The role of material in fertilizers industries with energy savingPremBaboo4
In Fertilizers industries the material plays a very important role. Right material can save energy as well as plant life and wrong selection of material may lead to catastrophic failures and outage of plants & even loss of Human lives, Right selection of material leads to long life of plant. In urea plant very corrosive chemicals are used for urea production. The raw material of urea plant is Ammonia and Carbon Dioxide gas which makes very corrosive chemical ammonium Carbamate. For reduced corrosion passivation air is used in reactor as well as stripper according to material of selection different quaintly of air is used. Controlled and less quantity of passivation air is required for Titanium and Zirconium material and hence saving of energy because the huge amount of ammonia is waste with venting of inerts, i.e. saving of energy and environments also. Passivation oxygen given in CO2 is directly proportional to ammonia losses in MP section. This paper intended how to increase life of urea reactor liner and energy saving with low passivation air and high N/C ratio, Ammonia is the noncorrosive and ammonia to CO2 Ratio is an important parameter for process optimization occurring less losses and less explosion probability in urea reactor because it affects the amount of produced urea and corrosion to the material in the reactor. Generally we are using urea reactor liner 316L (urea grade), now adopted 2RE69 for large capacity plant (world largest) and Duplex stainless steel.
The Role of Material in Fertilizers IndustrieswithEnergy saving.pdfPremBaboo4
In Fertilizers industries the material plays a
very important role. Right material can save
energy as well as plant life and wrong
selection of material may lead to
catastrophic failures and outage of plants &
even loss of Human lives, Right selection of
material leads to long life of plant. In urea
plant very corrosive chemicals are used for
urea production. The raw material of urea
plant is Ammonia and Carbon Dioxide gas
which makes very corrosive chemical
ammonium Carbamate. For reduced
corrosion passivation air is used in reactor as
well as stripper according to material of
selection different quaintly of air is used.
Controlled and less quantity of passivation
air is required for Titanium and Zirconium
material and hence saving of energy because
the huge amount of ammonia is waste with
venting of inerts, i.e. saving of energy and
environments also. Passivation oxygen
given in CO2 is directly proportional to
ammonia losses in MP section. This paper
intended how to increase life of urea reactor
liner and energy saving with low passivation
air and high N/C ratio, Ammonia is the
noncorrosive and ammonia to CO2 Ratio is
an important parameter for process optimization occurring less losses and less
explosion probability in urea reactor because
it affects the amount of produced urea and
corrosion to the material in the reactor.
Generally we are using urea reactor liner
316L (urea grade), now adopted 2RE69 for
large capacity plant (world largest) and
Duplex stainless steel.
