The document discusses various design smells that negatively impact software quality attributes like reusability, changeability, understandability and extensibility. It covers different categories of design smells including abstraction smells, encapsulation smells and modularization smells. Some examples of specific smells discussed are missing abstraction, leaky encapsulation, broken modularization etc. The document emphasizes the importance of addressing design smells through refactoring to improve design quality and reduce technical debt.

1. Girish Suryanarayana, Tushar Sharma, Ganesh Samarthyam

2. 2
Outline
Introduction
Design smells
Abstraction
smells
Encapsulation
smells
Modularization
smells
Hierarchy smells
Refactoring
Process and
Tools

3. 3
Why care about software quality?
Poor software quality
costs more than $150 billion
per annum in U.S.
and greater than $500 billion
per annum worldwide
- Capers Jones

4. Capers Jones on design errors in industrial software
* http://sqgne.org/presentations/2012-13/Jones-Sep-2012.pdf
0
20
40
60
80
100
120
IBM
Corportation
(MVS)
SPR Corporation
(Client Studies)
TRW
Corporation
MITRE
Corporation
Nippon Electric
Corp
PercentageContribution
Industry Data on Defect Origins
Adminstrative Errors
Documentation Errors
Bad Fixes
Coding Errors
Design Errors
Requirements Errors
Up to 64% of software defects can be traced back
to errors in software design in enterprise software!

5. 5
Why care about design quality?
Poor software quality
costs more than $150
billion per year in U.S. and
greater than $500 billion
per year worldwide
The debt that accrues when
you knowingly or unknowingly
make wrong or non-optimal
design decisions
Software
Quality
Technical
Debt
Design
Quality
Design Quality means changeability,
extensibility, understandability, reusability, …

6. 6
Technical debt
“Technical debt is the debt that accrues
when you knowingly or unknowingly make
wrong or non-optimal design decisions”
Reference: Refatoring for Software Design Smells– Girish et al Morgan Kaufman 2014

7. 7
Why care about technical debt?
Global 'IT Debt' as $500 billion
for the year 2010, with
potential to grow to $1 trillion
by 2015
- Gartner

8. 8
Why care about technical debt?
Reference: Zen and the art of software quality – Jim Highsmith Agile 2009 conference

9. 9
What constitutes technical debt?
…
Code debt
Static
analysis tool
violations
Inconsistent
coding style
Design debt
Design smells
Violations of
design rules
Test debt
Lack of tests
Inadequate
test coverage
Documentation
debt
No
documentation
for important
concerns
Outdated
documentation

10. 10
Outline
Introduction
Design smells
Abstraction
smells
Encapsulation
smells
Modularization
smells
Hierarchy smells
Refactoring
Process and
Tools

11. 11
Why care about smells?
Impacted Quality
 Reusability
 Changeability
 Understandability
 Extensibility
 Testability
 Reliability
Product
Quality
Design
Quality
Design
Smells
Impacted Quality
 Maintainability:
Affected by
changeability &
extensibility
 Reliability: Impacted
by poor
understandability
 …
Indicators
 Rigidity & Fragility
 Immobility & Opacity
 Needless complexity
 Needless repetition
 …

12. 12
Why care about refactoring?
As an evolving program is
continually changed, its
complexity, reflecting
deteriorating structure,
increases unless work is done
to maintain or reduce it
- Lehman's law of Increasing
Complexity

13. 13
What are design smells?
“Design smells are certain structures in the
design that indicate
violation of fundamental design principles
and
negatively impact design quality”
Reference: Refatoring for Software Design Smells– Girish et al Morgan Kaufman 2014

14. 14
What is design quality?
Quality
Attribute
Definition
Understandability The ease with which the design fragment can be comprehended.
Changeability
The ease with which a design fragment can be modified (without causing
ripple effects) when an existing functionality is changed.
Extensibility
The ease with which a design fragment can be enhanced or extended (without
ripple effects) for supporting new functionality.
Reusability
The ease with which a design fragment can be used in a problem context other
than the one for which the design fragment was originally developed.
Testability
The ease with which a design fragment supports the detection of defects
within it via testing.
Reliability
The extent to which the design fragment supports the correct realization of
the functionality and helps guard against the introduction of runtime
problems.

15. “Design smells” aka…

16. 16
So, what causes design smells?

