Compressed air is a key utility used across many industrial sectors. A typical compressed air system contains multiple compressors, dryers, and filters to provide clean, dry air for applications like pneumatic controls and critical valves. Compressed air compressors increase air pressure and common types include reciprocating and rotary compressors. Instrument air requires very low moisture content to prevent corrosion and malfunctions in pneumatic instrumentation.
Pranav Vikas (India) Pvt. Ltd. is a heat exchanger manufacturer established in 1982 in Faridabad, India. Over the past 30 years, it has become one of the largest heat exchanger manufacturers in India with a strong R&D team and facilities for design and manufacturing. The company aims to be a world-leading heat exchanger manufacturer and benchmark in technology, design, manufacturing, and quality. Pranav Vikas produces aluminum heat exchangers for various applications and has received ISO and quality certifications. It also operates in other industries such as automotive air conditioning.
Delivery volume is the quantity of air that a compressor delivers to a system.
It is specified in terms of air at normal atmospheric conditions.
There are two types of delivery volumes
Ex:
For a reciprocating compressor, the theoretical delivery volume is the product of volume of air swept in one revolution of its rotating element and the number of revolutions per unit time.
Effective delivery volume
Depends on the type of compressor.
To pneumatic personnel, only the effective delivery volume is of interest as this air volume is available for driving and controlling pneumatic equipment.
When air is compressed, work is done, and a part of this work
appears as heat in the compressed air.
The heat produced must be removed by cooling the air. Good cooling extends the life of the compressor.
Cooling methods
Selection of a suitable cooling system depends on the amount of heat produced.
Cooling fins on smaller air-cooled compressors permit the heat to be
removed by radiation.
A large compressor is usually equipped with an additional fan to take away the heat. In the case of a compressors with a drive power in excess of 30 kw are equipped with a water circulation cooling system.
To match the delivery volume of the compressor with the fluctuating air consumption and as a safety measure, it is necessary to regulate the pressure developed by the compressor.
Various methods of regulation are employed for this purpose.
Start/Stop (On-off Regulation)
Pressure (switching) limits Pmax and Pmin that can be set on a regulator. The drive motor is switched off on reaching a preset maximum pressure, Pmax The motor is switched on again when the pressure has dropped to a preset minimum pressure, Pmin.
Start/Stop (On-off Regulation)
It keeps the motor running continuously, but unloads compressor when the discharge pressure is adequate.
Unloaded rotary screw compressors typically consume 15-35% of their full load power demand, while producing no useful compressed air output.
Optional unload timers are available that will save energy by automatically turning off the compressor and placing it in standby if the unit runs unloaded for a period of time (usually 15 minutes).
Regulation methods
Modulating Control
This mode of control varies the compressor output to meet flow requirements by adjusting the inlet valve, resulting in air restrictions to the compressor.
Variable Displacement
Some lubricated rotary screw compressors vary their output capacity using special capacity control valves, also called spiral, turn or poppet valves.
With a variable displacement control scheme, the output pressure and compressor power consumption can be closely controlled without having to start/stop or load/unload the compressor.
Regulation methods
Variable Speed Drive (VSD)
This control method varies the speed of the compressor to respond to changes in air demand.
Both lubricated and oil free screw compressors can be purchased equipped with variable speed drive controls that c
