1. FALSE CEILINGS
Group 1 : Section A : V SEM
Team members
Sal S S
Rushabh Mahore
Abhinav Anand
Anjali Vardani
Atul Prabhakar
Diksha M
Rushali Jain
Himanshu Jariwala
Nachiket Nadgauda
Pranav Ubale
1
SUBMITTED TO : DR VILAS BAKDE , DEPT OF ARCHITECTURE AND PLANNING,
VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY

2. CONTENT
1.INTRODUCTION
2.HISTORY
3. PURPOSE
4. TYPES OF
FALSE CEILING
5. MATERIALS
6.TYPES OF GRID
FALSE CEILING
12. DISADVANTAGES
11.ADVANTAGES
10. TOP 5 FALSE
CEILING BRANDS
9. COMPONENTS OF
FALSE CEILING.
8. INSTALLATION
7.FALSE CEILING
SHAPES
13. MAINTENANCE &
ACCESSIBILITY
14. CALCULATION OF COST
15.REFERENCE

3. 1. INTRODUCTION : DEFINITION
● False ceilings are often secondary ceilings that are hung below
the main ceiling with the help of suspension cords or struts.
● These ceilings are crafted from a wide range of materials such
as POP (plaster of Paris), gypsum board, asbestos sheets,
particle board, aluminium panel, wood etc.
● They are also known as dropped ceiling or suspended ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
3

4. 2. HISTORY
● Dropped ceilings and ceiling tiles were being used in
Japan for aesthetic reasons as early as the Muromachi
Period (1337 to 1573). Blackfriars Theater in London,
England, built in 1596, had dropped ceilings to aid
acoustics
Initially modern dropped ceilings were built using
interlocking tiles
and the only way to provide access for repair or
inspection of the area above the tiles was by starting
at the edge of the ceiling, or at a designated "key
tile"
●
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
4

5. 2. HISTORY OF POP CEILING
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
● First used in the 1700s due to large quarry deposits of gypsum located
in Montmartre, a district of Paris, which was a leading center of plaster
● It is a mixture of calcined gypsum (calcium sulfate dihydrate), sand
and water
● plaster of Paris is when dry, it is still soft enough to be sanded and
carved.
● The use of finely ground gypsum plaster to create decorative molding
was popular during the 18th and 19th centuries.
5

6. 3. PURPOSE OF FALSE CEILING
● To enhance the beauty of Room Interior
● To conceal electrical wires and cables
● To Manage height of too high ceiling
● To provide Sound and Thermal Insulation
● To install light and other fixtures
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
6

7. ● Adds dimension without necessarily
overwhelming the space
● Available in a variety of colors, shapes, textures
and lighting options to draw the eye upwards
immediately
4 . Types of false ceiling Designs
Single-Layered false ceiling Multi-Layered false ceiling
● In larger rooms, a multi-layered ceiling becomes the focal point and
creates drama with the touch of grandeur
● If they are laid out touching the edges of the space volume, they are more
likely to make the space look wider by revealing its expanse
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
7

8. ● Constructed completely out of POP, the elements
protrude out of a regular false ceiling or, by contrast,
are tucked into it
● Revolves around space geometry
4. Types of false ceiling Designs
Plus-Minus POP false ceiling Coffered false ceiling
● Coffers are sunken square or boxy panels that are flexed into a ceiling
● creates the illusion of higher ceiling height and multiple dimensions
within one room.
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
8

9. Gypsum false ceilings:
● Gypsum, a hydrated sulphate form of calcium, is one of the most
commonly used false ceiling materials.
● Gypsum false ceilings are pre-designed. Once the desired shape,
size, and design of the false ceiling are decided upon, it can easily
be installed.
● It sports a smooth, seamless finish and is known to absorb heat
and noise.
● Being lightweight, it can easily be hung from an iron board from
the original ceiling.
5. False Ceiling Material:
Gypsum false ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
9