17. 17
Most common cause of design smells

18. 18
Another cause: not adhering to processes

19. 19
Why should we focus on smells?
A good designer is one who
knows the design solutions
A GREAT designer is one who
understands the impact of
design smells and knows how to
address them

20. 20
Design smells as violations of fundamental principles
What do smells indicate?
Violations of
fundamental design
principles
We use Booch’s fundamental
principles for classification
and naming of smells
This helps identify cause of
the smell and potential
refactoring as well

21. 21
Design principles used to classify design smells
DesignPrinciples
Abstraction
Encapsulation
Modularization
Hierarchy

22. 22
Design principles and enabling techniques
PHAME: Principles of Hierarchy, Abstraction, Modularization and Encapsulation

23. 23
What is refactoring?
Refactoring (noun): a change
made to the internal structure of
software to make it easier to
understand and cheaper to
modify without changing its
observable behavior
Refactor (verb): to restructure
software by applying a series
of refactorings without
changing its observable
behavior

24. 24
A note on examples in this presentation
Almost all examples are from real-world software
Most examples are from OpenJDK 7.0 (open source)
Examples from industrial software are “sanitized” – they do not reveal
anything about where they came from…
All illustrations are mostly as UML diagrams so no need to know Java
Though you’ll appreciate them more if you are from a Java background
A few code examples are in Java, because JAVA is the most widely
used language
They are simple enough for people of any programming background to
understand

25. 25
Scope/Focus: Only structural design smells

26. 26

27. 27
Outline
Introduction
Design smells
Abstraction
smells
Encapsulation
smells
Modularization
smells
Hierarchy smells
Refactoring
Process and
Tools

28. 28
The principle of abstraction
“The principle of abstraction advocates the simplification of entities
through reduction and generalization: reduction is by elimination of
unnecessary details and generalization is by identification and
specification of common and important characteristics”

29. 29
Enabling techniques for abstraction

30. 30
public class Throwable {
// following method is available from Java 1.0 version.
// Prints the stack trace as a string to standard output
// for processing a stack trace,
// we need to write regular expressions
public void printStackTrace();
// other methods omitted
}

31. 31
Missing abstraction
This smell arises when clumps of data or encoded strings are used
instead of creating a class or an interface.

32. 32
Refactoring for missing abstraction smell
public class Throwable {
// following method is available from Java 1.0 version.
// Prints the stack trace as a string to standard output
// for processing a stack trace,
// we need to write regular expressions
public void printStackTrace();
// other methods omitted
}
public class Throwable {
public void printStackTrace();
public StackTraceElement[] getStackTrace(); // Since 1.4
// other methods omitted
}
public final class StackTraceElement {
public String getFileName();
public int getLineNumber();
public String getClassName();
public String getMethodName();
public boolean isNativeMethod();
}

33. 33

34. 34
Imperative abstraction
This smell arises when an operation is turned into a class.
This smell manifests as a class that has only one method defined
within the class. At times, the class name itself may be identical to
the one method defined within it.

35. 35
Refactoring imperative abstraction smell

36. 36

37. 37
Incomplete abstraction
• This smell arises when a type does not support a responsibility completely
• Specifically, the public interface of the type is incomplete in that it does not
support all behavior needed by objects of its type

38. 38
Incomplete abstraction – Example
In this case, the MutableTreeNode
supports only setUserObject but no
corresponding getUserObject (which is
provided in its derived class!)
Hence, MutableTreeNode has
Incomplete Abstraction smell
How to fix it? Provide all the necessary
and relevant methods required for
satisfying a responsibility completely in
the class itself
In case of public APIs (as in this case), it
is often “too late” to fix it!

39. 39
Another example

40. 40
How to refactor & in future avoid this smell?
For each abstraction (especially in public interface) look out for symmetrical
methods or methods that go together
For example, methods for comparing equality of objects and getting
hash code (in Java/C#)
Look out for missing matching methods in symmetrical methods (see table)
min/max open/close create/destroy get/set
read/write print/scan first/last begin/end
start/stop lock/unlock show/hide up/down
source/target insert/delete first/last push/pull
enable/disable acquire/release left/right on/off

41. 41
The Abstract Factory pattern

42. 42
java.util.Calendar
In addition to methods
supporting dates, the class
has methods for supporting
time as well!

43. 43
Multi-faceted abstraction
This smell arises when an abstraction has more than one
responsibility assigned to it.

