OpenStack is the prevailing open source cloud software. It includes numerous API services for programmatic management of all sorts of IaaS and SaaS services. VMs, Containers, Bare Metal, Multi-tenancy. Use this platform to strike the right balance between developer self-service to your infrastructure and a well defined platform for next generation containerized microservice applications that your IT department feels happy to support and your CFO would be happy to pay for.

1. BUILD YOUR OWN
OPEN SOURCE CLOUD
Adrian Otto, Distinguished Architect

2. 2

3. ON DEMAND, SELF SERVICE
CLOUD
API + VMs + Containers + Bare Metal + Multi-Tenancy

4. PUBLIC CLOUD SERVICE
01: CLOUD
Pay a service provider, run your workloads there.

5. PRIVATE CLOUD
02: CLOUD
You own it, so you make the rules.

6. PUBLIC + PRIVATE CLOUD
03: HYBRID CLOUD
Decide what to run where, and have a consistent way to use both.

7. Use the right tool for the job
Containers
Consistent deployment to deploy your apps to a different destinations.
7
Containers
Public Cloud
Private Cloud
App

8. Use the right tool for the job
Containers
Consistent deployment to deploy your apps to a different destinations.
8
Containers
Public Cloud
App

10. ADRIAN OTTO

11. 11
Outline
Developer Self-Service, and Enabling NextGen Applications
Giving your developers access to API driven infrastructure, the business case
Overview of OpenStack
The prevailing open source cloud software
Deploying OpenStack
What tools to use to create your own cloud
Review
Questions and Answers

12. Compute, Networking, and Storage
12

13. OPENSTACK
SERVICES
IdentityImagesCompute
SDNObject StorageBlock Storage DNS Bare Metal
DashboardEncryptionTelemetry
BigDataDBaaSOrchestration Containers Queues
Layer 4: Consumption Services
Layer 3: Optional Enhancements
Layer 2: Extended Infrastructure
Layer 1: Base Compute Infrastructure
SDLC

14. OPENSTACK
SERVICES
KeystoneGlanceNova
NeutronSwiftCinder Designate Ironic
HorizonBarbicanCielometer
SaharaTroveHeat Magnum Marconi
Layer 4: Consumption Services
Layer 3: Optional Enhancements
Layer 2: Extended Infrastructure
Layer 1: Base Compute Infrastructure
Solum

15. BARE METALVM
DOCKER
OPENSTACK
KUBERNETES
MESOS
MAGNUM
DOCKER
API
K8S
API
MAGNUM OVERVIEW

16. Cloud operators assume a risk when
selecting a single cloud technology
today… but OpenStack is different.
16

17. OpenStack Contributor Statistics
17
3,716,027
Lines of code
6437
Contributors
336
Companies
715
Projects
1107
Years of Effort

18. 18
Outline
Developer Self-Service, and Enabling NextGen Applications
Giving your developers access to API driven infrastructure, the business case
Overview of OpenStack
The prevailing open source cloud software
Deploying OpenStack
What tools to use to create your own cloud
Review
Questions and Answers

19. ON DEMAND, SELF SERVICE
CLOUD
API + VMs + Containers + Bare Metal + Multi-Tenancy

20. WHY? BECAUSE SHADOW IT.
DEVELOPER SELF SERVICE
If you don’t offer it as a service, it’s going to happen anyway.

21. MICROSERVICE ARCHITECTURE
NEXTGEN APPLICATIONS
Immutable infrastructure, Container per component, 12-Factor apps

22. YOU KNOW YOU WANT IT
(subliminal message)
22

23. WHY?
MICROSERVICES
Continuous deployment, efficient scale, smaller lifts to upgrade. Agility.

24. THE SOFTWARE DEFINED ECONOMY
EVERY COMPANY IS BECOMING A SOFTWARE COMPANY

25. FAST
GOOD CHEAP
TODAY

26. FAST
TOMORROW
FAST FAST

27. UBER, THE WORLD’S LARGEST TAXI COMPANY, OWNS NO
VEHICLES. FACEBOOK, THE WORLD’S MOST POPULAR MEDIA
OWNER, CREATES NO CONTENT. ALIBABA, THE MOST
VALUABLE RETAILER, HAS NO INVENTORY. AND AIRBNB, THE
WORLD’S LARGEST ACCOMMODATION PROVIDER, OWNS NO
REAL ESTATE. SOMETHING INTERESTING IS HAPPENING.
27
— TECH CRUNCH, MARCH 2015

