This document discusses RFID (Radio Frequency Identification) and its applications. It begins by explaining what RFID is and its basic components - RFID tags, readers, and software. It then describes the different types of RFID tags - passive, semi-passive, and active - and provides examples of their read ranges and uses. The document outlines several current applications of RFID technology, including credit cards, transportation payment systems, toll collection, and access control. It also shares the results of an online survey on RFID conducted with small and medium enterprises. In conclusion, it discusses further potential development areas and provides both positive and negative perspectives on RFID technology.

1. RFID & Its Applications
Members:
Fung LaiTing 15217221
GCIT1015

2. FLOW OF PRESENTATION
Introduction Applications Videos
Survey
Result
Conclusion
10/15/2015RFID & ITS Applications 2

3. RFID
• RFID = Radio Frequency Identification
• Electronic labeling and wireless identification of objects using radio frequency
• Tag carries with its information
• a serial number
• Model number
• Color or any other imaginable data
• When these tags pass through a field generated by a compatible reader, they
transmit this information back to the reader, thereby identifying the object
10/15/2015RFID & ITS Applications 3

4. RFID components
• A basic RFID system consists of these components:
• A programmable RFID tag/inlay for storing item data;
• Consisting of an RFID chip for data storage
• an antenna to facilitate communication with the RFID chip
• A reader/antenna system to interrogate the RFID inlay
• Application software and a host computer system
10/15/2015RFID & ITS Applications 4

5. RFIDTag
• The RFID tag consists of an integrated circuit (IC) embedded in a thin film medium.
• Information stored in the memory of the RFID chip is transmitted by the antenna
circuit embedded in the RFID inlay via radio frequencies, to an RFID reader
• 3 types
• Passive
• Semi-passive
• Active
10/15/2015RFID & ITS Applications 5

6. Types of RFIDTags
ActiveTags
• Use a battery
• communicate over distances of
several meters
Semi-passiveTags
• Contain built-in batteries to
power the chip’s circuitry, resist
interference and circumvent a
lack of power from the reader
signal due to long distance.
• They are different from active
tags in that they only transmit
data at the time a response is
received
PassiveTags
• Derive their power from the
field generated by the reader
• without having an active
transmitter to transfer the
information stored
10/15/2015RFID & ITS Applications 6

7. Applications
Frequency Appx. Read
Range
Data Speed Cost of
Tags
Application
Low Frequency
(125kHz)
<5cm
(passive)
Low High • Animal Identification
• Access Control
High Frequency
(13.56 Mhz)
10 cm – 1m
(passive)
Low to Moderate Medium
to Low
• Smart Cards
• Payment (paywave)
Ultra High
Frequency (433,
868-928 Mhz)
3m -7m
(passive)
Moderate to High Low • Logistics and Supply Chain
• Baggage Tracking
Microwave (2.45 &
5.8 Ghz)
10m -15m
(passive)
20m – 40m
(active)
High High • Electronic toll collection
(Autotoll)
• Container Tracking
10/15/2015RFID & ITS Applications 7

8. Current Applications
10/15/2015RFID & ITS Applications 8

9. Applications
Credit Cards with RFID
(Paywave function)
Octopus (Smart Card)
10/15/2015RFID & ITS Applications 9

10. Applications
Autotoll (Electronic toll collection)
Access Control
10/15/2015RFID & ITS Applications 10

11. Online Survey
• Target: SME
• Information: Opinion on RFID and its applications
• Site:
• http://qtrial.qualtrics.com/SE/?SID=SV_9N5UPRZuyuWtsk4
10/15/2015RFID & ITS Applications 11

12. Survey Result
10/15/2015RFID & ITS Applications 12
6%
23%
24%
29%
6%
12%
Types of the companies answersing the questionnaire
Education
Manufacturing
Retailing
Warehousing
Transportation
Others

13. Further Development
• In medical uses and library management
10/15/2015RFID & ITS Applications 13

14. Video
10/15/2015RFID & ITS Applications 14

15. Conclusion
• Positive
• RFID is a contactless reading technology and can read through other
materials
• Hold more data than barcode does
• RFID tags data can be changed or added
• More effective, bring lots of convenience to us
• Negative
• Cost is relatively remain high (compare to barcode)
• RFID signals may have problems with some materials
• RFID standards are still being developed 10/15/2015
RFID & ITS Applications
15
