overview
● Replication Basics
● Requirements
● HBase Shell Commands
● Implementation Details
● Monitoring
● Extra Tools
● Hands-on labs

3. © Cloudera, Inc. All rights reserved.
Replication Basics
● Source-push strategy
● Master, Source, Originator - means the cluster sending data.
● Slave, Destination, Target - means cluster receiving data.
● Can be cyclic and allows for multiple masters and slaves
○ A master can have multiple slaves
○ A slave can have multiple masters
○ A cluster can perform both master/slave roles on a given topology
● Eventual consistency
● Asynchronous
● Configurable at column family level
● Relies on WAL data
○ Any changes that bypass WAL won't be replicated, such as bulk load, truncate command, or if skip wal
has been enabled.
● Tracked via ZooKeeper
● Work done by RegionServers
● Adds a source cluster ID to edit's metadata

4. © Cloudera, Inc. All rights reserved.
Requirements
● All RegionServers must be accessible from all RegionServers from each cluster
● Zookeeper Quorum from slaves must be accessible by masters
● Table structure must be the same in master and slave clusters
○ The column family target for replication must match on master/slave clusters
● If same Zookeeper Quorum is used for master/slave clusters,
zookeeper.znode.parent must be different
● Clusters can have varying sizes
● Clusters can have pre-existing data on target tables
○ In this case, only data added on master after replication has been enabled will be replicated

5. © Cloudera, Inc. All rights reserved.
HBase Shell Commands
● add_peer
○ Sets a new slave to the current cluster.
● list_peers
○ Shows current list of slaves "known" by this cluster.
● disable_peer
○ Pause replication, but stays tracking new edits to be replicated.
● enable_peer
○ Resumes replication. All edits added since disable_peer execution will now be sent to related
slaves.
● remove_peer
○ Disables replication for the given slave.
○ No edits will be sent to the slave.

6. © Cloudera, Inc. All rights reserved.
HBase Shell Commands
● enable_table_replication
○ Sets replication flag as true on all column families from specified table.
● disable_table_replication
○ The opposite from the above.
● append_peer_tableCFs, remove_peer_tableCFs, set_peer_tableCFs,
show_peer_tableCFs, update_peer_config, get_peer_config, list_peer_configs,
list_replicated_tables.
○ General admin commands that allow for changing/monitoring configuration of tables currently
targeted for replication

7. © Cloudera, Inc. All rights reserved.
Implementation Details - Deployment Overview
● This is a deployment diagram
in the context of replication
only, so only major replication
flow relevant components are
highlighted.
● Note no presence of HMasters
either on master (source) or
slave (destination) clusters.
● Zookeeper is of vital
importance, as it keeps the
registry of edits to be
replicated, as well as peers to
replicate to.
● RSes on Master cluster depend
on ZK from Slave cluster.

8. © Cloudera, Inc. All rights reserved.
Implementation Details - Setup/Maintenance commands
● Shell commands interact directly with Zookeeper.
● Replication is kept on master cluster's Zookeeper znodes.
● No interaction within RSes when replication shell commands are ran.

9. © Cloudera, Inc. All rights reserved.
Implementation Details - Setup WAL and Replication
● RS init phase where
replication service classes are
created.
● Once replication related
classes are properly
initialized, Replication
instance is added to the list
of WALActionListener.
● WALFactory instance is
created, with the list of
listeners containing
Replication instance.

10. © Cloudera, Inc. All rights reserved.
Implementation Details - Setup WAL and Replication
● Replication related classes are only initialised if "hbase.replication" is set to true.
● This will happen between the following log messages from RS startup logs:
● Replication Source/Sink implementation default: org.apache.hadoop.hbase.replication.regionserver.Replication
○ This is configurable by hbase.replication.source.service and hbase.replication.source.service
INFO org.apache.hadoop.hbase.regionserver.HRegionServer: reportForDuty to master=...
INFO org.apache.hadoop.hbase.replication.ReplicationPeersZKImpl: Added new peer
cluster=remote_peer_host:2181:/hbase
INFO org.apache.hadoop.hbase.wal.WALFactory: Instantiating WALProvider of type class
org.apache.hadoop.hbase.wal.BoundedRegionGroupingProvider
Watch out for possible customer
specific configurations

