- 1. 背景图考虑更新 Goertek’s Experience with Qualcomm’sVR HMD Accelerator Program Accelerate Your VR HMD with Goertek’s Reference Design Dr. Allen Chien Director of VR/AR Product Marketing Goertek USA Said Bakadir Business & Product Lead, XR Business Qualcomm Technologies, Inc.
- 2. Who is Goertek? VR/ARRoboticsWearable VR accessories Gaming accessories Microphone SensorSPK BOX AntennaSpeaker Receiver LRA Optics lens Components ODM/JDM Finished Products Hearable ODM/JDM Accessories Pico Projector Module MIM
- 3. Goertek is ProvenWW #1 VR/AR ODM/JDM Partner Stand Alone VR Tethered VR Augmented Reality Accessories (Controllers/Cameras) Goertek made ~73% of 2017 WW Tethered VR Headsets Proven #1 VR/AR ODM/JDM Partner
- 4. 4 HMD Accelerator Program(HAP) Commercialize VR HMDs quickly with less resource restraints Commercialization High Quality Allow OEMs to quickly design and manufacture standalone VR HMDs Provide means for OEMs to track performance, monitor KPIs and promote them Standardizing a platform for the whole value chain to build on top and garner critical scale for VR to flourish Scale & Harmonization
- 5. 5 HMD Accelerator Program- Pillars Flexible, consistent approach to product development Product Reference Design ODM Partners Component/ Peripherals/ Technology Partners Performance and Quality Metrics/Testing Marketing Support 1 2 3 4 5
- 6. Goertek-Qualcomm VR History QualcommSnapdragon 820 VR HMD Since 2015….... Gen 1 Gen 2 Qualcomm Snapdragon 835 VR HMD Gen 3 Qualcomm Snapdragon 845 VR HMD
- 7. Successful VR 835Examples Pico Neo TFT LCD, 2880x1440 resolution, 90 Hz 6DOF Ultrasonic Controllers Built in 3D Audio Speakers $599 MSRP Available Now Lenovo Mirage Solo 5.5” LCD, 2560x1440 resolution, 75 Hz 3DOF Infrared Controllers Google Daydream 2.0 OS $399 MSRP Available Now
- 8. Qualcomm and Goertek DevelopHigh-Resolution VR Headset Reference Platform Accelerating Your Time-to-Market Qualcomm & Goertek VR Reference Design Highlights • Snapdragon 845 Mobile Platform • 4GB LPDDR4x RAM, 64GB Flash • Compute v65 DSP, 1.2GHz, 2xHVX, LPI, dedicated Audio DSP • Wi-Fi (11ac), Bluetooth (5.0), USB 3.1 Type-C, Trackpad Key VR features: • Room Scale 6DoF • 6DoF Controller Support • 3D Environment Mapping • Obstacle Avoidance • Eye Tracking • Foveated Rendering • 3D Audio Plugin Support for Unity Snapdragon 845
- 9. Qualcomm and Goertek DevelopHigh-Resolution VR Headset Reference Platform Snapdragon 845 Mobile Platform Snapdragon VR Software Development Kit (SDK) Goertek Qualcomm Firmware Acoustic Optical Electrical Mechanical System design Accelerating Your Time-to-Market Qualcomm & Goertek VR Reference Design
- 10. We’ve Got Allthe Key Components Covered
- 11. 机械设计 21% Goertek Capability –End to End Solution Mechanical Design Software Design ID Design Electronic Design RF & Antenna Design Acoustic-optic Design System Integration
- 12. VR Industry DesignCapability -Ergonomics Database With 10+ years wearable consuming electronics product and 4+ years VR HMD product experience, Goertek has built up our own ergonomics database. A B C D F E Purchase Ergonomics database from professional institution Ergonomics center Accumulation from previous products design and manufacture Goertek Ergonomics database Actual Measurement data from Employees and Customers A. Distance between nose bridge and occipital tip B. Distance between nose bridge and top head C. Distance between tragus and occipital tip D. Distance between canthus E. Distance between cheeks F. Distance between nose bridge and nose tip
- 13. • Excellent designteam ü >40 optical experts ü 10 years corporate experience • Optical expertise ü DOE + Fresnel ü Freeform, Light guide ü Large FOV ultra-thin lens • Advanced processing skills ü Class 1000 Clean Room ü Mold, injection, coating • Strong processing capacity ü Aspheric lens ü Fresnel Lens ü DOE product ü Curved prism • Complete testing equipment • E2E test solution ü Components, modules and products ü Optical parameters and image quality ü Reliability and durability ü Mold performance • Optical module assembly ü Super clean workshop ü 6 COB production lines ü Product quality monitoring ü Module AA assembly • Integrated optical module integrated solution service Design Manufacturing Testing Technology Integration • GTK Optical Research Institute ü Beijing Institute ü Changchun Institute ü Qingdao Optical laboratory • Technology accumulation ü Micro Display Technology ü VR lens technology ü AR optical path technology ü Lens film technology Goertek focuses on R&D and application of advanced optical technologies, we provide optical solutions for VR/AR. In House Optics Capability
- 14. Tooling Injection Molding Cleanroom Assembling EECTesting Development SMT LENS Forming VR-FATP Water Proof Surface Treatment Vertical integration of manufacturing resources & lean manufacturing- shortens lead time and lower costs Product Manufacturing Capability – Vertical Integration Lens Tooling Injection Molding LENS Clean Room Assembling PCBA Water Proof Assembling
- 15. HMD LENS OLED HMD Body Lens Tester •Back Focus testing • MTF testing • Light axis alignment • Distortion testing • Light uniformity testing • Adapting to 0 – 1000 degree nearsighted • Focal length testing accuracy：0.01mm • Resolution testing accuracy：0.01mm • Light axis alignment accuracy：0.02mm • Distortion testing accuracy : 0.1% • ACC testing； • GYRO testing； • ECOMPASS testing； • Linear accuracy：≤0.5 degree； • Angle accuracy：≤0.2 degree； IMU Tester • Recording force curve； • Button function； • Accuracy：0.05%； • Resolution：±0.001mm Force tester • X、Y、Z gesture sensing； • Accuracy：0.02mm； Gesture Tester • Calibration and test of P-Sensor； • Accuracy：1mm ； P-Sensor Tester • IPD sensor calibration and testing； • Accuracy：0.002mm； IPD Calibration Tester • Output power testing； • Power mask testing； • EVM testing； • Receiver sensitivity testing； • High accuracy Camera Tester Audio Tester • MIC calibration and testing； • Speaker calibration and testing； • High accuracy • Industry standard • Screen tilt testing； • Accuracy：0.001mm ； Screen Assembling Tester WIFI Test BT Test • Output Power • Power Control • Initial Carrier Frequency • Carrier Frequency Drift • Modulation Characteristic • Single Slot Sensitivity • Multi Slots Sensitivity • Maximum Input Level • Output power testing； • Power control testing； • Initial carrier frequency testing； • Carrier frequency drift testing； • MI、SS、MS、MIP testing； • High accuracy Manufacturing Capability- In-Line Testing • Camera image quality test ； • Camera calibration ；
- 16. Summary – UseQualcomm VR HMD Accelerator Program “Launch in half the time with half the resources” Comprehensive, Robust Reference Design Fast Prototyping All key components covered + =
