1. A. Monitoring Internet Endpoints and Bandwidth Consumption
1. NetFlow/Slow: NetFlow and Slow are protocols used for monitoring network traffic. Network
devices like routers and switches can be configured to export flow data to a collector. This data
includes information such as source and destination IP addresses, ports, and the volume of data
transferred. By analyzing this data, we can gain insights into which clients are communicating
with which servers and the amount of bandwidth they are using.
2. Packet Sniffers: Packet sniffers like Wireshark capture and analyze individual network
packets. They provide a detailed view of network traffic, including the actual data payload.
While this approach is thorough, it can be resource-intensive, and storing all packets may require
significant storage capacity.
3. Proxy Servers: Deploying a proxy server can help monitor internet usage by clients. Proxy
servers act as intermediaries between clients and servers, logging all requests and responses. This
provides detailed logs of web traffic, including URLs visited, data transferred, and user activity.
4. Intrusion Detection/Prevention Systems (IDS/IPS): IDS/PS systems are designed to monitor
network traffic for suspicious or unauthorized activity. They use predefined rules or anomaly
detection algorithms to identify potentially malicious behavior. When such behavior is detected,
these systems generate logs and alerts for further investigation.
If we lack the resources to capture and store all network packets, we can consider using sampling
techniques to capture a representative subset of traffic or filtering criteria to focus on specific
types of traffic. For instance, you might prioritize capturing and storing packets for traffic to and
from critical servers or for specific applications critical to our organization's operations.
B. Identifying the Local Host in a Data Exfiltration Event
Identifying the local host involved in data exfiltration from external server logs can be done as
follows:
1. Identify the External IP Address: Look in the web server logs to find the external IP address
associated with the data exfiltration.
This IP address typically corresponds to our company's router or firewall through which the data
left our network.
2. Analyze High-Level TCP Port Number: Examine the high-level TCP port number in the logs.
Some services or applications use specific ports. This can help us narrow down the scope of
potential local hosts.
3. Check Firewall or Network Device Logs: Access logs on our company's router/firewall or
other network devices responsible for outgoing traffic. Look for outbound connections
originating from the internal IP address linked to the external IP address identified in the web
server logs.

2. 4. Cross-reference with Internal Logs: If your internal network has logs, such as firewall logs or
proxy server logs, cross-reference the external IP address and port number with these logs. This
will enable us to identify the local host that initiated the suspicious connection.
By correlating information from external server logs with internal network logs, we can pinpoint
the specific local host that was involved in the data exfiltration event. This information is crucial
for further investigation and remediation.
C. Reviewing Windows Event Viewer Logs: Here are some things to notice when reviewing the
application and security event logs:
Application event log: This log contains events from applications and services running on our
computer. It can be used to troubleshoot problems with applications and services, as well as to
track their activity.
Security event log: This log contains events related to security on our computer, such as logins,
logoffs, and file access. It can be used to detect and investigate security incidents, as well as to
monitor compliance with security policies.
It is important to review the application and security event logs regularly to identify and address
any potential problems. For example, we may notice errors in the application event log that
indicate that an application is not working properly.
Here are some specific examples of why it is important to review the application and security
event logs:
Application event log:
To troubleshoot problems with applications and services. For example, if an application is
crashing, we can review the application event log for errors that may indicate the cause of the
problem.
To track the activity of applications and services. For example, we can review the application
event log to see when a particular application was last used or when a particular service was
started or stopped.
Security event log:
To detect and investigate security incidents. For example, if we suspect that our computer has
been hacked, we can review the security event log for suspicious activity, such as failed login
attempts or unauthorized access to files.
To monitor compliance with security policies. For example, we can review the security event
log to ensure that users are logging in and logging out of our computer at the appropriate times.
