A short talk which covered more the core game loop/entity/drawing primitive pattern more than the actual Canvas API. Terrible Haiku as a bonus.

1. The Canvas API
for Rubyists
Cascadia Ruby, August 3rd, 2012
Harry Dean Hudson

2. Who Am I?
Dean Hudson, @deanero
Bit Twiddler at Massively Fun

3. We make games with
open web technology.
(And are hiring).
http://massivelyfun.com
@massivelyfun

4. Word * Word

5. What is this talk?
• Actually less about Canvas API and more
about patterns in which it can be used...
• No Ruby! (Sorry Rubyists).
• Play along! https://github.com/massivelyfun/
canvas-playground
• ...in 5 / 7 / 5.

6. Canvas API:
2D graphics in browser.
It is quite simple.

7. Canvas is
• 2D, immediate mode, graphics API
• Well supported in modern browsers
• A collection of drawing calls
• Not Flash!

8. (function () {
var ImageData = function (width, height) {
this.width = width || 10;
this.height = height || 10;
numPixels = this.width * this.height;
this.data = new Uint8Array(numPixels * 4);
};
var CanvasGradient = function () {};
CanvasGradient.prototype.addColorStop = function (offset, color) {
return undefined;
};
var CanvasPattern = function (image, repetitionStyle) {
this.image = image;
this.repetitionStyle = repetitionStyle;
};
var TextMetrics = function (ctx, text) {
this...
// quick and dirty style
var fontSize = parseInt(ctx.font),
chars = text.split().length;
this.width = fontSize * chars;
}
var CanvasRenderingContext2D = function (canvas) {
this.canvas = canvas;
this.fillStyle = "rgb(0,0,0)";
this.font = "10px sans-serif";
this.globalAlpha = 1.0;
this.globalCompositionOperation = "source-over";
this.lineCap = "butt";
this.lineJoin = "miter";
this.lineWidth = 1.0;
this.miterLimit = 10;
this.textAlign = "start";
this.textBaseLine = "alphabetic";
this.shadowBlur = 0;
this.shadowColor = "rgba(0,0,0,0)";
this.shadowOffsetX = 0;
this.shadowOffsetY = 0;
this.strokeStyle = "rgb(0,0,0)";
this.__width = this.canvas.width;
this.__height = this.canvas.height;
this.__imageData = null; // don't do this until we need it, it's a memory hog.
// new ImageData(this.__width, this.__height);
this.__curX = 0;
this.__curY = 0;

9. this.__openSubpath = true;
this.__initTime = new Date();
this.__lastUpdateTime = null;
this.__lastFillTime = null;
this.__updateCount = 0;
this.__fillCount = 0;
};
CanvasRenderingContext2D.prototype.__update = function () {
var args = Array.prototype.slice.call(arguments);
this.__lastUpdateTime = new Date();
this.__updateCount++;
}
CanvasRenderingContext2D.prototype.__fill = function () {
var args = Array.prototype.slice.call(arguments);
this.__lastFillTime = new Date();
this.__fillCount++;
}
// Stub out the real methods. I'm explicitly returning undefined
// in cases where the API calls for void return, so as to be clear
// about the intent. This is a simple sub-set of the API focused
// on operations for images. TODO: implement transforms and state.
CanvasRenderingContext2D.prototype.arc = function (x, y, radius, startAngle, endAngle, counterClockwise) {
this.__openSubpath = true;
...plus this...
return undefined;
};
CanvasRenderingContext2D.prototype.arcTo = function (x1, y1, x2, y2, radius) {
this.__openSubpath = true;
this.__curX = x2;
this.__curY = y2;
return undefined;
};
CanvasRenderingContext2D.prototype.beginPath = function () {
this.__openSubpath = true;
return undefined;
};
CanvasRenderingContext2D.prototype.bezierCurveTo = function (cpX1, cpY1, cpX2, cpY2, x, y) {
this.__openSubpath = true;
this.__curX = x;
this.__curY = y;
return undefined;
};
CanvasRenderingContext2D.prototype.clearRect = function () {
return undefined;
};
CanvasRenderingContext2D.prototype.clip = function () {
return undefined;
};
CanvasRenderingContext2D.prototype.closePath = function () {
this.__openSubpath = false;
return undefined;
};
CanvasRenderingContext2D.prototype.createImageData = function () {
var args = Array.prototype.slice.call(arguments);

