paper iundustry

2. (Paper industry)
What is paper:
It is the material
manufactured in thin sheets from the pulp of
wood or other fibrous substances, used for
writing, drawing, or printing on, or as
wrapping material.
Fridayday, November 29, 2013 2

3. (Paper industry)
 The word paper is derived from
the name of a reedy plant papyrus,
which grew mostly along the River
Nile in Egypt around 3000B.C.
 The invention of modern paper is
credit to Ts’ai Lun of china
Tsai-Lun of china
Fridayday, November 29, 2013 3

4. Paper is formed by pulp.
Pulp:
A mixture of cellulose
material, such as wood, paper, and
rags, ground up and moistened to
make paper.
(Paper industry)
Fridayday, November 29, 2013 4

5. (Paper industry)
 Nonwoody raw material:
Wheat straw Rice straw
Bagasse Bamboo Cotton stalk
Cotton linter Grasses
 Woody raw material:
Poplar (hard wood)
Eucalyptus (hard wood)
Douglas fir (soft wood)
Fridayday, November 29, 2013 5

6. (Paper industry)
Fridayday, November 29, 2013 6
Kraft process (Alkaline)
Sulphite (Acidic)
Neutral sulphite semi-chemical process (NSSC)
 In Pakistan NSSC process is mostly used for pulping.

7. • Cutting of Raw
material
• Drying Section
Wet cleaning
• Material Unit
• Blow Tank
Screening
• Centrifugal
Screening
• Washing
Thicking
• Bleaching
• Digesting Unit
Ready for
paper making
Fridayday, November 29, 2013 (Paper industry) 7

8.  This process utilizes sodium sulphite cooking liquor which is
buffered with sodium carbonate or NaOH to neutralize the organic
acid liberated from the raw materials.
I. Cutting of raw material:
The non-woody raw materials
come in the precut state and cut into
small chips before the further
processing.
Fridayday, November 29, 2013 (Paper industry) 8

9.  Dry & Wet Cleaning:
o Wheat straw is collected from the storage and is then sent for the
dry cleaning. For this purpose air is blown into the raw material.
o Dry wheat straw is then subjected to wet cleaning, which removes
the remaining dust particles.
 Screening:
o In most paper processes some type of
screening operation is required to remove
oversized and unwanted particles. Vibratory,
gravity and centrifugal separators used for
this process.
Fridayday, November 29, 2013 (Paper industry) 9

10.  Digestion:
o As the raw material enters into the digester,
steam is introduced at the bottom and liquor
containing sodium sulphite is injected .
o It is revolved at 2.5 R.P.M and temperature
of 160-180oC is maintained
 Blow tank:
o The cooked material from the digester
is blown into a blow tank and then pumped to
centrifugal screen for the separation of cooked
from uncooked materials.
Fridayday, November 29, 2013 (Paper industry) 10

11.  Bleaching:
 In Pakistan, bleaching is done with chlorine or hydrogen peroxide.
After washing, the unbleached pulp is sent to the chlorinator where
chlorine at 4-5 bar pressure is injected.
 After chlorination pulp is washed with hot water at 60o C and then sent
to the storage tank. After drying the pulp is ready for manufacturing of
paper.
Fridayday, November 29, 2013 (Paper industry) 11

12.  Paper making machine
 A basic fourdrinier type machine is used for paper making and a brief
description of its major components is given below:
Flow spreader Head box Fourdrinier
Press suction Dryer section Calendar stock
Reel
Fridayday, November 29, 2013 (Paper industry) 12

13.  Recycling of paper:
o Some industry sources estimate that an
ordinary sheet of paper made from cellulose
fibers derived from wood can survive only
four to six trips through the recycling process.
 The paper is chopped and then subjected to a mixture of chemicals
to remove impurities and de-inked it chemicals.
 An ordinary newspaper can be recycled five (5) times.
Fridayday, November 29, 2013 (Paper industry) 13

14. Deforestation
Wood is used widely in the formation of
paper which cause deforestation.
Air pollution
Nitrogen dioxide, sulfur dioxide and carbon
dioxide are emitted during paper manufacturing.
Water pollution
From treated water of paper industry organic
matter dissolved in fresh water.
Fridayday, November 29, 2013 (Paper industry) 14

15.  According to the International organization for Standardization
(I.S.O) some recommended sizes are:
 Legal
 Letter
 Tabloid
 A0
 A1
 A2
 A3
 A4
 B1
Fridayday, November 29, 2013 (Paper industry) 15

16. S.N. Particular Time of
Information
01 Country Pakistan
02 Population (Million) 180.0 2012
03 Total Pulp/Paper/Paperboard
Production
1.079 2010
03.1 Writing & printing 0.258 2010
03.2 Others 0.821 2010
04 Import 0.409 2010
05 Export 0.008 2010
06 Net Consumption 1.480 2010
07 Per Capita Consumption
(Kg./year/person)
8.22 2010
08 No. of Pulp/Paper Mills App. 10 2010
Fridayday, November 29, 2013 (Paper industry) 16
 Usage of paper (million matric tone) in Pakistan is given in the following table:

17. Some major paper mills (Private & public sector)
names are given below:
 Bulleh Shah Paper Mill,
 Misk paper mills
 Empire Paper & Board Mills
 Fiaz Paper and Board mills
 Ali Murtaza Paper Mills
 Usama Paper mills
 Al Aziz Paper mills
Fridayday, November 29, 2013 (Paper industry) 17

18. COMPOSER:
REG NO:
Subject:
• ADNAN ASLAM
• Muhammad Majid
• Muhammad Maaz
Akhtar
• (13-ME-008)
• (13-ME-109)
• (13-ME-108)
• CHEMISTRY
