Overview and extended description: AI is expected to be the engine of technological advancements in the healthcare industry, especially in the areas of radiology and image processing. The purpose of this session is to demonstrate how we can build a AI-based Radiologist system using Apache Spark and Analytics Zoo to detect pneumonia and other diseases from chest x-ray images. The dataset, released by the NIH, contains around 110,00 X-ray images of around 30,000 unique patients, annotated with up to 14 different thoracic pathology labels. Stanford University developed a state-of-the-art model using CNN and exceeds average radiologist performance on the F1 metric. This talk focuses on how we can build a multi-label image classification model in a distributed Apache Spark infrastructure, and demonstrate how to build complex image transformations and deep learning pipelines using BigDL and Analytics Zoo with scalability and ease of use. Some practical image pre-processing procedures and evaluation metrics are introduced. We will also discuss runtime configuration, near-linear scalability for training and model serving, and other general performance topics.

1. WIFI SSID:SparkAISummit | Password: UnifiedAnalytics

2. Yuhao Yang, Intel
Bala Chandrasekaran, Dell EMC
Using Deep Learning on Apache
Spark to diagnose thoracic
pathology from chest X-rays
#UnifiedAnalytics #SparkAISummit

3. Agenda
• Problem statement
• Analytics Zoo
• Chest Xray Model architecture
• Results and Observations
3#UnifiedAnalytics #SparkAISummit

4. Predicting diseases in Chest X-rays
• Develop a ML pipeline in Apache Spark and train a deep
learning model to predict disease in Chest X-rays
▪ An integrated ML pipeline with Analytics Zoo on Apache Spark
▪ Demonstrate feature engineering and transfer learning APIs in
Analytics Zoo
▪ Use Spark worker nodes to train at scale
• CheXNet
– Developed at Stanford University, CheXNet is a model for
identifying thoracic pathologies from the NIH ChestXray14 dataset
– https://stanfordmlgroup.github.io/projects/chexnet/
4#UnifiedAnalytics #SparkAISummit

5. X-ray dataset from NIH
5#UnifiedAnalytics #SparkAISummit
• 112,120 images from over 30000 patients
• Multi label (14 diseases)
• Unbalanced datasets
• Close to 50% of the images have ‘No findings’
• Infiltration get the most positive samples
(19894) and Hernia get the least positive
samples (227)
0
10000
20000
30000
40000
50000
60000
70000
Atelectasis
Consolidation
Infiltration
Pneumothorax
Edema
Emphysema
Fibrosis
Effusion
Pneumonia
PleuralThickening
Cardiomegaly
Nodule
Mass
Hernia
NoFindings
Frequency
00000013_005.png,Emphysema | Infiltration | Pleural_Thickening
00000013_006.png,Effusion|Infiltration
00000013_007.png,Infiltration
00000013_008.png,No Finding

6. Analytics Zoo

7. Analytics Zoo
Reference Use Cases
Anomaly detection, sentiment analysis, fraud detection, chatbot, sequence prediction,
etc.
Built-In Deep Learning Models
Image classification, object detection, text classification, recommendations, sequence-
to-sequence, anomaly detection, etc.
Feature Engineering
Feature transformations for
• Image, text, 3D imaging, time series, speech, etc.
High-Level Pipeline APIs
• Distributed TensorFlow and Keras on Spark
• Native deep learning support in Spark DataFrames and ML Pipelines
• Model serving API for model serving/inference pipelines
Backends Spark, TensorFlow, Keras, BigDL, OpenVINO, MKL-DNN, etc.
7#UnifiedAnalytics #SparkAISummit
Distributed TensorFlow, Keras and BigDL on Apache Spark
https://github.com/intel-analytics/analytics-zoo/

8. Bringing Deep Learning To Big Data Platform
• Distributed deep learning framework for Apache Spark*
• Make deep learning more accessible to big data users
and data scientists
– Write deep learning applications as standard Spark
programs
– Run on existing Spark/Hadoop clusters (no changes
needed)
• Feature parity with popular deep learning frameworks
– E.g., Caffe, Torch, Tensorflow, etc.
• High performance (on CPU)
– Built-in Intel MKL and multi-threaded programming
• Efficient scale-out
– Leveraging Spark for distributed training & inference
8#UnifiedAnalytics #SparkAISummit
https://github.com/intel-analytics/BigDL
https://bigdl-project.github.io/