10. CanvasRenderingContext2D.prototype.clip = function () {
return undefined;
};
CanvasRenderingContext2D.prototype.closePath = function () {
this.__openSubpath = false;
return undefined;
};
CanvasRenderingContext2D.prototype.createImageData = function () {
var args = Array.prototype.slice.call(arguments);
if (args[0].hasOwnProperty('data') && typeof args[0].data !== 'undefined') {
return new ImageData(args[0].data.length, 1);
} else if (typeof args[0] === 'number' && typeof args[1] === 'number') {
return new ImageData(args[0], args[1]);
} else {
throw new Error("Invalid arguments. createImageData() takes 1 or 2 args.");
}
};
CanvasRenderingContext2D.prototype.createLinearGradient = function (xStart, yStart, xEnd, yEnd) {
return new CanvasGradient();
};
CanvasRenderingContext2D.prototype.createPattern = function (image, repetitionStyle) {
return new CanvasPattern(image, repetitionStyle);
};
CanvasRenderingContext2D.prototype.createRadialGradient = function (xStart, yStart, radiusStart, xEnd, yEnd, radiusEnd) {
...plus this...
return new CanvasGradient();
};
CanvasRenderingContext2D.prototype.drawImage = function () {
switch(arguments.length) {
case 3:
return CanvasRenderingContext2D.prototype.__drawImage3.apply(this, arguments);
case 5:
return CanvasRenderingContext2D.prototype.__drawImage5.apply(this, arguments);
case 9:
return CanvasRenderingContext2D.prototype.__drawImage9.apply(this, arguments);
default:
throw new Error("Invalid number of arguments. drawImage() takes, 3, 5, or 9 args.");
}
};
// All that contortion and I don't do anything with it. I'm stubbing
// this out in case I want to at some point.
CanvasRenderingContext2D.prototype.__drawImage3 = function (image, dx, dy) {
return undefined;
};
CanvasRenderingContext2D.prototype.__drawImage5 = function (image, dx, dy, dw, dh) {
return undefined;
};
CanvasRenderingContext2D.prototype.__drawImage9 = function (image, sx, sy, sw, sh, dx, dy, dw, dh) {
return undefined;
};
CanvasRenderingContext2D.prototype.fill = function () {
return undefined;
};
CanvasRenderingContext2D.prototype.fillRect = function (x, y, width, height) {

11. return retImageData;
};
CanvasRenderingContext2D.prototype.isPointPath = function (x, y) {
return true;
};
CanvasRenderingContext2D.prototype.lineTo = function (x, y) {
this.__openSubpath = true;
this.__curX = x;
this.__curY = y;
return undefined;
};
CanvasRenderingContext2D.prototype.measureText = function (text) {
return new TextMetrics(this, text);
};
CanvasRenderingContext2D.prototype.moveTo = function (x, y) {
this.__curX = x;
this.__curY = y;
return undefined;
};
CanvasRenderingContext2D.prototype.putImageData = function (insertData, dx, dy, sx, sy, sw, sh) {
if (arguments.length !== 7)
throw new Error("putImageData requires 7 arguments")
var imageData = this.__imageData || new ImageData(this.__width, this.__height),
...plus this...
startAt = dx * dy * 4 + dx + 4,
fromData,
fromOffset = sx * sy * 4 + sx * 4,
fromNumPixels = sw * sh * 4 + sw * 4,
endAt = imageData.length - 1,
howMany;
if (typeof fromOffset === 'number' && typeof fromNumPixels === 'number') {
fromData = insertData.data.slice(fromOffset, fromOffset + fromNumPixels);
} else {
fromData = insertData.data;
}
startAt + fromData.length > endAt ? howMany = endAt - startAt : howMany = startAt + fromData.length;
imageData.data.splice(startAt, howMany, fromData);
return undefined;
};
CanvasRenderingContext2D.prototype.quadraticCurveTo = function (cpX, cpY, x, y) {
this.__curX = x;
this.__curY = y;
return undefined;
};
CanvasRenderingContext2D.prototype.rect = function (x, y, width, height) {
this.__curX = x;
this.__curY = y;
return undefined;
};
CanvasRenderingContext2D.prototype.restore = function () {
return undefined;