10. Plaster of Paris false ceilings
● Gypsum is heated to form Plaster of Paris (POP), which is then mixed with
water to form a paste.
● the POP false ceiling can be moulded into any shape, therefore, allowing
immense versatility to POP false ceiling designs.
POP is maintenance free and highly durable besides being good insulators
of cold and heat
Plaster of Paris false ceiling
Wood false ceilings
Wooden false ceilings
● Wooden false ceilings have excellent natural patterns and textures and are
most suited for cold climates
● Wooden panels can come in the form of hollow blocks, boards or panels.
● They are durable but are susceptible to termite attacks and warping.
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
10

11. Fibre false ceilings:
● Fibre false ceilings appear in the form of tiles. They are made of natural and
synthetic materials including wood, stone, tar, and other material.
● These false ceilings are strong, durable, budget-friendly, and resistant to
both heat and noise.
● Due to its ability to prevent heat and noise and low cost, false fibre ceilings
are usually used in commercial places and buildings.
Metal false ceilings:
● They comprise aluminium and galvanized iron due to their durability,
strength, and ability to absorb noise.
● Metal false ceilings are also available in different designs and shapes and are
easy to maintain.
● false metal ceilings are expensive in comparison to gypsum or POP false
ceilings.
Fiber False Ceiling
Metal False Ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
11

12. Glass false ceilings:
● Owing to its transparency, false glass ceilings are enchanting.
● One can get beautiful floral designs can be carved on the glass or completely transparent
allowing an unrestricted view of the sky and surroundings.
● Their transparency can be used effectively to make small spaces look bigger
PVC false ceilings:
● PVC false ceilings are mostly installed in washrooms, kitchens, garages, and other places.
● They are lightweight, easy to maintain, and light on your pocket as well.
Fabric and synthetic leather false ceilings:
● Fabric and Synthetic leather false ceiling generally use a cloth or leather
● . These can be moulded and designed with ease. However, they are not meant for long
term use and are generally created for a specific occasion.
● They are prone to dust and damage.
Glass
False
Ceiling
Fabric
False
Ceiling
Pvc
False
Ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
12

13. NAME PRICE MAINTENANCE WATER-PROOF FIRE-PROOF Durability
Wooden High High No No Low
POP(plaster of
Paris)
Low Low Yes Yes High
Gypsum/ Gypsum
Board
Low Low Yes Yes High
PVC Low Low Yes No High
Metal High High No Yes Medium
Glass High High Yes No Low
Fabric Low High No No Low
Fibre Low Low Yes Yes High
Comparison of false ceiling materials
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
13

14. 6. Types of Grid False Ceiling
1. Exposed Grid
● these ceilings are easily identified by the fact that the
grid work supporting the tiles is exposed
● The exposed grid system is suspended from the soffits
using pre-tensioned suspension wire, rigid angle, rigid
hangers and threaded rod
● There are four main types of exposed grid systems:
1 Tee section
2 Linear slotted tees
3 ‘C’ profile main runner
4 Bandraster section
tee section C’ profile main runner / cross runner sections
linear slotted
base
a bandraster section with widths of 50-150mm
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
14

15. 6. Types of Grid False Ceiling
2. Concealed Grid
● With this type of ceiling, the grid work supporting the tiles or membrane is concealed and only
the ceiling tiles are visible
● The tiles or membranes can be metal, mineral wool, gypsum, calcium silicate, stone wool and
glass wool
● Mineral wool and gypsum-This type of ceiling employs a method of interlocking panels into
each other and the grid with the use of small strips of metal called 'splines'. Normally, these
type of ceilings will have a ‘key panel’ (usually in the corner) which can be removed, allowing
for the other panels to be slid out of the grid (a series of metal channels called 'Z bars') one by
one, until eventually removing the desired panel.
● Metal- The metal tiles can be either clipped into, hooked over or held in place with torsion
springs into the supporting grid work
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
15

16. 6. Types of Grid False Ceiling
3. Semi-Concealed/Partially exposed grid ceiling
● Some systems are a mixture of concealed and exposed
grid, where part of the supporting framework can be
seen from the underside of the ceiling.
● Sometimes the tile forms the two long supporting
edges while some have additional sections that form
part of the system
● The tiles and panels can be manufactured from mineral
wool, stone wool, gypsum, metal and timber.
semi concealed grid partially exposed grid
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
16