44. 44
Refactoring for multifaceted abstraction smell

45. 45
public class FormattableFlags {
// Explicit instantiation of this class is prohibited.
private FormattableFlags() {}
/** Left-justifies the output. */
public static final int LEFT_JUSTIFY = 1<<0; // '-'
/** Converts the output to upper case */
public static final int UPPERCASE = 1<<1; // 'S'
/**Requires the output to use an alternate form. */
public static final int ALTERNATE = 1<<2; // '#'
}

46. 46
class Currency {
public static String DOLLAR = "u0024";
public static String EURO = "u20AC";
public static String RUPEE = "u20B9";
public static String YEN = "u00A5";
// no other members in this class
}

47. 47
Unnecessary abstraction
The smell occurs when an abstraction gets introduced in a software
design which is actually not needed and thus could have been avoided.

48. 48
Unused abstract
classes in an
application

49. 49
Unutilized abstraction
This smell arises when an abstraction is left unused (either not
directly used or not reachable).
Two forms:
• Unreferenced abstractions – Concrete classes that are not
being used by anyone
• Orphan abstractions – Stand-alone interfaces/abstract classes
that do not have any derived abstractions

50. 50
Refactoring for unutilized abstraction

51. 51

52. 52
• executing objects of type ActionEvent at
specified intervals
javax.swing.Timer
• scheduling a thread to execute in the future as a
background thread
java.util.Timer
• sending out an alarm to wake-up the listeners
that have registered to get timer notifications
javax.management.timer.
Timer

53. 53
/*
* Note on casts to double below. If the arithmetic of
* x+w or y+h is done in float, then some bits may be
* lost if the binary exponents of x/y and w/h are not
* similar. By converting to double before the addition
* we force the addition to be carried out in double to
* avoid rounding error in the comparison.
*
* See bug 4320890 for problems that this inaccuracy causes.
*/
/*
* Note on casts to double below. If the arithmetic of
* x+w or y+h is done in int, then we may get integer
* overflow. By converting to double before the addition
* we force the addition to be carried out in double to
* avoid overflow in the comparison.
*
* See bug 4320890 for problems that this can cause.
*/
Rectangle2D class Rectangle class

54. 54
Duplicate abstraction
This smell arises when two or more abstractions have identical
names or identical implementation or both.

55. 55

56. 56
Types of clones
• exactly identical except for variations in whitespace, layout, and
comments
Type 1
• syntactically identical except for variation in symbol names, whitespace,
layout, and comments
Type 2
• identical except some statements changed, added, or removed
Type 3
• when the fragments are semantically identical but implemented by
syntactic variants
Type 4

57. 57
Refactoring for Date example

58. 58
SummaryofSmellsViolatingAbstraction

59. 59
Outline
Introduction
Design smells
Abstraction
smells
Encapsulation
smells
Modularization
smells
Hierarchy smells
Refactoring
Process and
Tools

60. 60
The principle of encapsulation
“The principle of encapsulation advocates separation of concerns and
information hiding through techniques such as hiding implementation
details of abstractions and hiding variations”

61. 61
Enabling techniques for encapsulation

62. 62

63. 63
Lenient encapsulation
This design smell arises when the hiding is deficient so that clients
can access the implementation aspects of the abstraction directly
(An abstraction should expose only the interface to the clients
and hide the implementation details.)

64. 64
Lenient encapsulation – Example
The java.awt.Rectangle class has 4
pubic fields: x, y, width, and height
in addition to public getter and
setter methods for these fields!
Smell since the accessibility of
its members is more permissive
(i.e., are declared public) than
actually required (i.e., they are
required to be declared private)
Refactoring suggestion: Make all
data members private
Lenient
encapsulation
Insufficient
modularization

65. 65

66. 66
Case study: Use of global variable “current” in Linux

67. 67

68. 68

69. 69
Leaky encapsulation
This smell arises when an abstraction “exposes” or “leaks”
implementation details through its public interface.

70. 70
Refactoring leaky encapsulation smell

71. 71

72. 72

73. 73
Missing encapsulation
This smell occurs when the encapsulation of implementation
variations in a type or hierarchy is missing.

74. 74
How about this refactoring?

75. 75
Refactoring missing encapsulation smell

76. 76
Refactoring missing encapsulation smell

77. 77
switch (transferType) {
case DataBuffer.TYPE_BYTE:
byte bdata[] = (byte[])inData;
pixel = bdata[0] & 0xff;
length = bdata.length;
break;
case DataBuffer.TYPE_USHORT:
short sdata[] = (short[])inData;
pixel = sdata[0] & 0xffff;
length = sdata.length;
break;
case DataBuffer.TYPE_INT:
int idata[] = (int[])inData;
pixel = idata[0];
length = idata.length;
break;
default:
throw new UnsupportedOperationException("This method has not been "+ "implemented
for transferType " + transferType);
}

78. 78
Unexploited encapsulation
This smell arises when client code uses explicit type checks (using
chained if-else or switch statements that check for the type of the
object) instead of exploiting the variation in types already
encapsulated within a hierarchy.