12. return undefined;
};
CanvasRenderingContext2D.prototype.restore = function () {
return undefined;
};
CanvasRenderingContext2D.prototype.rotate = function (angle) {
return undefined;
};
CanvasRenderingContext2D.prototype.save = function () {
return undefined;
};
CanvasRenderingContext2D.prototype.scale = function (sx, sy) {
return undefined;
};
CanvasRenderingContext2D.prototype.setTransform = function (a, b, c, d, e, f) {
return undefined;
};
CanvasRenderingContext2D.prototype.stroke = function () {
return undefined;
};
CanvasRenderingContext2D.prototype.strokeRect = function (x, y, width, height) {
return undefined;
};
CanvasRenderingContext2D.prototype.strokeText = function (text, x, y, max) {
return undefined;
...and this.
};
CanvasRenderingContext2D.prototype.transform = function (a, b, c, d, e, f) {
return undefined;
};
CanvasRenderingContext2D.prototype.translate = function (dx, dy) {
return undefined;
};
var Canvas = function () {
this.width = 10; // API default is 300 x 150, but that makes
this.height = 10; // our ImageData a memory hog.
};
Canvas.prototype.getContext = function (cxtType) {
return new CanvasRenderingContext2D(this);
};
Canvas.prototype.toDataURL = function () {
var buf = new Buffer("Say hello to my little friend.");
return "data:text/plain;base64," + buf.toString('base64');
};
module.exports = Canvas;
})();

13. The CanvasContext:
It has all the calls to draw
Pixels to the screen.

14. Simple, no?
cvs = document.getElementById("canvas")
ctx = cvs.getContext("2D")
# ctx has all your draw methods...
ctx.fillText("Hello!", 100, 100, 200)

15. Simple, no?
cvs = document.getElementById("canvas")
ctx = cvs.getContext("2D")
# ctx has all your draw methods...
ctx.fillText("Hello!", 100, 100, 200)
You’ll only see this from here out.

16. dean@dean:~$ grep prototype canvas.js |
wc -l
38
You can learn the draw
API in a weekend!

17. dean@dean:~$ grep prototype canvas.js |
wc -l
38
You can learn the draw
API in a weekend!
...so, on to bigger things!

18. Browser event loops
Are not well suited for games
You must roll your own

19. Simple Game Loop
• Handle queued UI/server events
• Update state of “things” on screen.
• Re-draw!

20. # a fake game loop
gameLoop =
run: ->
@handleQueuedEvents()
@update()
@draw()
# loop somehow?

21. setInterval()?
setTimeout()?

22. NO!

23. 16 ms !=
16.666...ms
Text
(60 FPS)

24. For accurate loops
requestAnimationFrame()
Will bring you great joy

25. requestAnimationFrame
allows the browser to
manage screen updates
efficiently...

26. requestAnimationFrame
allows the browser to
manage screen updates
efficiently...
...but is not uniformly
supported.

27. buildRAFPolyfill = ->
requestAnimationFrame =
requestAnimationFrame ||
webkitRequestAnimationFrame ||
mozRequestAnimationFrame ||
oRequestAnimationFrame ||
msRequestAnimationFrame ||
-> (cb, elt)
setTimeout (cb) ->
cb(+new Date())
, 1000 / 60

28. class GameLoop
constructor: (cvs) ->
@ctx = cvs.getContext("2D")
@entities = []
addEntity: (entity) ->
@entities.push(entity)
run: () =>
tick = @frameId = requestAnimationFrame(@run)
# Update entities
entity.update(tick) for entity in @entities
# Draw!
entity.draw(@ctx) for entity in @entities
stop: ->
root.cancelAnimationFrame(@frameId)

29. class GameLoop
constructor: (cvs) ->
@ctx = cvs.getContext("2D")
@entities = []
addEntity: (entity) ->
@entities.push(entity)
run: () =>
tick = @frameId = requestAnimationFrame(@run)
# Update entities
entity.update(tick) for entity in @entities
# Draw!
entity.draw(@ctx) for entity in @entities
stop: ->
root.cancelAnimationFrame(@frameId)
requestAnimationFrame returns a int “id”

