41. PROJECT PROCESS
1. GOOGLE
2. LITERATURE SURVEY
3. BASE PAPERS
4. BLOCK DIAGRAM
5. PAPER READY CIRCUIT DESIGN
6. SIMULATION
7. HARDWARE IMPLEMENTATION
42.
43. ALMOST ALL REAL TIME PROJECTS ARE
EMBEDDED PROJECTS
• PROCESSOR OR CONTROLLER
• SPECIFICATIONS - no. of input pins , no. of
output pins, no. of serial communication
• SENSOR UNITS / PERIPHERALS
• PROGRAMMING
• SERIAL COMMUNICATION
• SOFTWARE BACKEND
45. CHOOSING SENSORS
TEMPERATURE – PRESSURE – ACCELEROMETER – IR SENSORS
CHOOSING THEM ACCORDING TO YOUR PROCESSOR
COST EFFECTIVE
SPEED / RANGE / RELAIABLITY /WEIGHT
46.
47. TYPICAL PROJECT BATCH
• ONE DOES ALL THE WORK
• ONE JUST DOES THE TYPING WORK
• ONE DOESN’T EVEN KNOWS WHATS
HAPPENING IN THE PROJECT
• THE LAST ONE DISSAPPEARS AND COMES
ONLY ON THE DAY OF SUBMISSION
54. INSTRUCTION SET
• ARITHMATIC
• LOGICAL
• MOVEMENT
• ROTATIONS
• SPECIAL FUNCTION and COMMANDS
55. 8051 PROGRAMS
• Basic data manipulation and movement
• Internal Modules
• Timer/Counter
• UART
• ADC
• Interrupts
• Interfacing
• LCD
• Keypad
• ………
• ……..
56. UART – Serial Communication
• TMOD
• TCON
• SCON
• SBUF
• TXD
• RXD
• ….
57. Send me an ‘A’
#include "reg_51.h"
char uart_data;
void main (void)
{
SCON = 0x50; /* uart in mode 1 (8 bit),
REN=1 */
TMOD = TMOD | 0x20 ; /* Timer 1 in mode 2 */
TH1 = 0xFD; /* 9600 Bds at 11.059MHz */
TL1 = 0xFD; /* 9600 Bds at 11.059MHz */
ES = 1; /* Enable serial
interrupt */
EA = 1; /* Enable global interrupt
*/
TR1 = 1; /* Timer 1 run */
while(1); /* endless */
}
58. void serial_IT(void) interrupt 4
{
if (RI == 1)
{ /* if reception occur */
RI = 0; /* clear reception flag for
next reception */
uart_data = SBUF; /* Read receive data */
SBUF = uart_data; /* Send back same data on
uart*/
}
else TI = 0; /* if emission occur */
/* clear emission flag for next emission*/
}
68. PROJECT PROCESS
1. GOOGLE
2. LITERATURE SURVEY
3. BASE PAPERS
4. BLOCK DIAGRAM
5. PAPER READY CIRCUIT DESIGN
6. SIMULATION
7. HARDWARE IMPLEMENTATION
69. Things to start your project ?
1.) bread board
2.) DVM
3.) Soldering iron
4.) dot board
5.) sensors , cables, components
6.) processors / controllers
73. OUR WORKSHOPS
• HANDS ON KEIL IDE & PROTEUS
• 80C51 @ 89C51 HANDS ON
• PIC MICROCNTROLLER HANDS ON
• ROBOTICS WORKSHOP
• BUSINESS ELECTRONICS WORKSHOP
• PCB DESIGNING & SOLDERING HANDS ON
• WEB DEISGNING HANDS ON
• WEB DEVELOPMENT HANDS ON
• PHOTOSHOP AND AFTER AFFECTS
