This document provides an estimate for constructing a retaining wall near an odai (stream). It includes: 1) An itemized list of work descriptions and quantities for excavation, concrete work, plastering and murambu stone filling. 2) An abstract estimate summarizing the quantities, rates and amounts for each work item totaling 219,000 INR. 3) Specifications noting the concrete mixes and dimensions to be used in foundations, footings and superstructure according to approved drawings and standard specifications.

1. Name of work: Construction of a retaining wall at
Detailed Estimate.
S.No.
Description of work. No. Measurements Contents
L. B D
1 Earthwork excavation in all clauses of
soils with intial lead and lift as per SS 20B
For foundation.
Wall foundation. 1 45.00 1.40 0.75 47.25
2 Cement concrete 1:4:8 mix using 40mm
ISS HBG metal including all cost and
conveyance and all materials etc.complete.
Wall foundation 1 45.00 1.40 0.3 18.90
3 Cement concree 1:3:6 mix suing 40mm
ISS HBG metal including all cost and
conveyance and all materials etc. complete
including centering charges.
I st footing 1 45.00 1.25 0.45 25.31
Iind footing 1 45.00 0.78 2.00 69.75
average
95.06
4 Plastering with cement mortar 1:5, mix
20mm thick including all cost and
conveyance etc. complete.
Top of wall 1 45.00 0.45 20.25
5 Collection and supply of well murambu
from an average lead of 1KM including
all cost and conveyance and laying the
same as per standard specifications.
Side of wall 1 45.00 2.00 0.6 54.00
6 Contigencies and other unfroseen
charges. L.S..

2. Contents

3. Name of work:Construction of Flood Protective wall/retaining wall at
ABSTRACT ESTIMATE .
S.No. Description of work Quantity
Rate Per Amount
1 Earthwork excavation in all clauses of
soils with intial lead and lift as per SS 20B 47.25 52 1cum 2457
For foundation.
2 Cement concrete 1:4:8 mix using 40mm
ISS HBG metal including all cost and
conveyance and all materials etc.complete. 18.90 ### 1cum 31567
3 Cement concree 1:3:6 mix suing 40mm
ISS HBG metal including all cost and
conveyance and all materials etc. complete
including centering charges. 95.06 ### 1cum 177041
4 Plastering with cement mortar 1:5, mix
20mm thick including all cost and
conveyance etc. complete. 20.25 110.12 1sqm 2230
5 Collection and supply of well murambu
from an average lead of 1KM including
all cost and conveyance and laying the
same as per standard specifications. 54.00 96.25 1cum 5198
6 Contigencies and other unfroseen L.S. 508
charges.
total: 219000

4. SPECIFICATION REPORT TO ACCAMPANY THE ESTIMATE FOR THE WORK
OF CON STRUCTION OF A PROTACTIVE WALL/RETAINING WALL AT
Estimate Amount:Rs. 219000
It is proposed to construction of a protective wall/retaining wall
near by odai at
as per the District Collector
Proceedings No: Dated adopting
the current schedule of rates year the _10 under
the for 2009
scheme 2009_10.
The following provisions are made in this estimate.
1 Earthwork excavation as per SS 20 for foundation to a depth of
0.75m and to a wdith of 1.40 m
2 Cement coincrete 1:4:8 mix using 40mm ISS HBG metal will be
laid for 0.30m thick
3 Cement concrete 1:3:6 mix using 40mm ISS HBG metal will be laid
for Ist footing and superstructure as shown in the drawing.
4 The top of the wall will be plastered with CM1:5,20mm thick.
5 The side of the wall will be filled with well murambu as per
standardspecifications
On sanction of this estimate the work will be executed as per the standard
specifications and other relevant circulars in force.