30. Entities and Rects:
The largest things are built
From just these pieces.

31. Simple Game
Entity
• Respond to update call
• Manage position, height, width
• Delegate draw calls

32. # Game level object
class Entity
# Rect is a drawing primitive
constructor: (options = {}) ->
@rect = options.rect ? null
{x, y} = options
@position = {x: x, y: y}
update: (tick) ->
# override and do something interesting here.
draw: (ctx) ->
# delegate to your drawing primitive!
@rect.draw(ctx)
module.exports = Entity

33. # Game level object
class Entity
# Rect is a drawing primitive
constructor: (options = {}) ->
@rect = options.rect ? null
{x, y} = options
@position = {x: x, y: y}
update: (tick) ->
# override and do something interesting here.
draw: (ctx) ->
# delegate to your drawing primitive!
@rect.draw(ctx)
module.exports = Entity
Game level logic, once per tick

34. # Game level object
class Entity
# Rect is a drawing primitive
constructor: (options = {}) ->
@rect = options.rect ? null
{x, y} = options
@position = {x: x, y: y}
update: (tick) ->
# override and do something interesting here.
draw: (ctx) ->
# delegate to your drawing primitive!
@rect.draw(ctx)
module.exports = Entity
DELEGATE!!!!!

35. Simple Draw
Primitive
• Associated with Entity
• Responds to draw() call
• Has actual CanvasContext2D drawing calls
• You can determine containment here
(image hit detection, for instance)

36. #
# Rect: Drawing primitive for canvas.
class Rect
constructor: (options = {}) ->
@width = options?.width ? 1
@height = options?.height ? 1
{x, y} = options
@position = {x: x, y: y}
draw: (canvasCtx) ->
throw new Error("Implement draw()")
module.exports = Rect

37. #
# Rect: Drawing primitive for canvas.
class Rect
constructor: (options = {}) ->
@width = options?.width ? 1
@height = options?.height ? 1
{x, y} = options
@position = {x: x, y: y}
draw: (canvasCtx) ->
throw new Error("Implement draw()")
module.exports = Rect
Your *simple* interface

38. Rect = require "rect"
# Sometimes we just need the simple things.
# Make a simple box subclass.
class Box extends Rect
constructor: (options = {}) ->
super(options)
draw: (ctx) ->
{x, y} = @position.get()
ctx.fillRect(x, y, @width, @height)
module.exports = Box

39. Rect = require "rect"
# Sometimes we just need the simple things.
# Make a simple box subclass.
class Box extends Rect
constructor: (options = {}) ->
super(options)
draw: (ctx) ->
{x, y} = @position.get()
ctx.fillRect(x, y, @width, @height)
module.exports = Box
Implement draw

40. Rect = require "rect"
# Sometimes we just need the simple things.
# Make a simple box subclass.
class Box extends Rect
constructor: (options = {}) ->
super(options)
draw: (ctx) ->
{x, y} = @position.get()
ctx.fillRect(x, y, @width, @height)
module.exports = Box
Do work on CanvasContext2D

41. Canvas tests are hard;
The one true way is to cheat.
Stub, Stub, stub the world.

42. CanvasRenderingContext2D.prototype.__update = function () {
var args = Array.prototype.slice.call(arguments);
this.__lastUpdateTime = new Date();
this.__updateCount++;
}
CanvasRenderingContext2D.prototype.__fill = function () {
var args = Array.prototype.slice.call(arguments);
this.__lastFillTime = new Date();
this.__fillCount++;
}
// Stub out the real methods. I'm explicitly returning undefined
// in cases where the API calls for void return, so as to be clear
// about the intent. This is a simple sub-set of the API focused
// on operations for images. TODO: implement transforms and state.
CanvasRenderingContext2D.prototype.arcTo = function (x1, y1, x2, y2, radius) {
this.__openSubpath = true;
this.__curX = x2;
this.__curY = y2;
return undefined;
...etc.
};

43. Questions?

44. Thanks!
dean@massivelyfun.com, @deanero
http://massivelyfun.com
