Coining process by satyam diwedi
•Download as PPTX, PDF•
0 likes•43 views
Coining is a cold working process that uses high pressure to plastically deform a workpiece between a punch and die to conform to their shapes. The metal flows under compressive forces to take on the impressions of the completely closed dies. Coining provides a finer, more detailed surface finish than other metal forming processes and work hardens the surface. It is commonly used for minting coins and medallions, making jewelry, badges, buttons, springs, and complex electronic and precision parts that require close tolerances and smooth polished surfaces.
Report
Share
Report
Share
