1. Telemecanique Sensors
Briefing
Cabling and accessories

2. Agenda
Property of Schneider Electric |
Table of content
• Telemecanique Sensors portofolio
• Cabling and accessories OsiSence XZ
• PVC cable
• PUR cable
• Reinforced PVC cable
• Panorama accessories
• Where to find further details

3. Telemecanique Sensors – May 2016 3
Telemecanique Sensors portfolio
A world-class global brand offering a comprehensive line of products complying with
international standards: IEC, UL, CSA, CCC, GOST
Other
Cordsets, encoders
Safety
RFIDUltrasonicPhotoelectric Pressure
Inductive,
capacitive
NEMA switchesLimit switches

4. Telemecanique Sensors – May 2016 4
Quality
Our products have earned the independent approval of all the relevant bodies
that govern the industries and applications we serve.
All our manufacturing facilities are ISO 9001 and ISO 14001 certified.
Limoges, France Batam, Indonesia

5. Telemecanique Sensors – May 2016 5
Cabling accessories
• Full range of connectors, cordsets, and jumpers with PVC
or PUR cable
• M8, M12, DiN, ½”, 7/8”, EN 175301-803-A, … connectors
New

6. Telemecanique Sensors – May 2016 6
Why cabling accessories?
• Opting for sensors incorporating a connector gives you a quick,
high-performance solution. In the event of having to replace a
sensor on a machine, this is achieved very quickly using
products with connectors.
• We offer a complete range of cabling accessories featuring
three types of cable to suit the environment.

7. Telemecanique Sensors – May 2016 7
PVC cable for general use
The OsiSenseTM
XZ range of PVC pre-wired connectors and jumper cables
for general use is recommended for machines in nondemanding environments
and subject only to moderate mechanical stress.
These products are particularly suited to assembly, material handling,
and packaging machines.
The sheath color distinguishes the two versions available:
• Gray sheath for versions with metric connectors (M8 and M12)
• Yellow sheath for versions with imperial connectors (1/2” and 7/8”)
Good resistance
• to moderate mechanical stress
• to chemical products
• to humid environments
Easy cable stripping, UL certified
PVC
economy
and competitiveness
The + of the PVC range

8. Telemecanique Sensors – May 2016 8
PUR cable for severe industrial environments
The OsiSense XZ range of very high performance PUR (polyurethane)
pre-cabled connectors and jumper cable is designed for the most demanding
industrial requirements.
This offer is ideal for machines using lubricants, cooling oils, and grease and
subject to severe mechanical stress (cable flexing and friction). These cables are
ideal for the automobile, machine tool, and hydraulic machine sectors. Their
excellent flexibility enables intensive use for alternating movements such as those
associated with cable carries, robotics, turntables, etc.
They are halogen free and UL certified, and have high degrees of protection
(IP67 and IP69K).
0 discharge,
halogen free
4 million
alternating
(flexing)
operations
Good resistance
• To severe mechanical stress
(friction, abrasion, torsion)
• To hot and cold oils,
greases, and lubricants
Halogen free, UL certified
The + of the PUR range

9. Telemecanique Sensors – May 2016 9
Reinforced PVC cable for food and beverage
processing environments
The OsiSense XZ range of reinforced PVC pre-cabled connectors and jumper
cables is specially designed for the food and beverage processing industry.
Featuring hygienic design stainless Steel 316L connectors with smooth clamping
ring, these products are designed to withstand high pressure washing
and disinfection using aggressive products.
IP69K
stainless steel
316L
resistance
assurance
Good resistance
• to high pressure cleaning
(IP69K and smooth, stainless steel,
clamping ring)
• to disinfection using
aggressive products
The + of the PVC food range

10. Telemecanique Sensors – May 2016 10
How to choose the right cable?
2 31 4
2 31 4
Mecanichal compatibillity
with sensors
Pin Wire Mecanichal compatibillity
with splitter boxes
Reference
> > > >

11. Telemecanique Sensors – May 2016 11

12. Telemecanique Sensors – May 2016 12

13. Telemecanique Sensors – May 2016 13
Where to find details
• Click here to find info on SE.com
• Click here to find cordset and connectors on SE.com
• Click here to access our Digicat
• Click here to access to CAD files
• Click on the link below for FAQs (frequently asked
question)
Page 13