9. 9
Architecture
• Training using synchronous mini-batch SGD
• Distributed training iterations run as standard Spark jobs

10. Parameter Synchronization
10#UnifiedAnalytics #SparkAISummit
Task n
1 2 n
1 2 n
1 2 n 1 2 n
1 2 n
Task 1 Task 2
local gradient local gradient local gradient
∑ ∑ ∑
gradient 1 gradient n
weight 1 weight 2 weight n
“Parameter Synchronization” Job
update update update
gradient 2

11. Integrated Pipeline for Machine Learning
and Deep Learning
ImageReader Image Pre-
processing
Classification fit
Images
in HDFS
Images
DataFrame
Images as
RDD
Image Classification
Model

12. Building the X-ray Model

13. Let’s build the model
13#UnifiedAnalytics #SparkAISummit
Read the X-ray images
Feature Engineering
Define the model
Define optimizer
Train the model

14. Read the X-ray images as Spark DataFrames
• Initialize NNContext and load X-ray images into
DataFrames using NNImageReader
• Process loaded X-ray images and add labels (another
DataFrame) using Spark transformations
14#UnifiedAnalytics #SparkAISummit
Read the X-ray
images
Feature Engineering
Define the model
Define optimizer
Training the model
from zoo.pipeline.nnframes import NNImageReader
imageDF = NNImageReader.readImages(image_path, sc,
resizeH=256, resizeW=256, image_codec=1)
trainingDF = imageDF.join(labelDF, on="Image_Index",
how="inner")

15. Feature Engineering – Image Pre-processing
In-built APIs for feature engineering using ChainedPreprocessing API
15#UnifiedAnalytics #SparkAISummit
Read the X-ray
images
Feature Engineering
Define the model
Define optimizer
Training the model
ImageCenterCrop()
ImageFlip()
ImageChannelNormalize()
ImageMatToTensor()
ImageCenterCrop(224, 224)
Random flip and brightness
ImageChannelNormalize()
To Tensor()

16. Transfer Learning using ResNet-50
trained with ImageNet
16#UnifiedAnalytics #SparkAISummit
Condition E
Condition D
Condition C
Condition B
Condition A
Patient A
Add a new
input layer
Remove the existing
classification layer and add
new classification layer

17. Defining the model with Transfer Learning APIs
17#UnifiedAnalytics #SparkAISummit
Read the X-ray
images
Feature Engineering
Define the model
Define optimizer
Training the model
• Load a pre-trained model using Net.load_bigdl. The model is
trained with ImageNet dataset
– Inception
– ResNet 50
– DenseNet
• Remove the final softmax layer of ResNet-50
• Add new input (for resized x-ray images) and output layer (to
predict the 14 diseases). Activation function is Sigmoid
• Avoid overfitting
– Regularization
– Dropout

18. Defining the model with Transfer Learning APIs
18#UnifiedAnalytics #SparkAISummit
Read the X-ray
images
Feature Engineering
Define the model
Define optimizer
Training the model
def get_resnet_model(model_path, label_length):
full_model = Net.load_bigdl(model_path)
model = full_model.new_graph(["pool5"])
inputNode = Input(name="input", shape=(3, 224, 224))
resnet = model.to_keras()(inputNode)
flatten =
GlobalAveragePooling2D(dim_ordering='th')(resnet)
dropout = Dropout(0.2)(flatten)
logits = Dense(label_length,
W_regularizer=L2Regularizer
(1e-1), b_regularizer=L2Regularizer(1e-1),
activation="sigmoid")(dropout)
lrModel = Model(inputNode, logits)
return lrModel

