1. Appropriate Fit
Using Today’s
Technologies
to
Overcome Common
Building Problems
www.CBS-Homes.com

2. Current Conditions
• Labor intensive systems
– High cost skill trades, shortage of trained workers, poor workmanship,
inadequate supervision, inconsistent quality, energy inefficient, unmet
current needs, growing housing deficits - worldwide
• Building methods unchanged
– Escalating environmental damage, severe raw material cost cycles,
intermittent shortages, recurring disaster damage – resistance to change
• Constant pressure to build fast and cheap
– Overlooks innovation, relies on cheapest materials
– Little industry effort to improve construction methods
– No concern for long term costs of building ownership
Traditional Complacency Maintains status quo
“I only do what I know” mentality
www.CBS-Homes.com

3. Implication - “No-changes in Sight”
• Labor Intensive – Old Methods – Low Cost Materials
– Means
• No immediate universal fix of deficits
– Implications
• No evolving large scale solution “We have always done it this
way”
– Consequences
• A continuing series of band aid solutions rising deficits & no
solutions
– Until the CBS Egis® Home
• Automated Assembly with Construction Optimized Composites
www.CBS-Homes.com

4. High Speed - High Quality - Buildings
Egis®-Systems fight disasters and overcome deficits
www.CBS-Homes.com

5. A Simple Solution from CBS
• Replace traditional building materials with
– Disaster resistant composites
• Replace old building methods with
– Factory panelized buildings
• Use automotive assembly line production methods
– For rapid production
• Erect protective building shells for builders to finish
– Existing workers finish & deliver buildings
– No change in their tools, materials, or methods
– No retraining
www.CBS-Homes.com

6. Purpose
• Establish Manufacturing Base
– Generate jobs, income, & taxes
• Set up Construction Technology Centers
– Local population rebuilds country
– With rapid assembly & erection
– Trained on production line
• Overall strategy
– Adapt the products and methods to exactly fit needs
– Use local architects and engineers to adapt the system
for local preferences

7. Sustainability in Disasters
CBS Composites solve these problems
www.CBS-Homes.com

8. CBS Stewardship Solution
Protect against losing natural resources
1 CBS assembly plant saves 15,000 acres (6,071 ha) of trees each year
3 CBS plants save 70 square miles (181 sq km) of trees each year
Where do we get our oxygen now?
Where are we going to get it later?
www.CBS-Homes.com

9. One Solution to Major Problems
• Hurricanes & Tornados Tons
• Earthquakes 45 41
• Insurance
40
• Termites
• Water 35
• Mold 30
• Fire 25
One Solution to Global Waste 20 17
1 ton of composite replaces* 15
17 tons of wood* (including waste)
10
41 tons of concrete block*
(mortar, steel, tie beams) 5 1
Environmentally friendly to the world 0
* In a 2,000 sq ft (186 sq m)
disaster resistant home
www.CBS-Homes.com

10. Any Building can be Panelized
Each Panel is Quick to Assemble, Simple to Automate,
Low cost to Transport, Easy to Erect, and Traditional to Finish
www.CBS-Homes.com

11. Years in Research & Development
• The Process
– Construction Optimized Pultruded Composite
• The Products
– 38 Patents Issued
– 3 Registered Trademarks
– Domestic & International Patents Pending
• The Methods
– Unique assembly line
– Modular jigs
www.CBS-Homes.com

12. Semi-complete Delivered and Erected
Foundation made by others,
Interiors and Exteriors finished by others
Any design, size, or style by local architects & engineers
www.CBS-Homes.com

13. Superior Longevity
Structure Now 300 +
Years
The Structural Frame is the most important part of every building
www.CBS-Homes.com

14. Time to
Re-think
Automate
&
Panelize
Assemble Houses
The same way that
Cars are assembled

15. Automotive Progress
100
Years
1910
To
2010
Spectacular Progress !
www.CBS-Homes.com

16. Building Progress
400
Years
1600 1610
1941
to
2010
1913
No Significant Progress ! 2005
www.CBS-Homes.com

17. Composites are here and growing
Ladders Bridges
Seawalls Industrial Parts
www.CBS-Homes.com

18. Multiple Applications Rebar
Seawalls
Car Bodies
Now Composite Framing
Railing
Bridges
Ladders
www.CBS-Homes.com

19. Composites
have been
Optimized
for
Construction
Light & Strong
Environmentally Resistant
Assembles like Lego blocks
www.CBS-Homes.com

20. CBS Egis® - Studs
Stronger than Steel :: Lighter than wood :: Low cost to ship
www.CBS-Homes.com

21. CBS Egis®-walls
Stick
First of Built
2 floors
each
45m x 9m
5 Man
Crew
1 Day
www.CBS-Homes.com

22. CBS Egis® - Active Panel Roof
Low Cost
House Cooling
&
Alternative
Energy
Production
www.CBS-Homes.com

23. Optimum Resistance
Egis®-Wall
Maximum Engineered Resistance to
Earthquakes and Hurricanes
www.CBS-Homes.com

24. Use in Single & Multi Family Homes
• Replace
– Exterior block walls
– Infill walls
• Replace
– Aluminum, steel,
wood, & plastic
– With composite railing
– Decks, & Lanais

25. CBS Trains
&
Oversees
until
Self-sufficiency
is
Achieved
www.CBS-Homes.com

26. Community’s
Builder Academy
Trains & Assembles
Successful Housing Projects
CBS Construction Technology Centers™
are opportunities to instill pride and self-sufficiency
www.CBS-Homes.com

27. Panel Plants are Profitable
CBS Profit Comparison
$10,000
$8,000
Price
$6,000
Cost
$4,000
Profit
$2,000
$0
100 Sticks Kits Panels Modules
Sales Method
Profitability leads to business growth, expansion,
& growing corporate and private taxable incomes
www.CBS-Homes.com

28. Govern a Prosperous Economy
Use Composite Building Structures
to Overcome Deficits
www.CBS-Homes.com
