An Introduction to the Emulex Network Xceleration Solution – FastStack™ Sniffer10

Emulex Technology Webcast Series

Emulex Confidential - © 2012 Emulex Corporation
Emulex© Corporation 2012 1

Logistics

Attendees will be placed on mute during the presentation

Please use the WebEx’s Q&A feature to submit questions at any time

For a copy of this presentation please send an e-mail to:
allen.ordoubadian@emulex.com

Please visit emulex.com/webcasts for list of our upcoming webcasts


TM
FastStack Sniffer10G

For superior network analytics & cyber-security


Agenda

Background
High Performance Networking
What Matters in Lawful Intercept & Network Analytics
FastStack Sniffer10G Overview
Conclusion and Q/A session


Emulex Background

Emulex solutions are used and offered by the industry’s leading server
and storage OEMs
– An ever-expanding interoperability ecosystem
– High scalability with support for small and large environments
Industry leader in the Fibre Channel Storage market
– The performance expected of high demand environments
– Tools to maximize the efficiency of your resources
– Reliability that is second to none
The leader in converged networking solutions, providing enterprise-class
connectivity for servers, networks and storage
– Deployment flexibility that minimizes management expenses
– High scalability with support for small and large environments
– #1 in 10GbE Port Shipments
– Requests for higher performance solutions for specific vertical markets


Myricom Background

Leading provider of adaptable Ethernet Solutions for vertical markets
requiring extreme performance
Pioneer in HPC – Interconnect technology since 1994
Unique, adaptable hardware and software architecture
One of the first to deliver general-purpose 10GbE adapters
– Processor-based architecture, highly programmable
– Allows for firmware and API development for high performance applications
– Solutions offer performance, time-to-market customer advantages
Low latency networking – low CPU overhead solutions


High Performance Networks (HPN)

Challenges of High Performance Networks
– Extremely low latency
– Massive packet rate processing capability
– Capability to stream large numbers of data sets

The Solution:
– Emulex OneConnect® Network Xceleration (NX) solutions
• OneConnect OCe12000-DX family of high performance10GbE NICs
– Windows, Linux, Apple OSX support
• FastStack family of network accelerators
– FastStackTM DBLTM
– FastStackTM Sniffer10GTM
– FastStackTM VideoPumpTM


FastStack™ Network Acceleration
FastStack DBL
 Superior latency performance: 2.9µs for UDP, 3.8µs for TCP
 Predictable performance
 Markets: Financial High Frequency Trading (HFT)

FastStack Sniffer10G
 High throughput, lossless packet capture and analysis
 Packet capture and wire speed packet injection - 14.88 Mpps
 Markets: Analytics for network security and surveillance, financial,
measurement and packet generation, DDoS defense appliances

FastStack VideoPump
 Accelerate and improve data streaming
 Line-rate streams with low CPU usage via packet pacing
 Scalable: Support in excess of 25,000 streams at 3Mb/s
 Markets: Video content delivery, IPTV, Telcos and Network providers


What Matters in Lawful Intercept & Network Analytics

High Performance
• Line rate throughput (up to 14.88 Mpps)
• Process more “rules” through your application
• Capture - regardless of packet size
• Injection – for network infrastructure monitoring and probing

Flexibility and efficiency
• Compatible with industry standard-interface – libpcap
• Functions on an industry-standard 10Gb-E PCIe adapter
• Easily programmable
• Support Windows and Linux

Cost Effective
• Broader deployment
• Create more robust/secure environments


FastStack Sniffer10G Overview
Lossless packet capture/injection enabling superior network analytics

High Performance Flexibility Cost Effective

- Kernel by-pass architecture - Enables Deep Packet - No specialized capture
Inspection (DPI) hardware (ie: Appliance)
- Delivers line rate, loss less
packet capture and injection - Multi-core awareness
- In “Sniffer Mode”, packet-
without introducing latency
- Flexibility of how data can rate sensitive firmware
- Provides lossless packet be analyzed runs on MIPS-like
capture regardless of packet processor on the adapter
size - Supports packet capture
and injection at
14.88Mpps (Million - Leverages industry
packets per second) standard 10GbE


Sniffer10G Architecture

 Kernel By-pass
 No context switching
 Zero copy


Maximum Receive Packet Rate (Mpps)

SNF API:
–14.88Mpps, line rate
–Lossless packet capture
–Documentation and support for SNF API
customization
SNF libpcap:
–14.88Mpps, line rate SNF libpcap
–Lossless packet capture
–Sniffer10G links/hooks for libpcap
Through OS Kernel: Through OS
– Less than 4Mpps
– In-kernel packet capture
0.0 5.0 10.0 15.0
– Application does not support SNF Mpps
API or libpcap


Sniffer10G – Technology Application

Network Surveillance & Intrusion Detection &
Monitoring Protection

 Complete network visibility  Lossless packet capture
 100% packet capture  No missed threats
 More cost effective vs. FPGA  Increased network availability
Value Prop adapters: 10X ASP
 More energy efficient vs. FPGA
adapters: 2-3X power

 Government agencies  Security appliance
 TELCO  Large commercial customers
Target Markets  Appliance vendors


Sniffer10G Ecosystem

SURICATA


Resources on Emulex.com

Product pages
– Product landing pages
Resources
– Datasheets
– FastStack Sniffer10G solution
– Competitive assessment


FastStack Sniffer10G – Summary

Key enablers for:
– Network surveillance & monitoring
– Intrusion detection & protection
– Network performance analysis

Provides:
– Streamlined integration
– Line rate lossless packet capture and injection
– Leverages 10GbE network infrastructure
– Cost effective deployment of robust network monitoring


FastStack™ Sniffer10G™ Products and Pricing

Emulex Part Number Description MSRP
Dual Port 10GbE

OCe12102-DX Emulex OCe12102-DM Dual-Port 10GbE Adapter $795

OCe12102-DX-SNF2 Emulex OCe12102-DM Dual-Port 10GbE Adapter bundled $1,090
with FastStack™ Sniffer10G™ Software
Single Port 10GbE

OCe12101-DX Emulex OCe12101-DM Single-Port 10GbE Adapter $395

OCe12101-DX-SNF2 Emulex OCe12101-DM Single-Port 10GbE Adapter $690
bundled with FastStack™ Sniffer10G™ Software
Software Only

FastStack™ SNF2-License FastStack™ Sniffer10G™ Software License $295

OneConnect Transceivers
OneConnect dual channel optical transceivers (Short
OCe10100-OPT $420
Reach Optical) (2/pkg)


Putting It All Together
One Company

Storage Solutions Network Solutions High Performance
Network Solutions

9th Generation Fibre Channel 3rd Generation CNA Optimized to meet the
Technology Technology requirements of vertical
Over 12 million adapter ports #1 in 10GbE port shipments markets:
installed world wide Efficient power design Low latency
Bullet-proof driver stack Optimized for virtual servers Lossless packet capture
Backward compatibility – Universal Multi-Channel, Video/content delivery
Rock-solid reliability and SRIOV Versatile and scalable
Superior management Protocol offloads – TCP, One adapter, multi-
TOE, iSCSI, FCoE applications
capabilities


Thank You for Participating

Click http://www.emulex.com/company/events/webcasts.html to:
– View this webcast
– View past webcasts
– Register for upcoming webcasts
