Capabilities of Arduino

  Sudar Muthu (@sudarmuthu)
    http://sudarmuthu.com
    http://hardwarefun.com
    http://github.com/sudar
Photo credit: Arduino team
Types of Arduino
•   Leonardo, Uno (and older ones)
•   Due (32-bit)
•   Mega (more input pins)
•   Arduino BT (includes Bluetooth)
•   LilyPad (wearable)
•   Arduino Pro
•   ADK (supports Android ADK)
•   Clones (around 300+)
Specs (Uno, Leonardo)
Type                         Value
Microcontroller              ATmega328
Operating Voltage            5v
Digital I/O Pins             14 (of which 6 provide PWM output)
Analog Input Pins            6
Flash Memory                 32 KB (ATmega328) of which 0.5 KB used
                             by bootloader
SRAM                         2 KB (ATmega328)
EEPROM                       1 KB (ATmega328)
Clock Speed                  16 MHz
Specs (Due)
Type                     Value
Microcontroller          AT91SAM3X8E
Operating Voltage        3.3v
Digital I/O Pins         54 (of which 12 provide PWM output)
Analog Input Pins        12
Flash Memory             512 KB
SRAM                     96 KB
Clock Speed              84 MHz
Pin Mappings
•   Serial: 0 (RX) and 1 (TX)
•   External Interrupts: 2 and 3
•   PWM: 3, 5, 6, 9, 10, and 11
•   SPI: 10 (SS), 11 (MOSI), 12 (MISO), 13 (SCK)
•   TWI: A4 or SDA pin and A5 or SCL pin
•   AREF and Reset
External Interface
•   UART TTL Serial communication
•   I2C (TWI)
•   SPI communication
•   ICSP (In-Circuit Serial Programming)
•   Bootloader uses STK500 protocol
•   USB (Only Due)
Interfacing with external boards
• Using I2C bus
• Serial communication
• SPI
• USB Micro port (other board should act as
  host)
• Direct USB support (Only in Due)
Interfacing with external boards



If you use external shields, then
       anything is possible
Things which I have tried
•   Connecting to mobile Android phones using
     –   Bluetooth
     –   Wired and wireless
     –   Audio Jacket
     –   NFC
     –   ADK
•   Connected all sorts of display devices including VGA devices like projectors
•   Connected external USB devices like keyboard, mouse and even USB Missile
    launchers
• Connected ez430 chronos watch
• Connected IR devices like TV Remotes etc
• Connected bluetooth devices like WiiRemote
• Created small bots which can be controlled by either a WiiRemote or Android
    phones.
• Controlled GSM module using AT commands
• Controlled external devices using Relay
http://sudarmuthu.com/arduino and http://hardwarefun.com
Thanks
http://github.com/sudar
http://hardwarefun.com
http://sudarmuthu.com
