EAP-TLS
The document discusses the complexities of deploying EAP-TLS for secure authentication in networks, emphasizing the need for proper configuration of a RADIUS server, certificates, and an authorization database. It outlines the challenges faced in managing client certificates and stresses the importance of testing in real environments to ensure successful implementation. Additionally, it suggests careful vendor selection for support in the design and deployment process.
More Related Content
EAP-TLS
- 1.
- 2. EAP-TLS is easy… … for RADIUS server. At the minimum one needs only to configure RADIUS server certificate and the CA certificate for client certificate verification. … to configure improperly. Understanding how certificates, certificate revocation, root and intermediate CAs, PKI etc works requires significant effort. Designing and deploying working model requires even more. … only when one does not need to care about the client certificates, their configuration, provisioning and management.
- 3. Deploying EAP-TLS never startor settle requirements because of a product, solution or technology start with defining and designing policies (validity, expiry times, authorisation, usage …) PKI (hierarchy: CAs, intermediate CAs, certificate usage …) configuration management certificate provisioning certificate requirements (roaming, use, technology …) … but do pilot /trials simultaneously to learn and to see how things do (or do not) work or scale with real users and infrastructure
- 4. Start with simpletrial … Try self-signed CA, manually created client certificates first (or Radiator’s certificates directory) eduroam managed IdP as a service for roaming EAP-TLS tests Verify first that your underlying network and especially firewalls and their rules work when using EAP-TLS Firewalls filtering UDP fragments and especially *BSD firewalls (scrub setting) can cause problems. Federation Level RADIUS IdP/SP RADIUS Wi-Fi network (controller) Client devices
- 5. Add basic automaticcertificate validation… a separate Certificate Authority (CA) capable of providing certificate revocation lists (CRLs) or function as a Online Certificate Status Protocol (OCSP) server is needed several open source CAs/PKIs available: easypki, dogtag, ejbca … with this setup one can ensure that when certificates expire, they do not work for authentication anymore automating the certificate validity check is essential for using certificate authentication Federation Level RADIUS IdP/SP RADIUS Wi-Fi network (controller) Certificate Authority (CA) OCSP reqs. CRLs, delta- CRLs Certificates
- 6. Add connection toauthorisation database… Authorisation database can be Active Directory, LDAP, SQL with additional information about the client certificate. CA, CRLs and OCSP can be sometimes replaced by client certificate check against the authorisation database. Authorisation database can contain additional information such as VLAN assignments, account active/locked etc. How flexible/complex/simple the authorisation checks can be depends on the IdP RADIUS product. Federation Level RADIUS IdP RADIUS Wi-Fi network (controller) Certificate Authority (CA) OCSP reqs. CRLs, delta- CRLs Certificates LDAP, SQL, etc. IdP Authorisation Database (AD, LDAP, SQL)
- 7. Deploy certificate managementservice… Properly distributing and configuring certificates in the end user devices is difficult. For managed devices (Windows domain/ Intune) or for Apple devices it is easier, but Android/Linux devices are hard. Currently there seems to be no better approach than to have an app in the device talking to a service. One commercial option is SecureW2. Certificate signing requests created in the actual device are even harder. IdP RADIUS Wi-Fi network (controller) Certificate Management Service OCSP reqs. CRLs, delta- CRLs Certificates LDAP, SQL, etc. IdP Authorisation Database (AD, LDAP, SQL) Certificate (signing) requests Certificate request authorisation requests
- 8. … and youare done… sort of … maybe … If everything presented before works for you, it’s brilliant … and you are brilliant. Unfortunately any organisation who does not have the first step right will break your organisation’s users’ roaming. Sometimes even the packet filters / firewalls in front of federation level RADIUS servers need configuration adjustments. Deploying certificate based authentication requires design, competence and support from infrastructure and service vendors — choose wisely, select vendors and solutions, for which you can get support for design, deployment and production.
- 9. Questions? Find this presentationand more from: https://blog.radiatorsoftware.com/ https://slideshare.net/radiatorsoftware/ https://slideshare.net/khuhtanen/ https://twitter.com/OSCRadiator Extended presentation coming to JISC govroam stakeholders’ meeting (15th of October 2019 in Manchester, United Kingdom) and to the Internet locations above.
