Security has become a top priority in cloud native, integration and microservices programing. Years of maintaining a good reputation could be irrecoverably damaged with a single security breach. Security is not an easy problem. It is easy to overlook something when attack patterns and security techniques evolve rapidly. What if the programming language you are using is aware of these security threats and keeps evolving along with new developments in the security landscape? The presentation discusses securing microservices and how Ballerina helps developers to write secure programs by providing inherent protection against threats listed in OWASP Top 10 Vulnerabilities and SANS Top 25 Software Errors. The session also includes demonstrations on the Ballerina compiler's security awareness features and how it prevents mistakes that could result in major security breaches.

1. Secure by Design Microservices & Integrations
Ayoma Wijethunga
Associate Technical Lead, WSO2

2. OWASP Top 10 Application Security Risks SANS TOP 25 Most Dangerous Software Errors
A1:2017 - Injection
Improper Neutralization of Special Elements used in an SQL
Command ('SQL Injection')
A2:2017 - Broken Authentication
Improper Neutralization of Special Elements used in an OS
Command ('OS Command Injection')
A3:2017 - Sensitive Data Exposure
Improper Neutralization of Input During Web Page Generation
('Cross-site Scripting')
A4:2017 - XML External Entities (XXE) Unrestricted Upload of File with Dangerous Type
A5:2017 - Broken Access Control Cross-Site Request Forgery (CSRF)
A6:2017 - Security Misconfiguration URL Redirection to Untrusted Site ('Open Redirect')
A7:2017 - Cross-Site Scripting (XSS)
Buffer Copy without Checking Size of Input ('Classic Buffer
Overflow')
A8:2017 - Insecure Deserialization
Improper Limitation of a Pathname to a Restricted Directory
('Path Traversal')
A9:2017 - Using Components with Known
Vulnerabilities
Download of Code Without Integrity Check
A10:2017 - Insufficient Logging & Monitoring Inclusion of Functionality from Untrusted Control Sphere
Use of Potentially Dangerous Function
Incorrect Calculation of Buffer Size
Uncontrolled Format String
… 12 more to go
Multitude of Application Security Risks & Growing

3. Security @ WSO2 - 1000 Foot View
* https://wso2.com/technical-reports/wso2-secure-engineering-guidelines
Security with Code &
Design Reviews
Static Code
Analysis
Dynamic Security
Analysis
IDE & Build Level
Checks
Secure Engineering
Guidelines *

4. Security @ WSO2 - Pain Points
○ Multiple iterations of checks to identify security mistakes
○ Finding an issue towards the end of the process is costly
○ False positives
○ Suppression & vulnerability management
○ WSO2 uses DefectDojo (customized)

5. Making Ballerina security-aware
○ Make language compiler aware of security risks
○ Detect and prevent unintentional security mistakes
○ Essential security features built-in to the language

6. Security Vulnerability Prevention
Taint Analysis

7. Every Function Has Security
Information Attached
public native function select
(@sensitive string sqlQuery,
typedesc? recordType,
boolean loadToMemory = false,
Param... parameters)
returns @tainted table|error;
@sensitive [parameter]
Security Sensitive Parameters
(Passing untrusted data to the
parameter can lead to a security risk)
returns @tainted
Returns Untrusted Data
Signature is derived
if not explicitly mentioned.
public native function read
(@sensitive int numberOfChars)
returns @tainted string|error;
public function execute
(@sensitive string httpVerb,
@sensitive string path,
Request|string|xml|json|byte[]
|io:ByteChannel|mime:Entity[]|()
message)
returns Response|error;
public native function getHeaders
(@sensitive string headerName)
returns @tainted string[];
ballerina/sql
ballerina/io
ballerina/http
ballerina/mime

8. Derived Security Information public native function select
(@sensitive string sqlQuery,
typedesc? recordType,
boolean loadToMemory = false,
Param... parameters)
returns @tainted table|error;
baseSqlQuery and sortColumn
derived to be "security sensitive"
public function sortedSelect (string
baseSqlQuery, string sortColumn)
returns table|error {
return dbclient->select(baseSqlQuery
+ " ORDER BY " + sortColumn, ());
}

9. Language Compiler
Performs Taint Analysis
Ballerina Compiler
Taint Analyze
Code Analyze
Code Generation
Desugar
Type Check
Compiler Plugin
Ballerina can:
Segregating untrusted
data from trusted data
Ballerina knows:
Security sensitive areas
Ballerina can:
Accurately propagate
tainted state across the
program
Evolves with the
language

10. SQL Injection Prevention
Demo
sql:Parameter param_id = { sqlType:
sql:TYPE_INTEGER, value: params.id };
var selectRet = testDB->select
("SELECT * FROM student WHERE id = ?", (),
param_id);
match selectRet {
table tableReturned => {
if (td.hasNext()) {
res.setPayload("Found!");
} else {
res.setPayload("Not Found!");
}
td.close();
}
error err => throw err;
}
var params = req.getQueryParams();
var selectRet = testDB->select
("SELECT * FROM student WHERE id = "
+ params.id, ());
match selectRet {
table tableReturned => {
if (td.hasNext()) {
res.setPayload("Found!");
} else {
res.setPayload("Not Found!");
}
td.close();
}
error err => throw err;
}
Correct Approach:
error: ./sqli_fail.bal:23:40: tainted value passed to
sensitive parameter 'sqlQuery'

