This document describes an automated garden control system that uses sensors to monitor soil moisture, temperature, humidity, and motion to control irrigation and other systems. The system uses sensors connected to a microcontroller that processes the sensor data and controls actuators like irrigation. Wireless communication using Zigbee allows the sensor data to be transmitted remotely and monitored on a computer. The goal is to automate garden maintenance and control environmental factors like moisture and temperature scientifically to optimize plant growth while reducing manual labor.