19. Define the Optimizer
19#UnifiedAnalytics #SparkAISummit
Read the X-ray
images
Feature Engineering
Define the model
Define optimizer
Training the model
• Evaluated two optimizers: SGD and Adam Optimizer
• Learning rate scheduler is implemented in two
phases:
– Warmup + Plateau schedule
– Warmup: Gradually increase the learning rate for 5
epochs
– Plateau: Plateau("Loss", factor=0.1, patience=1,
mode="min", epsilon=0.01, cooldown=0, min_lr=1e-
15)

20. Train the model using ML Pipelines
20#UnifiedAnalytics #SparkAISummit
Read the X-ray
images
Feature Engineering
Define the model
Define optimizer
Training the model
• Analytics Zoo API NNEstimator to build the model
• .fit() produces a neural network model which is a Transformer
• You can now run .predict() on the model for inference
• AUC-RoC is used to measure the accuracy of the model. Spark
ML pipeline API BinaryClassificationEvaluator to determine the
AUC-ROC for each disease.
estimator = NNEstimator(xray_model, BinaryCrossEntropy(), transformer)
.setBatchSize(batch_size).setMaxEpoch(num_epoch)
.setFeaturesCol("image").setCachingSample(False).
.setValidation(EveryEpoch(), validationDF, [AUC()], batch_size)
.setOptimMethod(optim_method)
Xray_nnmodel = estimator.fit(trainingDF)

21. Results and observations
21#UnifiedAnalytics #SparkAISummit

22. Spark parameter recommendations
• Number of executors Number of compute nodes
• Number of executor cores Number of physical cores
minus two
• Executor memory
Number of cores per executor * (Memory required for each core +
data partition)
22#UnifiedAnalytics #SparkAISummit

23. 0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
0
0.00002
0.00004
0.00006
0.00008
0.0001
0.00012
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
AverageAUC(Higherisbetter)
LearningRate
Epochs
Learning rate
Average AUC w/ Learning Rate Scheduler
Average AUC w/o Learning Rate Scheduler
Impact on Learning Rate Scheduler
• Adam (with Learning
Rate Scheduler)
outperforms SGD
– Warmup
– Plateau
• Learning rate scheduler
helps is covering the
model much faster
23#UnifiedAnalytics #SparkAISummit
1E-7

24. Base model comparison
24#UnifiedAnalytics #SparkAISummit
0.5
0.55
0.6
0.65
0.7
0.75
0.8
0.85
0.9
0.95
AUC(Higherisbetter)
Inception-V3 DenseNet-121 ResNet-50

25. 0.55
0.6
0.65
0.7
0.75
0.8
0.85
1 2 3 4 5 6 7 8
AverageAUC(Higherisbetter)
Batch per thread
Batch size and Scalability
• Two factors:
– Batches per thread (mini-batch): Number of
images in a iteration per worker
– Global batch size: Batches per thread *
Number of workers
• Batch size is a critical parameter for
model accuracy as well as for
distributed performance
– Increasing the batch size increases
parallelism
– Increasing the batch size may lead to a loss in
generalization performance especially
25#UnifiedAnalytics #SparkAISummit

26. Scalability
26#UnifiedAnalytics #SparkAISummit
0
0.5
1
1.5
2
2.5
3
3.5
4 8 12 16
Speedup(Higherisbetter)
Number of nodes
3x speed up from 4 nodes to 16 nodes.
~ 2.5 hours to train the model
bz=512
bz=1024
bz=1536
bz=2048
* 15 epochs and 32 cores per executor

27. Future Work
• Continue to improve the model performance and
scalability
– Implement LARS and other advanced learning rate scheduler for
large scale training
• Increase the feature set
– Incorporate patient profile information
• Develop performance characteristic and sizing
guidelines for image classification problems
27#UnifiedAnalytics #SparkAISummit

28. Links
Code and white paper available at
https://github.com/dell-ai-engineering/BigDL-
ImageProcessing-Examples
28#UnifiedAnalytics #SparkAISummit

29. Acknowledgements
Mehmood Abd, Michael Bennett, Sajan Govindan, Jenwei Hsieh, Andrew Kipp,
Dharmesh Patel, Leela Uppuluri, and Luke Wilson
29#UnifiedAnalytics #SparkAISummit
(Alphabetical)