28. AGILITY IS THE SHIELD FOR DISRUPTION
And it can also be your weapon.
28

29. Summary of business case for private cloud
29
1
2
3
Shadow IT will happen if you don’t offer a developer self service option
Microservice software architecture for efficiency and agility reasons
Software defined economy means agility is essential to avoid disruption

30. 30
Outline
Developer Self-Service, and Enabling NextGen Applications
Giving your developers access to API driven infrastructure, the business case
Overview of OpenStack
The prevailing open source cloud software
Deploying OpenStack
What tools to use to create your own cloud
Review
Questions and Answers

31. 31
OpenStack Deployment Tools
Chef Recipes
If you love chef, there are recipes for OpenStack deployment
Puppet Modules
The traditional way to deploy a complex software system
Various Vendor Solutions
Fuel, Crowbar, Redhat OpenStack Platform, etc.
OpenStack Ansible (OSA)
Upstream managed project for container based OpenStack control plane using Ansible

32. 32
OpenStack Ansible (OSA)
•Deploy OpenStack in about 30 minutes
•Services run in lightweight system containers
•Easy to upgrade
•Community designed, developed, and managed
http://docs.openstack.org/developer/openstack-ansible/

34. OPENSTACK MAGNUM
How OpenStack can host your microservice applications
34

35. What is Magnum?
• Magnum is an OpenStack API that allows the use of your keystone credentials.
• Magnum is designed from the ground-up to be multi-tenant in both the cloud’s data
plane and control plane.
• Magnum allows for different container cluster types to be simultaneously run side-
by-side in the same cloud account, by the same tenant.
• Clusters are isolated from each other using groups of nova instances.
• When you want to upgrade your container runtime, you simply create a new cluster.
HOW IS THIS DIFFERENT THAN JUST RUNNING KUBERNETES OR DOCKER SWARM?
An OpenStack API Service that allows creation of container clusters
35

36. Terminology (1/4)
COE
Container Orchestration Engine.
Examples: Docker Swarm, Kubernetes, Apache Mesos.
36

37. Terminology (2/4)
Magnum Cluster
A Magnum cluster is an API resource in OpenStack Magnum that is composed of
nova instances, neutron networks, security groups, and other resources combined
using a heat stack. This is where your Container Orchestration Engine (COE) runs.
Clusters may be scaled up or down by adding or removing nodes from them. Heat
facilitates the setup and scaling of Clusters.
37
Cluster Cluster Cluster
COE COE COE
Nova
instance
Nova
instance
Nova
instance
Nova
instance
Nova
instance
Nova
instance

38. Terminology (3/4)
ClusterTemplate
A ClusterTemplate is a model used for creating a Cluster resource. It contains
information that is common among all clusters that are instantiated from it. Each
one uses a driver that defines a cluster type (swarm, kubernetes, mesos, etc.).
38
ClusterTemplate Cluster
Cluster
Cluster

39. Terminology (4/4)
Native Client
The client distributed with the COE. For example “docker” or “kubectl”. A native
client is not an OpenStack Client. It uses TLS to authenticate with the COE.
39
Cluster
COE
Nova
instance
Nova
instance
Nova
instance
Native
Client
TLS

40. Magnum Differentiators
40
Fundamental Design Goal
Docker Swarm, Kubernetes, Mesos
VM or Bare Metal
SSO Experience for Cloud Users
Multi-Tenant Control and Data Planes
Choice of COE
Choice of Server Flavor
Integrated with OpenStack

41. getcarina.com
Free Beta available today.

42. Why This Matters
42
1
2
3
Choice. Avoid locking into a single container orchestration tool
Speed. Easily create new container clusters in ~2 minutes
Agility. Iterate quickly on your software, and make small lifts.

43. 43
Outline
Developer Self-Service, and Enabling NextGen Applications
Giving your developers access to API driven infrastructure, the business case
Overview of OpenStack
The prevailing open source cloud software
Deploying an OpenStack
What tools to use to create your own cloud
Review
Questions and Answers

44. 44
Review
•You may need a private cloud just as much as you need a public one.
•Shadow IT will happen if you don’t offer a developer self service option
•Microservice software architecture for efficiency and agility reasons
•Software defined economy means agility is essential to avoid disruption
•One cloud == Myth.
•Use containers as a way to deploy apps to the cloud of your choice.
•OpenStack: prevailing open source cloud software
•Offers compute, networking, and storage (+715 modules for everything under the sun).
•Safe to bet on OpenStack because of diverse community & no single corporate sponsor.
•Offers quick and easy way to run different container orchestration environments.
•Many ways to deploy and run OpenStack
•OpenStack Ansible Recommended

45. O N E FA N AT I C A L P L AC E | S A N A N TO N I O , T X 7 8 21 8