17. 1: Box ceiling
This design features a layered ceiling with
boxed and recessed lights attached to them.
2: Peripheral ceiling
This minimal design runs along the corners of the room and is
perfect for low ceiling homes. You can also find space for a
chandelier or pendant lights in this design.
7. False ceiling Shapes
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
17

18. 3: Geometric design
This design requires suspended panels for each
piece that is put together. It’s a modern design that
gives the room a stylish edge.
4: Intricate lattice
Installing a lattice in a false ceiling provides a subtle demarcation
to an open space and adds to the aesthetics of a room.
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
18

19. 5: Wooden slats
Wooden false ceilings are a favourite albeit expensive option
among homeowners. It is also one of the best insulating
ceiling options
6: Inverted cove
A great option to reduce high ceilings. It works well in every
room and is perfect for ambient lighting. You can also find
space for a chandelier in this design.
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
19

20. Installation process
8a. Installation process
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
20

21. Concealed/Clip in system T-Grid Suspension System
8b. Installing Diagram
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
21

22. Product Details
8c. Product Details
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
22

23. Accessories
8d. Accessories
Access panel Soffit Cleat
Drywall Screw
Edge Bead
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
23

24. Materials
❖ Aluminum channels
❖ Mild steel channels
❖ Wooden runners
❖ Stainless steel coated screw
9a. Materials and Components Of False Ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
24

25. Fixing framework directly on the beams
and structural ceiling.
Fixing the wall support and angle support.
Fixing suspended framework to the
supporting members.
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
25

26. Gypsum Board False Ceiling Details of light fixtures inside false ceiling
9b. Details Drawings of False ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
26

27. 9b. Details Drawings of False ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
27

28. 9b. Details Drawings of False ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
28

29. 10a. TOP 5 FALSE CEILING BRANDS
1. GYPROC SAINT GOBAIN
2. ARMSTRONG
3. SHERA
4. USG Boral
5. Gypcore
6. Gemini
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
29

30. 1. GYPROC SAINT-GOBAIN
● Saint-Gobain Gyproc India has been a pioneer and market leader in offering false ceiling and drywall solutions in India for the past 3 decades
● Complete range of products and systems for ceilings, dry walls and wall linings
● Products range includes
Gypsum plasterboards
grid ceiling tiles
metal framing
Plasters
jointing & finishing product
2. ARMSTRONG
Armstrong World Industries (AWI) is also a market leader in residential and commercial false ceiling manufacturing.
Armstrong is mostly used in commercial spaces as 2 x 2 grid ceiling. Easy to install and removable.
Over 3,700 employees around the globe and 24 manufacturing plants.
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
30

31. 3. SHERA
SHERA is 44 years old brand established in 1974 in Bangkok, Thailand.
SHERA manufactures interior and exterior plain and embossed pattern ceiling solutions.
4. Gypcore
Gypcore is an Oman based company. It is the 8-year-old brand.
Also known as GypsOman plaster boards.
Products:
Plasterboards
Plasters
Joint fillers
Metal frames
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
31

32. Products:
Drywall suspension system
Metal Ceilings
Acoustic panels and ceiling tiles
Joint Compounds
Wall Putty & plasters
● USG Boral is a leading manufacturer and supplier of gypsum-based wall and ceiling lining systems, mineral fiber ceiling
systems, metal framing, high performance panels, compounds and accessories
5. USG Boral
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
32

33. 1. Concealed / Clip-In System
● A concealed ceiling system is probably the most widely used metal tile ceiling system, and are often
suspended from the soffit.
● It has no visible grid and can integrate lighting, ventilation, and smoke detectors.
● Various acoustic requirements can also be met.
● The ceiling tiles are clipped into a concealed spring tee then are automatically leveled in the grid.
● The robust grid system can be easily installed and tiles can be removed and replaced for access to
services.
● Comprehensive ranges of the most popular sizes and perforation patterns are held in stock, together
with the necessary grid components.
10b. GEMINI TECHNICAL INDUSTRIES
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
33

