1. Simple Docker hosting on FIWARE Lab
Kenneth Nagin
IBM
Cloud Chapter Lead, FIWARE
nagin@il.ibm.com

5. FIWARE Lab Cloud Docker Hosting Overview
• Docker Hub: cloud service for managing and sharing Docker container images, including
FIWARE services, i.e. Generic Enablers (GEs) (http://catalogue.fiware.org/enablers);
• Docker Engine: creates and runs Docker containers; pulls/pushes images from/to
Docker Hub;
• Docker Compose: defines and runs multi-container applications;.
• Docker Swarm: manages a pool of Docker hosts using the full suite of Docker tools.
Because Docker Swarm serves the standard Docker API, any tool that already
communicates with a Docker daemon, e.g. Docker-Compose, can use Swarm to
transparently scale to multiple hosts.
• Docker Machine: creates and manages Docker hosts locally or on cloud providers
(including OpenStack). It can be used to create and manage Docker swam clusters.
• FIWARE Lab Docker Hosting: Docker Containers, Docker machines, and Docker Swarm
clusters can be hosted on the FIWARE lab, but remotely created and managed by local
Docker clients;
5

6. Simple Docker hosting on FIWARE
Remotely Managed by Docker Client
……
Region
….
Region
….
client
client
docker-engine
docker-machine
docker-compose
docker-swarm
docker api, openstack api, ssh
any tool based
on
docker-apidocker cli

7. Set up steps
1. Sign up fiware account (https://account.lab.fiware.org/sign_up/)
2. (Optionall) Request Community Upgrade
3. The orgranization automatically associated with your account must be able to
allocate at least on floating point IP and access at least one FIWARE region.
You can create other organizations.
4. In Cloud service
– Create Security Group that exposes ports for daemon, ssh, and any other
ports that are required.
– Allocated a floating point IP
5. Install docker and docker machine on your local computer
6. Use docker-machine to create hosts & swarm clusters on the desired FIWARE
regions
7

10. 10
FIWARE Set up: Add security group for docker-machine
SSH: Port 22
Docker Daemon Port 2376
Docker Swarm Master Port: 3376
Auto allocated user ports: 32768-
33768
Other User Ports e.g. 8080

11. 11
FIWARE set up: Allocate at least one public ip

12. 12
docker-machine create docker host on FIWARE
export OS_REGION_NAME=<fiware region> #e.g. 'Spain2’
export OS_TENANT_NAME=<user’s organization> #e.g. ‘username cloud’
export OS_USERNAME=<user’s email address> #e.g. ‘username@gmail.com’
export OS_PASSWORD=<user’s password>
Export OS_DOMAIN_NAME=‘default’
export OS_AUTH_URL='http://cloud.lab.fi-ware.org:4730/v2.0/'
export OS_AUTH_STRATEGY='keystone'

13. 13
docker-machine create docker host on fiware
$ docker-machine create -d openstack --openstack-flavor-id="2“
--openstack-image-name=“base_Ubuntu_14.04”
--openstack-net-name="node-int-net-01"
--openstack-floatingip-pool="public-ext-net-01"
--openstack-sec-groups="docker-machine-sg"
--openstack-ssh-user=“ubuntu”
FIWARE-SPAIN2
Don’t forget to configure the security group with all necessary ports.

15. 15
docker-machine ls

16. >eval “$(docker-machine env FIWARE-SPAIN2)”
>docker info

17. >eval $(docker-machine env FIWARE-SPAIN2)
>docker run hello-world

19. >eval $(docker-machine env FIWARE-SPAIN2)
>docker-compose up –d
>docker-compose ps
curl <FIWARE-SPAIN2 IP>:<EXPOSED PORT>
>curl <FIWARE-SPAIN2 IP>:<EXPOSED PORT>

21. 21
Docker create swarm container
Save token in $TOKEN
> docker

22. 22
Docker Swarm: create master
>export OS_REGION_NAME=Spain2
>docker-machine create -d openstack
--openstack-flavor-id="2"
--openstack-image-id=“base_Ubuntu_14.4”
--openstack-net-name="node-int-net-01"
--openstack-floatingip-pool="public-ext-net-01“
--openstack-sec-groups="docker-machine-sg"
--openstack-ssh-user=“ubuntu”
--swarm --swarm-master
--swarm-discovery token://$TOKEN
FIWARE-SPAIN2

23. 23
Docker Swarm: create agent
>export OS_REGION_NAME=Crete
>docker-machine create -d openstack
–-openstack-flavor-id="2"
--openstack-image-id=“base_Ubuntu_14.4”
--openstack-net-name="node-int-net-01"
--openstack-floatingip-pool="public-ext-net-01"
--openstack-sec-groups="docker-machine-sg“
--openstack-ssh-user=“ubuntu”
--swarm
--swarm-discovery token://$TOKEN
FIWARE-Crete

24. docker swarm
• docker-machine ls

25. >eval “$(docker-machine env --swarm FIWARE-SPAIN2)”
>docker info

26. >eval $(docker-machine env --swarm FIWARE-SPAIN2)
>docker run hello-world
>docker ps -a

27. >eval $(docker-machine env --swarm FIWARE-SPAIN2)
>docker-compose up -d
>docker ps
>curl http://147.27.60.99:32768/employees/resources/employees/

28. >eval $(docker-machine env --swarm FIWARE-SPAIN2)
>docker-compose stop
>docker-compose ps

29. Limitations
•labor-intensive for non-trivial environments
•security
•multi-tenancy
•scalability
•manageability
•limited Docker features (storage, network, etc)
•not production-ready (high availability, etc)