79. 79
Refactoring unexploited encapsulation smell
protected int transferType; protected DataBuffer dataBuffer;
pixel = dataBuffer.getPixel();
length = dataBuffer.getSize();
switch (transferType) {
case DataBuffer.TYPE_BYTE:
byte bdata[] = (byte[])inData;
pixel = bdata[0] & 0xff;
length = bdata.length;
break;
case DataBuffer.TYPE_USHORT:
short sdata[] = (short[])inData;
pixel = sdata[0] & 0xffff;
length = sdata.length;
break;
case DataBuffer.TYPE_INT:
int idata[] = (int[])inData;
pixel = idata[0];
length = idata.length;
break;
default:
throw new UnsupportedOperationException("This method
has not been "+ "implemented for transferType " +
transferType);
}

80. 80
Summary of Smells Violating Encapsulation

81. 81
Outline
Introduction
Design smells
Abstraction
smells
Encapsulation
smells
Modularization
smells
Hierarchy smells
Refactoring
Process and
Tools

82. 82
The principle of modularization
“The principle of modularization advocates the creation of
cohesive and loosely coupled abstractions through
techniques such as localization and decomposition”

83. 83
Enabling techniques for modularization

84. 84

85. 85
Broken modularization
This smell arises when members of an abstraction are broken and
spread across multiple abstractions (when ideally they should
have been localized into a single abstraction).
Two forms of this smell:
• Data and methods that ideally belong to an abstraction are
split among two or more abstractions.
• Methods that ideally belong to abstraction are split among
two or more abstractions.

86. 86
Suggested refactoring for broken modularization

87. 87
Refactoring for broken modularization smell

88. 88

89. 89

90. 90
Insufficient modularization
This smell arises when an existing abstraction could be further
decomposed thereby reducing its interface size, implementation
complexity or both.
Two variants:
a) When an abstraction has a large number of members in its interface, its
implementation, or both
b) When an abstraction has one or more methods with excessive complexity

91. 91
Insufficient modularization – Example
The abstract class java.awt.Component is an
example of insufficient modularization
It is a massive class with 332 methods
(of which 259 are public!)
11 nested/inner classes
107 fields (including constants)
source file spans 10,102 lines of code!
The Component serves as a base class and
the hierarchy is deep
Derived classes inherit the members =>
life is quite difficult!

92. 92

93. 93

94. 94

95. 95

96. 96
Cyclically-dependent modularization
This smell arises when two or more class-level abstractions depend
on each other directly or indirectly (creating a tight coupling among
the abstractions).
(This smell is commonly known as “cyclic dependencies”)

97. 97
Refactoring cyclically-dependent modularization

98. 98
Refactoring cyclically-dependent modularization

99. 99
Refactoring cyclically-dependent modularization

100. 100
Refactoring cyclically-dependent modularization

101. 101
Refactoring cyclically-dependent modularization

102. 102
Refactoring cyclically-dependent modularization

103. 103
Refactoring cyclically-dependent modularization

104. 104
Practical consideration: unit cycles

105. 105

106. 106

107. 107
Hub-like modularization
This smell arises when a class-level abstraction has dependencies
with large number of other class-level abstractions (high incoming
as well as outgoing dependencies).

108. 108
Summary of Smells Violating Modularization

109. 109
Outline
Introduction
Design smells
Abstraction
smells
Encapsulation
smells
Modularization
smells
Hierarchy smells
Refactoring
Process and
Tools

110. 110
The principle of hierarchy
“The principle of hierarchy advocates the creation of a
hierarchical organization of abstractions using techniques such
as classification, generalization, substitutability, and ordering”

111. 111
Enabling techniques for hierarchy

112. 112

113. 113

114. 114
Unfactored hierarchy
This smell arises when the types in a hierarchy share unnecessary
duplication in the hierarchy.
Two forms of this smell:
• Duplication in sibling types
• Duplication in super and subtypes

115. 115
A refactoring for missing intermediate types

116. 116
Refactoring for unfactored hierarchy

117. 117
Refactoring for unfactored hierarchy

118. 118
public Insets getBorderInsets(Component c, Insets insets){
Insets margin = null;
// Ideally we'd have an interface defined for classes which
// support margins (to avoid this hackery), but we've
// decided against it for simplicity
//
if (c instanceof AbstractButton) {
margin = ((AbstractButton)c).getMargin();
} else if (c instanceof JToolBar) {
margin = ((JToolBar)c).getMargin();
} else if (c instanceof JTextComponent) {
margin = ((JTextComponent)c).getMargin();
}
// rest of the code omitted …

119. 119
Missing hierarchy
This smell arises when an abstraction uses conditional logic to
determine behavior where a hierarchy could have been formed to
exploit variation in behavior.