11. © Cloudera, Inc. All rights reserved.
Implementation Details - Setup WAL and Replication

12. © Cloudera, Inc. All rights reserved.
Implementation Details - Setup WAL and Replication
● During WAL related classes creation, WAL file is rolled.
● Replication was added as a WAL listener before, so ReplicationSourceManager will be
notified about log roll.
● Using Zookeeper, ReplicationSourceManager adds the new WAL file to the queue of
logs (this will be under replication znodes).

13. © Cloudera, Inc. All rights reserved.
Implementation Details - Setup WAL and Replication
● Over WAL file rolling, no replication specific log message is recorded.
● ReplicationSourceManager code will be notified about new WAL file creation
between below messages:
INFO org.apache.hadoop.hbase.regionserver.wal.FSHLog: WAL configuration: blocksize=128 MB, ...
...
INFO org.apache.hadoop.hbase.regionserver.wal.FSHLog: New WAL /hbase/WALs/…
….

14. © Cloudera, Inc. All rights reserved.
Implementation Details - Setup WAL and Replication
● Potential errors involving replication on this phase will be mostly related to znodes
access, preventing ZK queue from being initialized:
ERROR org.apache.hadoop.hbase.regionserver.HRegionServer: Failed init
java.io.IOException: Failed replication handler create
at org.apache.hadoop.hbase.replication.regionserver.Replication.initialize(Replication.java:130)
at org.apache.hadoop.hbase.regionserver.HRegionServer.newReplicationInstance(HRegionServer.java:2662)
at org.apache.hadoop.hbase.regionserver.HRegionServer.createNewReplicationInstance(HRegionServer.java:2632)
at org.apache.hadoop.hbase.regionserver.HRegionServer.setupWALAndReplication(HRegionServer.java:1647)
at org.apache.hadoop.hbase.regionserver.HRegionServer.handleReportForDutyResponse(HRegionServer.java:1388)
at org.apache.hadoop.hbase.regionserver.HRegionServer.run(HRegionServer.java:918)
at java.lang.Thread.run(Thread.java:745)
Caused by: org.apache.hadoop.hbase.replication.ReplicationException: Could not initialize replication queues.
at org.apache.hadoop.hbase.replication.ReplicationQueuesZKImpl.init(ReplicationQueuesZKImpl.java:85)
at org.apache.hadoop.hbase.replication.regionserver.Replication.initialize(Replication.java:122)
... 6 more

15. © Cloudera, Inc. All rights reserved.
Implementation Details - Start Replication Thread
● From HRegionServer.startServiceThreads method, replication source and sink
threads are set and started.
● ReplicationSourceManager initialization involves several steps, to be detailed next.
● ReplicationSink instance will be used to perform the actual sink if the cluster act as a
destination cluster. To be detailed later.

16. © Cloudera, Inc. All rights reserved.
Implementation Details - Start Replication Thread

17. © Cloudera, Inc. All rights reserved.
Implementation Details - Start Replication Thread
● Once ReplicationSourceManager.addSource completed properly for each peer,
following message would be seen:
● Upon startup, ReplicationSource.run method will also log below message:
● Since this is asynchronously, it may occur before or after the previous message.
● It should be logged for each peer id.
INFO org.apache.hadoop.hbase.replication.regionserver.ReplicationSourceManager: Current list of replicators:
[host-1,60020,1510938412878, host1,60020,1510929825829] other RSs: [host-1,60020,1510938412878]
…
INFO org.apache.hadoop.hbase.replication.regionserver.ReplicationSource: Replicating
9fa10771-97b2-48ed-b635-b0bd474a99b2 -> 5f54f936-a5f8-4726-9d09-7bf1c709eeab