11. Cross Site Scripting (XSS)
Prevention Demo
import ballerina/http;
string regex = "[a-zA-Z]+";
service<http:Service> hello bind {port: 9090} {
sayHello(endpoint c, http:Request req) {
http:Response res = new;
var params = req.getQueryParams();
if (check params.name.matches(regex)) {
res.setPayload("Hello, "
+ untaint params.name + "!");
} else {
res.setPayload("Name contains
invalid data!");
}
_ = c->respond(res);
}
}
import ballerina/http;
service<http:Service> hello bind {port: 9090} {
sayHello(endpoint c, http:Request req) {
var params = req.getQueryParams();
_ = c->respond("Hello, " + params.name
);
}
}
error: ./http_fail.bal:9:25: tainted value passed to
sensitive parameter 'message'
Correct Approach:

12. Security Vulnerability Prevention
Secure Defaults

13. XML External Entity Injection
(XXE) Prevention Demo
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE foo [
<!ELEMENT foo ANY >
<!ENTITY xxe SYSTEM "file:///etc/passwd">
]>
<foo>&xxe;</foo>
This XML will expose the content
of /etc/passwd file.

14. XML Entity Expansion
Prevention
<?xml version="1.0"?>
<!DOCTYPE lolz [
<!ENTITY lol "lol">
<!ENTITY lol2 "&lol;&lol;&lol;&lol;&lol;&lol;">
<!ENTITY lol3 "&lol2;&lol2;&lol2;&lol2;&lol2;">
<!ENTITY lol4 "&lol3;&lol3;&lol3;&lol3;&lol3;">
<!ENTITY lol5 "&lol4;&lol4;&lol4;&lol4;&lol4;">
<!ENTITY lol6 "&lol5;&lol5;&lol5;&lol5;&lol5;">
<!ENTITY lol7 "&lol6;&lol6;&lol6;&lol6;&lol6;">
<!ENTITY lol8 "&lol7;&lol7;&lol7;&lol7;&lol7;">
<!ENTITY lol9 "&lol8;&lol8;&lol8;&lol8;&lol8;">
]>
<lolz>&lol9;</lolz>
Parsing the XML will result in DoS
attack, since parser will expand all
the entities.

15. Securing Microservices
Built-in Security Features

16. Built-in Security Features
○ OCSP validation for SSL/TLS certificates
○ CRL validation for SSL/TLS certificates
○ Config API reading encrypted passwords or secrets
○ Cryptographic operations
○ Authentication and authorization for services

17. Securing Microservices
Authentication & Authorization

18. Inbound Authentication & Authorization
Authentication
Filter
Authorization
Filter
Authentication
Provider
Resource
Request
Basic Auth
OAuth
JWT
Certificate
Response
HTTP JMS
Config File
LDAP
AD
DB
User Storage

19. Inbound Authentication
& Authorization - Basic Auth import ballerina/http;
endpoint http:SecureListener ep {
port:9090
};
@http:ServiceConfig {
basePath: "/hello",
authConfig: { scopes: [ "hello" ] }
}
service<http:Service> helloWorld bind ep {
@http:ResourceConfig {
methods: [ "GET" ],
path: "/"
}
sayHello (endpoint c, http:Request r) {
_ = c -> respond("Hello!");
}
}
http:AuthProvider configured to
use "config" file as the user store.
Endpoint is configured to use the
http:AuthProvider
@http:ServiceConfig is configured
to authorize users with scope
"hello"

20. Inbound Authentication
& Authorization - JWT Auth
http:AuthProvider jwtAuthProvider = {
scheme: "jwt",
issuer: "ballerina",
audience: "ballerina.io",
clockSkew: 10,
certificateAlias: "ballerina",
trustStore: {
path: "/home/ops/truststore.p12",
password: "t4C3F5WrFbQn6h4S"
}
};
endpoint http:SecureListener ep {
port:9090,
authProviders: [ jwtAuthProvider ]
};
http:AuthProvider configured to
use enforce authentication using
"jwt" scheme.

21. Outbound Authentication endpoint http:Client downstreamServiceEP {
url: "https://localhost:9092",
auth: { scheme: http:JWT_AUTH },
};
endpoint http:Client downstreamServiceEP {
url: "https://localhost:9092",
auth: {
scheme: http:OAUTH2,
accessToken: "34060588",
refreshToken: "15160398",
refreshUrl: "https://ballerina.io/ref"
clientId: "rgfKVdnMQnJSSr",
clientSecret: "BRebJ0aqfclQB9"
},
}
endpoint http:Client downstreamServiceEP {
url: "https://localhost:9092",
auth: {
scheme: http:BASIC_AUTH,
username: "downstreamServiceUser",
password: "QK1eIWH5d6UaZXA3"
}
Client endpoint can be configured
with the desired authentication
scheme.
JWT Authentication
OAuth2 Authentication
Basic Authentication

22. Summary
○ Taint Analysis
○ Secure Defaults
○ Security Features
○ Authentication and Authorization
"How to Write Secure Ballerina Programs"
https://ballerina.io/learn/how-to-write-secure-ballerina-code
