Design, manufacture and revamp, upgrade your rolling mill plant according to your tech requirements. Hani is the one-stop supplier able to design, manufacture, install and commission your hot rolling mill plant from A to Z.
Rishbin is an established manufacturer of many types of high frequency welded tube mill with tube diameter from 8 mm to 610mm, square & rectangular tube mill for making ERW/API and related applications rating maximum up to 120m/min which is based on German and Taiwan Design and technology. Our tube mill advantages are the custom design, horizontal accumulators, digital length control, competitive tooling, very competitive pricing, good delivery time, installation and start-up assistance, very good service & training and very good warranty.