34. 2.EXPOSED CEILING SYSTEM
● The GTI Exposed Ceiling Suspension System is a structural
suspension system for Lay – In Ceiling Panels.
● It consists of 24mm Main Channel and cross tees that combine
superior load carrying capacity, exceptional stability and design
flexibility.
● The GTI Exposed Ceiling System save time and money as its offers an
easy approach to installations and with the special stitch design in
GTI Tees that give more strength for the system and rigidity
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
34

35. 3.FURRING CEILING SYSTEM
● The GTI Furring Channel System is a concealed ceiling system that
suspends a hat shaped grid of furring channel in conjunction with a
primary support (main channel) and wall trim components onto which
plaster board is directly fixed.
● This allows for a smooth surface that can be kept plain or decorated.
● Lighting, access panels and ventilation can also be accommodated
easily.
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
35

36. 4.CEILING STRIP SYSTEMS
● Linear Strip Ceiling Systems are suitable for both interior and exterior
applications.
● Additionally, panels can be plain and perforated with acoustic backing added to
transform in to acoustic ceiling panels.
● Ceiling strip consists of strip panels with square edge in Butt or Gap joints in
modular recess.
● Self Supporting Strip consists of strip panels with square edge in Butt joints in
modular recess.
● Linear Strip System give decorative style and modernity with square edge.
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
36

37. 5.OPEN CELL SYSTEM
● An Open Cell System of 600*600 and 600*1200 are manufactured from
Aluminum U profiles to create an integrated system.
● Panels are built with upper and lower blades which is easy to dismantle for
easy access to ceilings.
● We offer a wide range of sizes, colors and finishes.
● Open Cell Ceiling systems features an integrated suspension system with
main and cross runners made from the same profiles as the cell ceiling
panels
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
37

38. 1. Beautiful Room :
False ceiling turns your ordinary room into extraordinary room.
It gives your room interior an elegant finish.
2. Control Room Temperature :
The best thing is thermal insulating features. It makes your home cooler
via thermal insulation properties and reduce excessive heat.
3. Mess free electric wire :
Another best thing is, it helps us to declutter our home by concealing electrical
wires and services. It reduces visual electric wire clutter.
4. Lower power cost :
It helps us to cut our electricity bills by reducing air conditioning loads.
11. Advantages Of False Ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
38

39. 1.It may get claustrophobic
● Construction of a ceiling panel usually causes the height of ceilings to
decrease from 12 feet to 10 feet or lesser.
● Results in a more closed area with less space for air circulation
● Large space enabled better cross-ventilation.
● With air conditioners being widely used these days, the need for
cross-ventilation has decreased, which has made rooms less airy.
2.Overhead trouble
● Unprofessional false ceiling contractors poorly affect installations as
well.
● Poor construction and use of substandard material often cause a major
accident..
● Additionally, it is also difficult to check for leaks and cracks in the false
ceiling, which is why it is important to contact experienced false ceiling
contractors for installation.
12. Disadvantages of False Ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
39

40. 3.Prone to natural calamities
● The false ceiling is not concrete ceilings like the traditional ones
● . They are crafted on ceiling panels, which are attached to the
main ceiling with screws and rods.
● During earthquakes, they may become unstable and even
collapse when the ground starts to shake
● . The installed fixtures on the ceiling might also loosen up and
move over time due to poor installation, which then eventually
break the false ceiling.
4.Plug in the gaps
● The hidden gaps in the false ceiling are often prone to
uninvited guests such as parasites, cockroaches, and other
fungal activity.
● If not maintained, the room may start stinging.
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
40

41. Maintenance
No special maintenance is required. For any dust accumulation it can be cleaned with broom or a smooth rug, just like other interiors
and avoid water contact.
Accessibility
Accessible ceilings consists of wood panels supported by a grid that allow you to take any panel out and put it in again as many
times as you want. This type of false ceiling is ideal for integrating accessories such as air vents, fire or safety sensors, lighting,
speakers, etc. and, while the same time, hiding other elements such as ventilation ducts, electrical or data wiring, pipes, etc.
13b. ACCESSIBILITY
13a. MAINTENANCE
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
41