18. © Cloudera, Inc. All rights reserved.
Implementation Details - New Peers
● ReplicationTrackerZKImpl receives notification about changes on replication znodes.
● New peer addition triggers peer list update on ReplicationPeersZKImpl.
● With at least one peer, ReplicationQueuesZKImpl will get notified about WAL file
creation.
INFO org.apache.hadoop.hbase.replication.ReplicationTrackerZKImpl: /hbase/replication/peers znode expired, triggering
peerListChanged event
...
INFO org.apache.hadoop.hbase.replication.ReplicationPeersZKImpl: Added new peer cluster=peer-host:2181:/hbase

19. © Cloudera, Inc. All rights reserved.
Implementation Details - Shipping Edits
● Main work done by ReplicationSourceWorkerThread instances.
○ One per WAL group
○ Every WAL group has its own queue of WAL files to be processed.
○ Runs in the background indefinitely. Will sleep for replication.source.sleepforretries if peer is
disabled.
○ On each loop iteration:
■ Reads current WAL being written.
■ Apply editlog filters (get only edits for CFs marked for replication, whose cluster origin ID is not same as peer).
■ For editlogs filtered, connect to a RS on the remote cluster and send those (via RPC).
■ Edits must be read (and processed) sequentially. If shipment fails, replication will not progress for that WAL
group, and lags may be seen

20. © Cloudera, Inc. All rights reserved.
Implementation Details - Shipping Edits (Source Side)

21. © Cloudera, Inc. All rights reserved.
Implementation Details - Shipping Edits (Source Side)
● HBaseInterClusterReplicationEndpoint.replicate() method detailed flow
● Uses its own thread pool for performing RPC calls
● Replicator class implements java.util.concurrent.Callable for async execution.

22. © Cloudera, Inc. All rights reserved.
Implementation Details - Shipping Edits (Source Side)
● Replicator uses SinkPeer to discover remote RS responsible to run the sink.
● ReplicationProtbufUtil is used for convert request to protobuff and perform RPC.

23. © Cloudera, Inc. All rights reserved.
Implementation Details - Shipping Edits (Destination Side)
● ReplicationSink uses default client API to process put/delete operations.
● Not necessarily the RS running the sink is the same for the regions where entries will
be placed.
● Coprocessors may get invoked.

24. © Cloudera, Inc. All rights reserved.
Monitoring
● Some classes provide additional TRACE/DEBUG messages that can be turned on for
further troubleshooting.
● Worth enable it using RS UI for specific classes only, instead of turn TRACE to whole
HBase service:
○ ReplicationSource, HBaseReplicationEndpoint, HBaseInterClusterReplicationEndpoint,
● JMX Metrics might also help get a state of replication:
○ shippedBatches, AgeOfLastShippedOP, logReadInBytes.
■ Global and per WAL group id.
● ReplicationStatisticsThread also logs replication stats every 5 minutes:
IINFO org.apache.hadoop.hbase.replication.regionserver.Replication: Normal source for cluster 1: Total replicated edits: 2, current progress:
walGroup [host-1%2C60020%2C1511034265841.null0]: currently replicating from:
hdfs://nameservice1/hbase/WALs/host-1,60020,1511034265841/host-1%2C60020%2C1511034265841.null0.1511196279542 at position: 83

25. © Cloudera, Inc. All rights reserved.
Monitoring
● HBase shell status 'replication' command:
○ On source cluster:
○ On destination cluster:
1 live servers
Host-10-17-101-41.coe.cloudera.com:
SOURCE: PeerID=1, AgeOfLastShippedOp=0, SizeOfLogQueue=0, TimeStampsOfLastShippedOp=Mon Nov 20 10:02:05 PST 2017, Replication Lag=0
SINK : AgeOfLastAppliedOp=0, TimeStampsOfLastAppliedOp=Sat Nov 18 11:49:29 PST 2017
1 live servers
Host-10-17-103-206.coe.cloudera.com:
SOURCE:
SINK : AgeOfLastAppliedOp=0, TimeStampsOfLastAppliedOp=Mon Nov 20 08:40:19 PST 2017

