Why look any further ?
We are the experts in electronic

contact@analogpowerlab.com
www.analogpowerlab.com 3
Company Profile
Validation of complex electronic products,
in analog & digital domains
Innovative test solutions
&
automated benchmark
Accelerated lifetime testing
&
thermal analysis
Electronic development
Firmware & graphic interface
development for computer &
smartphone applications

Experience
- We have more than 20 years of experience
in electronic validation.
- strong experience in Wireless &
Automotive IC Validation (OEM tests -
Testing of automotive electronic components
according to specific norms such as ISO
16750-1).
- Valuable experience in Automated
Benchmark design for System validation
Our Experts Profile
We are certified
ISO 9001
Expertise in Power Management and
Audio devices are recognized by
microelectronic companies such as :
Texas Instruments, STMicroelectronics and
NXP
Activities domains covers by our company
is various:
Audio & Video, Defense, Aircraft, Space,
Automotive, Medical, Power Management,
Renewal Energies.

Impossible d’afficher l’image.
Our Services
Electronic validation
Test systems development
Analog and digital IP validation
Full system validation
Stress tests
Electronic development
PCB design
Repair
Software development
Automation
Graphical User Interface
Apps
Firmware
Bus (I2C, SPI, UART, JTAG, GPIB, CAN ....)
Thermal analysis
Services performed in our laboratory and/or on-site :
Audio analysis

Impossible d’afficher l’image.
Electronic Validation
Our Entire Validation ICs Projects Step by Step :

310 tests done in 8 days
70% tests automatized
216Parametric tests:
24 Parameters
3 Samples
3 Temperatures
4 Stress tests:
Full static load 24h
Transient line with full load 24h
Vbattery max transient load 24h
Vbattery max full static load 24h
90Functional tests:
1 Samples
3 Temperatures
Validation Example
Step down converter validation :

Evaluation of thermal cartography of an IC,
a PCB or full systems by using an HD thermal
camera (384x288 pixels resolution in real time,
range -40 to 300°C, +/-1.5K accuracy).
IC thermal dissipation System thermal dissipation
Thermal Analysis

Audio Analysis
Hi-Fi Audio system tests using Audio Precision SYS2227 :
Analog Power Lab is expert in analysis of :
Power Amplifier.
Converters.
Amplifier Class D.
Loudspeakers.
Microphones.
Codecs.
Level Audio System.
Digital Interfaces.
Two analog channel input/output THD+N<-115dB,
analog analyser and generator, analyser and
generator DSP plus 192k numeric input/output.

Software Development
Graphical User Interface
• Graphical User Interfaces are developed in programming languages by our team.
• Graphical User Interfaces are fully compatible with automation programs and can
be integrated into.
Firmware
• Our team develops all types of firmware, compatible with our graphical interfaces.
Automation
• All kind of equipment are controlled and automated by programming languages.
• Use of standard / customized racks, remotely controlled.
• Possibility of set-up at customers’ locations.

Electronic Development
Electronic repairs :
Defects analysis of all kinds of board.
Defects repairs.
Quick delivery.
Cost reduction compared to the whole board
replacement.
Fight against planned obsolescence of electronic
systems.
PCB expertise :
Schematic, Layout.
Outputs/inputs analysis of integrated circuits
in order to optimize the number of PCB classes.
PCB up to 16 layers.
Board validation.

Laboratory
Power supplies 2x[20V -5A] 4x[50V-2A] 2x[20V-2A].
Bi-polar power supply KEPCO BOP [50V-4A].
Electronic load KTH 2425 [35V-3A] / Maynuo 150V.
Battery simulator KTH 2306 [15V 5A].
DC Current probe 50A BW 100MHz.
3 Arbitrary Waveform Generator 80 MHz.
Vector signal analyzer DC to 2,65 GHz.
Logic analyzer – 136 channels 512 Mb rec length.
2 PXI chassis (embedded with power matrix
relays, AWG, DAQ).
Oscilloscopes :
- A54642 mixed-signal 500 MHz 2w analog/16 dig
- MSO3054 mixed-signal 500 MHz 4w analog/16 dig
- LT344L 500 MHz 4w analog
Audio analyzer SYS2722 - 2 channels THD+N<-115dB.
Thermal chamber -40to180°C 106L (550x350x550
mm).
Data Timing Generator 5334 - 96 channels 3.35 Gb/s.
Thermal camera resolution 384x288, range -40 to
300°C.
Soldering station (BGA/QFN/TQFP).
The electronic validation requires special measurement and test instruments.
Analog Power Lab owns a fully equipped laboratory.
Main equipment :

Pierre Cantagrel
CEO
Expert in hardware development
& validation
Our Team
Jeremy Magade
Technician
Validation expert
Jerome Michelot
CEO
Expert in automation
Software development
Strong team spirit raises the company’s performance.
Our open-minded, young, however, well experienced
team is focused on meeting our customer’s needs.
Our trumps are flexibility, reactivity, & cost-
competitiveness.
Our goal is to establish and maintain strong & close
B2B relations with our interlocutors.
We provide our clients with ISO certified services !
More than 20 years of experience :

Our Added Value
Key Takeaways :
We offers functional validation in real system applications.
Self-sufficient team requiring very small internal Design support.
Automation solutions minimize the time allocated to the validation : 6000 tests during 3 months.
Reduce the cost due to generic stored sequences : 50% of test cases are re-usable.
96 % of bugs found before first sample delivery to final customers owing to functional and stress test.
Reliable prototypes = R&D cost reduction
Automation = gain of time

E.F.I.
They Trust Us

www.analogpowerlab.com
Arep Center, 1 Traverse des Brucs, 06560 Sophia Antipolis - Valbonne, France.
Phone : +33 (0)9 84 50 12 20
Fax : +33 (0)9 89 50 12 20
Analog Power Lab S.A.S.
Thank you for your attention !
