The document summarizes the design of the Spirit of Randy human powered vehicle created by the Cal Poly Pomona Human Powered Vehicle Team. Key points:
- The team's goal was to establish an organization to design and build HPVs for annual competition.
- Their design, the Spirit of Randy, is an unfaired front wheel drive recumbent bicycle intended for both competition and everyday use.
- Ergonomic testing was conducted to optimize rider position. The frame design was inspired by the Vendetta HPV but adapted to improve maneuverability.
- Components include a 35 degree steering angle for a shorter wheelbase, 4130 steel tubing, and a wood core seat for comfort and
