This document describes Trans Innovation Group (TI Group), an electronics design and manufacturing company established in 1985. It has over 200 employees with in-house R&D, production, and global sales networks. TI Group provides electro-mechanical design, embedded computing, cooling, power, and monitoring solutions for applications in telecom, defense, industrial, and medical sectors. It has capabilities in hardware and software development, manufacturing, and technical support.

1. GROUP
TRANS
INNOVATION
www. t i - group . c o. i l

2. ONE PLACE ENDLESS SOLUTIONS
Established in 1985 Over 200 employees In House R&D group Production plant Global presence WW network of reps & distributors

3.  Over 30 years of presence in
the Israeli market
 3000sqm logistic center
 Electronic component
lifecycle management
 Import / Export team
 Advanced exchange
 After sales support (SLA) Standards
 ISO 9001
 MIL
 Medical
 Serving the global market
 Vast experience and
proven building blocks
 HW / SW & Mechanical
Design
 In-house safety labs
approved by DEKRA
 NPI and V&V
 High-mix & high quality
production
 Over 150 skilled employees
 “class-100” clean room
 Exclusive vendors
 Large Customer Base &
long term relationship
 Experts Field
Application Engineers
CORE COMPETENCIES

4. CAPABILITIES
One Place Endless Solutions
Electro-Mechanical
Design
R&D CAPABILITIES MANUFACTURING COTS PRODUCTS CUSTOM SOLUTIONS
HW & SW Development
System V&V Team
Engineering + NPI
Custom Backplanes
MIL / MED standards
Embedded Computing
Cables Assemblies
Cabinet Solutions
ATCA
Dynamic LoadBlades
Backplanes
VPX solutions
mTCA
High Speed Backplanes
Mechanical design
Thermal analysis
HW & SW Solutions
Power & Monitoring
Solutions
System Architecture

5. SELECTED VENDORS & PRODUCTS CATEGORIES
Antennas & wireless modules
Cable protection solutions
Camera solutions
Communication devices
Connectors
Crystals & oscillators
Display
High availability platforms
High performance computing &
industrial PCs
Led light guide
Power supplies
Relays
Sensors and RFID
Sockets
Surge protection
Thermal Printers
Wires & Cables
Industrial control automation
& power infrastructure products

6. electro-mechanical and embedded engineering solutions
FIBER OPTICS PROJECTS
ELECTROMECHANICAL
CABINETS
ELECTROMECHANICAL
PROJECTS
ENCLOSURES
SOME OF TIG’S PROJECTS

7. electro-mechanical and embedded engineering solutions
PRODUCTS & CAPABILITIES
A solution for all your needs - from a small 1U chassis to the industry’s newest 14U chassis
40/100 ATCA Platforms Embedded Computing ATE

8. CABLES
Molded cables Robotics cables Communication and control cables
High Voltage cables RF cablesPower cables
PRODUCTS & CAPABILITIES

9. Military / Medical / Industrial Cables
PRODUCTS & CAPABILITIES

10. Military Cables AS9100
PRODUCTS & CAPABILITIES

11. PROJECTS &
CAPABILITIES
www. t i - group . c o. i l

12. FUTURE PROOF EXPANDABLE CHASSIS
Shelf manager module solution for control
and monitoring chassis activity and log.
Creative solutions & services, vast experience and proven building blocks
Designs and manufactures embedded computing systems, backplanes, hardware and software solutions for ATCA, CompactPCI, and custom applications. Established in 1998, the
company has been serving the telecom, enterprise, defense, aerospace, and industrial markets, bringing innovations in high-speed interconnect and thermal modeling that exceed the
standard in performance and reliability.
Record breaking cooling power
200W - 700W per slot in ATCA form factor
Cooling Management:
fan speed control per temp and status
Cooling architecture:
S2S, F2B (4U-Patented), B2T (CERN)
High Performance 40/100Gbps backplanes
High Speed PCB material (FR4, Nelco
4000SI, Megtron6, Tachiyon)
optimize layer stack-up, routing and via design
High speed signal integrity simulations
Layer stack-up
Routing and vias design
Backplane high speed performance verification
tests.
Power up and E-keying
Cooling management
Power management
Comprehensive event log and remote
monitoring support (SNMP, HPI, cli)
Power
Support AC and DC power
Up to 250A @ 48V
Redundancy: N+1 / N+N
Monitoring power supply status
(failures, redundancy)
Chassis Management
Embedded solutions R&D

13. PCIe SWITCH DEVELOPMENT
Test & Measurement
AXIe customized 5U 7S platform with Embedded PCIe GEN 3 switching architecture.
PCIe Switch Custom ATCA HW & SW Dev.
Custom Hardware &
Software Design
• AXIe platform based on ASIS 5U ATCA solution for T&M market.
• AXIe Embedded system module based on PCIe GEN 3 switch for
fabric zone
• Up to 8Gb per PCIe lane, capable of delivering up to 32Gb per slot.
• Ethernet switch for internal application management
• chassis management include FAN and Power control and
monitor based on IPMC devices, and ASIS proprietary IP's.
Embedded solutions R&D

14. SENSING + MONITORING
Industrial Machinery
MCU | Water leak and smoke detection control box - Industrial Machine
Sensing &
Monitoring
Manufacture HW + SW
Design
Smoke / Water Leak Detection
• The MCU comes with 3 sensors connected to the box, the sensors are
located in strategic locations inside the machine. Using this sensors the
box sends signals and alarms to main inspection machine controller,
and perform emergency shutdown.
• Events - water leak, smoke, door open etc.
Embedded solutions R&D

15. POWER + SW SOLUTIONS
Data Centers
Rack mount controller - ATS control and monitoring, remote access - for data Centers.
ATS design Thermal
Simulations
Embedded
Solutions
T.O.R – Critical Mission
• A critical mission 5 nines solution for managing and control 42U rack
Optimized software application especially for data-centers .(3 UPS,
SSD and HDD Storage)
• The solution includes an out-of-the-box Electro-Mechanical design that
allows 100% availability and easy serviceability..
Embedded solutions R&D

16. COOLING + MONITORING
Industrial Machinery
1U X9 Fans for Wafer Inspection Machine
Cooling
Expertise
Monitoring
SW
Automatic /
Manual Control
Custom design for
cooling solutions
• Floating, very low vaibration FAN Tray Solution - It was design in such a
way that the vibrations from the FAN's reduced to a minimum level to
prevent from the internal electron beam to be affect.
• The tray uses to cool electrical blocks inside the machine and in the
Rack. It’s Fully monitored with automatic and manual speed control
Embedded solutions R&D

17. RUGGEDIZED COMPUTING SOLUTIONS
Military Applications
Designs & Manufactures Embedded Solutions
Embedded
Computing
Solutions
Harsh
Environments
Wide
temperature
range
Mission Critical Application
• VPX Backplanes
• ATCA / mTCA platforms solutions
• Power Solutions for Tactic Vehicles
• RT HW / SW solutions
Embedded solutions R&D

18. THANK YOU
Join us on LinkedIn
LinkedIn.com/TransInnovation
Watch Our Videos
Youtube.com/TransInnovation
VISIT US ON OUR WEBSITE: WWW.TI-GROUP.CO.IL
