International Journal of Engineering Research and Applications (IJERA) is an open access online peer reviewed international journal that publishes research and review articles in the fields of Computer Science, Neural Networks, Electrical Engineering, Software Engineering, Information Technology, Mechanical Engineering, Chemical Engineering, Plastic Engineering, Food Technology, Textile Engineering, Nano Technology & science, Power Electronics, Electronics & Communication Engineering, Computational mathematics, Image processing, Civil Engineering, Structural Engineering, Environmental Engineering, VLSI Testing & Low Power VLSI Design etc.
This paper presents combinations of level shifted pulse-width modulation algorithm with conventional discontinuous pulse-width modulation methods for cascaded multilevel inverters. In the proposed DPWM a zero sequence signal is injected in sinusoidal reference signal to generate various modulators with easier implementation. The analysis four various control strategies namely Common Carrier (CC), Inverted Carrier (IC), Phase Shifted (PS) and Inverted Phase Shift (IPS) for cascaded multilevel inverter fed induction motor drive has been illustrated. To validate the proposed work experimental tests has been carried out using dSPACE controller. Experimental study proves that using proposed algorithms reduction in common-mode voltage with fewer harmonics along with reduced switching loss for a cascaded multilevel inverter fed motor drive has been achieved.
Harmonic Minimization In Multilevel Inverters By Using PSOIDES Editor
Harmonic Elimination in a multilevel inverters is
an optimization problem which is solved by applying particle
swarm optimization (PSO) technique. The derived equation
for the computation of total harmonic distortion (THD) of the
output voltage of the multilevel inverter is used as the objective
function in PSO algorithm. The objective function used is to
reduce the THD of the multilevel inverter and obtain the
corresponding switching angles with the elimination of
possible lower order harmonics. In this paper a pseudo code
based algorithm is proposed to deal with inequality constraints
which will helps in accelerating the optimization process. The
proposed method is applied for seven level cascade inverter to
eliminate the 5th and 7th order harmonics to reduce the total
harmonic distortion .This proposed PSO algorithm is effective
in reducing the total harmonic distortion corresponding the
range of modulation index. The simulation results shows that
the proposed PSO method is indeed capable of obtaining
higher quality of solutions to eliminate 5th and 7th order
harmonics and to reduce the total harmonic distortion of 7-
level cascade inverter
