This document compares several propagation path loss models - Okumura, Hata, ECC 33, Cost-231, and SUI - by estimating path losses and signal strengths at 950 MHz in urban, suburban, and rural areas. Path losses are estimated using each model and compared to measured practical data from those environments. The results show that the Hata model most closely matches the practical data across all three environments. Therefore, the Hata model is concluded to be the most suitable for predicting signal strength in urban, suburban, and rural areas.
Path Loss Characterization of 3G Wireless Signal for Urban and Suburban Envir...Onyebuchi nosiri