120. 120
Refactoring for missing hierarchy

121. 121
Refactoring for missing hierarchy
margin = c.getMargin();
if (c instanceof AbstractButton) {
margin = ((AbstractButton)c).getMargin();
} else if (c instanceof JToolBar) {
margin = ((JToolBar)c).getMargin();
} else if (c instanceof JTextComponent) {
margin = ((JTextComponent)c).getMargin();
}

122. 122

123. 123

124. 124
Deep hierarchy
This smell arises when an inheritance hierarchy is excessively deep.

125. 125
Refactoring for deep hierarchy

126. 126
Refactoring for deep hierarchy
/**
* Pluggable look and feel interface for JButton.
*/
public abstract class ButtonUI extends ComponentUI {
}

127. 127

128. 128
Wide hierarchy
This smell arises when an inheritance hierarchy is “too” wide and
shallow indicating missing intermediate abstractions.

129. 129
Suggested refactoring for wide hierarchy

130. 130

131. 131
Rebellious hierarchy
This smell arises when a subtype rejects the methods
provided by its supertype(s).

132. 132
How about this refactoring for rebellious hierarchy?

133. 133
How about this refactoring for rebellious hierarchy?

134. 134
How about this refactoring for rebellious hierarchy?

135. 135
Dealing with addComponent() in Composite pattern

136. 136

137. 137

138. 138

139. 139
Broken hierarchy
This smell arises when the base abstraction and its derived
abstraction(s) conceptually do not share “IS-A” relationship
(resulting in broken substitutability).
This design smell arises when inheritance is used wrongly instead of
using composition.

140. 140
Liskov’s Substitution Principle (LSP)
It should be possible to replace
objects of supertype with
objects of subtypes without
altering the desired behavior of
the program
Barbara Liskov

141. 141
Refactoring broken hierarchy

142. 142
Refactoring broken hierarchy

143. 143

144. 144
Multipath hierarchy
This smell arises when a subtype inherits both directly
as well as indirectly from a supertype leading to
unnecessary inheritance paths in the hierarchy.

145. 145
Suggested refactoring for multipath hierarchy

146. 146
How about multiple interface inheritance?

147. 147
Real-world example

148. 148

149. 149

150. 150
Unnecessary hierarchy
This smell arises when an inheritance hierarchy has one or more unnecessary
abstractions. Includes the following cases:
• all the subtypes are unnecessary (i.e., inappropriate use of inheritance)
• supertype has only one subtype (i.e., speculative generalization)
• intermediate types are unnecessary

151. 151
Refactoring unnecessary hierarchy

152. 152
Refactoring unnecessary hierarchy

153. 153
Refactoring unnecessary hierarchy

154. 154
Refactoring unnecessary hierarchy

155. 155
Practical considerations: language limitations

156. 156

157. 157
Speculative hierarchy
This smell arises when one or more types in a hierarchy are provided speculatively
(i.e., based on imagined needs rather than real requirements)

158. 158
Refactoring for speculative hierarchy

159. 159

160. 160
Cyclic hierarchy
This smell arises when a supertype in a hierarchy
depends on any of its subtypes.

161. 161
Suggested refactoring for cyclic hierarchy

162. 162
SummaryofSmellsViolatingHierarchy

163. 163
How to improve design quality in practice?

164. 164
Refactoring process model

165. 165
Suggested Reading

166. 166
More on design smells?

167. 167
Key take-aways
 Technical debt accrues when you knowingly or unknowingly make
wrong or non-optimal design decisions
 Design smells indicate violation of fundamental design principles
Also, design smells negatively impact design quality
 We need to care about technical debt
 Accumulating debt will lead to “technical bankruptcy”
 Refactoring is the primary means to repay technical debt

168. 168
Key take-aways
 Apply fundamental design principles (such as abstraction,
encapsulation, modularization, and hierarchy) to create high-
quality software
 Smells are related: they tend to co-occur, amplify the effect of
other smells, or can indicate deeper design problems
 Use the IMPaCT process model to identify/mark, prioritize,
and refactor design smells in practice

169. 169
Design principles and enabling techniques

170. 170

171. 171
Thank you!

172. Girish Suryanarayana, Tushar Sharma, Ganesh Samarthyam
