3 engineers, 2 technicians, 2 assistants

1. Breakthrough Power Transformer
with ceramic insulation of winding
«If we did all the things we are capable of, we
would literally astound ourselves»
Thomas A.Edison
Vladimir Stepanchuk

2. 2. Market
Transformer applications
Power transformers Instrument transformers
Electric devices And other
(incl. welding transformers)

3. The world market by Grandview Research:
Power transformers:
2013: 11,375 units, total $18,55B
2020: 16,994 units, total $28,22B
The largest submarket: Asia (42%)
The largest suppliers: ABB Ltd., Alstom SA, Siemens Energy,
Toshiba Corp., GE Co., Crompton Greaves Ltd. etc.
Russia market
More then 10-12 bln. RUB*
The largest segment: transformers with power up to 100 kV*A
The largest suppliers of transformers with power up to 100 kV*A:
• «METZ V.I. Kozlova», Belarus, Minsk
• OJSC «ETK BirZST», Birobidzhan
• CJSC «Group Elektroshchit-TM Samara», Samara
2. Market
*Source: http://www.rus-trans.com/?ukey=auxpage_sovremennie-transformatory

4. 2. Market (transformer types)
Dry Oil
Insulation type Epoxy compounds, air and
others.
Oil
Market share in Russia up to 10% up to 90%
Cost high low
Reliability high low

5. 3. Problems of power transformer
Transformer with oil insulation:
The frequent occurrence of oil (the need for periodic monitoring)
Explosive
The need for protective structures, should not be placed near the human
flows
The need for frequent inspection (at least 1 time per quarter)
High operating costs for the Power Grid Company

6. Dry power Transformers:
Over time, the insulation material microcracks appear. They lead to
microbreakdown that entails eventually charring insulation
and short-circuiting the transformer (its failure)
Works range (-25C + 40C)
Afraid of dust
The need for frequent inspection (at least 1 time per quarter)
Expensive repair
High operating costs for the Power Grid Company
3. Problems of power transformer

7. 4. Solution – Ceramic Insulation
We invented low-cost, having no analogues in the world technology
of application of ceramic insulation thickness of 300 microns on a winding
of the transformer by micro-arc oxidation.
microarc oxidation (MAO), is an electrochemical surface treatment
process for generating oxide coatings on metals
Oxidation occurs simultaneously with the process of winding
𝑨𝒍 𝟐 𝑶 𝟑𝑨𝒍
Aluminium - metal Corrundum - ceramic
wire effective insulator

8. The advantages of ceramic insulation:
1. High, more than 0.9 winding factor (the ratio of total
conductor cross section (usually copper cross section) to
the area of the core window)
2. High temperature resistance;
3. High mechanical strength;
4. Radiation resistance;
5. Fire safety.
Aluminum wires in conjunction with ceramic insulation superior copper and
aluminium wires with dry or oil type of insulation on the mechanical and
temperature resistance.
4. Solution – Ceramic Insulation

9. Transformer 10kV/400V with power of 100 kV*A is one of the most common transformer on the
market. Comparison of new and existing types of transformers:
Features Dry
«ТСЛ-100/10»
Oil
«ТМГ11-100/10»
Ceramic Insulation
Short-circuit loss,
watt
1570 1970 not higher 750
No-load loss, watt 465 290 not higher 250
Efficiency at nominal
power, %
98 97,7 99
Efficiency under load
of 200% of nominal
- - 95
Temperature class F С (до 4500С)
Operating
temperature, 0С
От -45 до +40 От -60 до +40 От -70 до +150
Mass, kg 670 490 not higher 350 кг
Price (2015), th. RUB 253 120 до 300
5. Features of the New Transformer

10. Due to high insulating properties
of ceramics it is possible to use
very thin layer of ceramic that
provides a high (more than 0.9)
winding factor;
Small volume transformer
requires less material (steel) for
body
Winding density provides high
efficiency (low losses of electricity
power) even with aluminum wire,
comparable to dry and oil
transformers with copper windings
Reduce costs (aluminum is three
times cheaper than copper)
Low Cost Factors
5. Features of the New Transformer

11. 6. Applications
Transformer with ceramic insulation is beneficial in all areas
of traditional (oil and dry) transformer.
However, we want to highlight in particular:
The Far North and the zone of the tropics / subtropics
The possibility of the transformer to work at
wide temperature range (from -70C to + 70C) and any humidity
eliminating the need for design and construction,
installation of protective covers, booths, structures,
which gives substantial reduce in CAPEX
Transformers on drilling rigs
In conditions of relatively frequent changes
of location of the transformer, there is no need
to have housing for stabilize the temperature.
So this reduces CAPEX

12. Nuclear Power Plants
Transformer with ceramic insulation is absolutely radiation-resistant
in the United States at NPP there are widely used of radiation-resistant
«Nomex» insulation (provided by DuPont)
Nomex - an expensive synthetic aromatic polyamide, i.e. plastic.
Ceramic insulation has surely better performance
6. Applications

13. 7. Existing transformer prototype

14. 9. Next Steps
• Make transformer 10kV/400V with power of 100 kV*A
• Test it in cooperation with the Electric Grid Company
• Patent protection
• Demonstrate device to large transformer manufactures
(Siemens, ABB Ltd., etc.)
• Need Investment: 500 000 USD for 14 monthes
• Need partner: Electric Grid Company or
Transformer manufacturer

15. 8. Team
8 personы
Key persons:
CTO (author)
A.Nikiforov
Institute of Inorganic Chemistry of RAS (Novosibirsk)
17 years of tech-managerial experience in commercial structures.
Under his leadership, small companies made about ten scientific developments:
• technology for super-pure scandium and cesium,
• technology for production of absolute pure ethanol,
• power supplies for micro-arc oxidation,
• analyzer dispersion of solid particles in a liquid, and others.
CEO
Vladimir Stepanchuk
awarded honorary radio operator of the Russian Federation
5 years experience: director of venture fund
15 years of tech-backed companies management
Project manager
Ryabykh Viktor
7 years experience: project manager of innovation venture projects