26. © Cloudera, Inc. All rights reserved.
Monitoring
● VerifyReplication
○ MR job that compares the records for the table in source and destination cluster.
○ Prints counter within its findings:
1 test-1
...
17/11/20 10:43:12 INFO mapreduce.Job: map 0% reduce 0%
17/11/20 10:43:18 INFO mapreduce.Job: map 33% reduce 0%
17/11/20 10:43:19 INFO mapreduce.Job: map 67% reduce 0%
17/11/20 10:43:23 INFO mapreduce.Job: map 100% reduce 0%
17/11/20 10:43:24 INFO mapreduce.Job: Job job_1506585949780_0005 completed successfully
…
org.apache.hadoop.hbase.mapreduce.replication.VerifyReplication$Verifier$Counters
BADROWS=25
GOODROWS=11
ONLY_IN_SOURCE_TABLE_ROWS=25
...

27. © Cloudera, Inc. All rights reserved.
Monitoring
● DumpReplicationQueues
hbase org.apache.hadoop.hbase.replication.regionserver.DumpReplicationQueues --distributed
...
Dumping replication peers and configurations:
Peer: 2
State: ENABLED
Cluster Name:
clusterKey=host-10-17-103-187.coe.cloudera.com,host-10-17-103-189.coe.cloudera.com,host-10-17-103-193.coe.cloudera.com:2181:/hbase,replicationEndpoint
Impl=null
Peer Table CFs: null
…
Dumping replication queue info for RegionServer: [host-10-17-101-41.coe.cloudera.com,60020,1511971261591]
replication queue: 1
Replication position for host-10-17-101-41.coe.cloudera.com%2C60020%2C1511971261591.null0.1512140473468: 13227
...

28. © Cloudera, Inc. All rights reserved.
Extra Tools
● In case data is already available on either source/destination cluster tables, some
tools can be used to sync data:
○ CopyTable
■ https://hbase.apache.org/book.html#copy.table
○ Export Snapshots
■ https://hbase.apache.org/book.html#ops.snapshots.export
○ Bulk Load
■ https://blog.cloudera.com/blog/2013/09/how-to-use-hbase-bulk-loading-and-why/
○ HashTable/SyncTable
■ Now documented here.
■ Best option, can be used even after replication is already enabled.
■ Allows for syncing deleted rows.
■ Only available from CDH 5.9.0 onwards

29. © Cloudera, Inc. All rights reserved.
Extra Tools
● HashTable/SyncTable:
○ Two MR jobs
■ org.apache.hadoop.hbase.mapreduce.HashTable
■ org.apache.hadoop.hbase.mapreduce.SyncTable
○ Usage:
■ First, run HashTable MR job on the cluster whose state should be propagated to the remote peer. For example, if
we want to sync table "test-1" state on destination cluster with state from source cluster, run below at source:
● Where first param is the table name, and second param is an hdfs path where HashTable job should
output table's summary
$ hbase org.apache.hadoop.hbase.mapreduce.HashTable test-1 /tmp/test-1

30. © Cloudera, Inc. All rights reserved.
Extra Tools
● HashTable/SyncTable:
○ Usage
■ Once HashTable has finished on source cluster, run SyncTable on destination cluster:
■ First and second params are the ZK address and NN address of source cluster, respectively
■ Last two params are the table names on source and destination cluster
■ This command would cause the table data on destination cluster to be in sync with the source
cluster
● If source cluster had more rows prior to the command, these additional rows would be
copied to destination.
● If destination cluster had more rows then source, these rows would be deleted from
destination.
$ hbase org.apache.hadoop.hbase.mapreduce.SyncTable --sourcezkcluster=source_zk:2181:/hbase hdfs://source_nn:8020/tmp/test-1 test-1 test-1

31. © Cloudera, Inc. All rights reserved.
Labs Exercises
1. Problem 1: Replication related znodes not readable by RSes
2. Problem 2: Remote cluster not reachable by source cluster
3. Problem 3: Remote cluster is reachable, but sinks are not completing