42. Multiple factors are involved while calculating the cost of false ceiling per sq. ft. These include:
● Design: More complex the design of the false ceiling, the costlier it gets.
● Size: The price is low for a larger ceiling area as the materials required can be purchased at
wholesale prices in bulk.
● Quality: If you go for high-quality materials, it is pricier. But as high-quality materials are
durable, it has a higher return on investment (ROI).
● Availability: If the materials you are using are easily available in the market, transportation and
logistic costs can be cut.
● Additional cost: This includes the cost of finishes, fittings, cutting, lighting, accents etc.
14a. Cost Calculation
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
42

43. a. Price of False Ceilings- Gypsum
Gypsum ceilings are supported by 12 no. Galvanized channel or Gypsum channel or Aluminium pipe and generally comes in the
range of Rs 50 to Rs 150/ square feet.
The 3D Gypsum ceiling can cost up to Rs. 350/ square feet.
b. Price of False Ceilings- POP
They are usually available in the range of Rs. 35 to 120/ square feet
c. Price of False Ceilings- PVC
They are usually available in the range of Rs. 20 to 80/ square feet
e. Price of False Ceiling- Glass
Mirror Glass is generally used for glass thickness 5mm to 8mm. Prices may vary according to the type.
This available in the range of Rs. 350 to Rs. 600/ square feet
d. Price of False Ceilings- Wooden ceilings
Wooden ceilings are supported by Aluminium pipe or plywood (4’ x 8’, 4’ x 6’, 3’ X 7’).
The Wooden ceiling price also depends upon the thickness of the wooden board
f. Price of False Ceilings- Fibre
This available in the range of Rs.65 to Rs 450/ square feet.
14b. False ceiling Price list
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
43

44. Thickness Min Price Max Price
10 mm Rs 110/Square Feet Rs 1000/Square Feet
12 mm Rs 450/Square Feet Rs 900/Square Feet
16 mm Rs 200/Square Feet Rs 250/Square Feet
8 mm Rs 180/Square Feet Rs 180/Square Feet
14c. False ceiling Price list
Wooden
False
Ceiling
price
range
Labour
Cost
Mumbai
Labour – Rs. 30/-
Material – Rs. 90/-
Material – Rs. 160/-
Material – Rs. 80/-
Pune
Labour – Rs. 35/-
Material – Rs. 90/-
Material – Rs. 150/-
Material – Rs. 80/-
Delhi NCR
Labour – Rs. 30/-
Material – Rs. 90/-
Material – Rs. 160/-
Material – Rs. 85/-
Bengaluru
Labour – Rs. 35/-
Material – Rs. 90/-
Material – Rs. 160/-
Material – Rs. 80/-
Gypsum False Ceiling
Acrylic False Ceiling
Armstrong False Ceiling
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
Rates per Sq Ft*
Gypsum False
Ceiling
1BHK (400 to
500 sq.ft)
3BHK (850 to
1000 sq.ft)
Plain Rs. 40,000 Rs. 75,000
18″ Running Patta
– Side corner only
Rs. 60,000 Rs. 1,12,500
Two Layer Ceiling Rs. 80,000 Rs. 1,50,000
Gypsum
False
Ceiling
price
range
Approximate Values *
44

45. 15. Reference
GROUP 1 VISVESVARAYA NATIONAL INSTITUTE OF TECHNOLOGY
● https://www.gti-me.com/product/concealed-clip-in-system/
● https://civillane.com/2018/07/07/top-5-false-ceiling-brands-in-india/
● https://www.armstrongceilings.com/commercial/en/suspension-systems/ceiling-grid.html#b
bbh=%7B%22selectedItem%22%3A%7B%22name%22%3A%22browseFamily%22%2C%22ite
mIndex%22%3Anull%7D%7D
● https://theconstructor.org/building/types-false-ceilings-applications/13602/
● https://www.livspace.com/in/magazine/decor-pillar-false-ceiling
● https://www.homelane.com/false-ceiling
● https://www.archdaily.com/catalog/us/products/25153/acoustic-ceilings-heartfelt-origami-ce
iling-system-hunter-douglas-architectural-europe?utm_source=Whatsapp&utm_medium=IM&
utm_campaign=share-button
● https://buildingandinteriors.com/false-ceilings-the-ultimate-guide-to-help-select-the-best-on
e-prices-incl/
45

46. Thank You
46
