1. WELCOME TO SEMINAR OnJK PRODUCTS

2. JK White Cement Product Portfolio Your Smile.. Our Satisfaction

3. J K WHITE CEMENT Gotan , Rajasthan

4. The Organization“JK White Cement Works “Started the Production Of White Cement in 1984 at GOTAN (Rajasthan) using the DRY PROCESS technology in Technical Expertise from F.L. Smidth & Company – DenmarkProduction Capacity of 3,00,000 MT of White Cement Per Annum

5. ISO – 9001:2000and 14001 Certified Company by LRQA

6. OHSAS 18001: 2005 For safety and environmental upkeep

7. Quality control by FUZZY Logic & QCX which control the RMP( Raw Mill Proportionate) for the consistency of White Cement

8. Innovator for new technology and energy conservation

9. The Factory is Situated at Gotan (Raj.) having one of the Best known source of Chemically Pure High Grade Lime stone which is a key ingredient of White Cement ( reserves for next 50 years)JK White Cement Your Smile.. Our Satisfaction

10. PRODUCTION CHART

11. JK White CementUsage Flooring with White cementWalls with White cementPlastering Decorative/UtilityArchitectural Your Smile.. Our Satisfaction

12. Flooring with ..JK White Cement(Under bed for marble) Your Smile.. Our SatisfactionMarble Being Translucent will reflect part of the background. Hence a white base will Enhance the whiteness of the Marble which Can Be Achieved using JK White Cement

13. Flooring with ..JK White Cement(Mosaic/In Situ/Pavers) Your Smile.. Our SatisfactionMosaic TlesDifferent Colors

14. Designs

15. Durability ,dense

16. Water tight

17. Hard wearing surface

18. Made & fixed with white cementTerrazo Flooring In-Situ Terrazzo

19. Wide variety of patterns

20. Various color schemes using the white cement with pigmentsPavement Blocks Used for road markings, pavements , parking lots, foot path & any landscaping ApplicationWalls with .. JK White Cement( Cement Wash and Designer Wall Tiles ) Your Smile.. Our SatisfactionWhite Washing with JK White CementWhite wash with white cement gives more life as it is an integral part of the wallDoes not stain clothes.Superior results obtained by applying PuttyDesigner Wall tiles in JK White CementMade using white cement Designs of your choice and imagination

21. Walls with ..JK White Cement( Cement Paint ) Your Smile.. Our SatisfactionIS SpecificationsIS: 5410:1992Reaffirmed -1999Composition: As per ISWhite Portland cement : 65% (min) Hydrated lime : 25% (max) Pigments and other materials : Depends on properties (i.e. Alkali resistant, Water repellants, Hygroscopic salts and Fungicides ) Application Substrate:Porous surfaces like Masonry Concrete, Rough plaster except gypsum plasterCement paints are material consisting of White Portland cement and other ingredients like lime, pigments, Hygroscopic salts, water repellants, fungicides, etc (>65% White Cement)Cement Paints have better performance than distemper paints for out door protection and decoration of building as long as they are manufactured as per BIS StandardsAbsence of organic binding materials and the fungi static action of cement paint were considered important hence incorporated. Cement Paint Uses White cement is widely used for decorative water-proof cement paint

22. For interiors and exteriors

23. Superior results with puttyPlaster with .. JK White Cement Your Smile.. Our SatisfactionSand Face Spray PlasterFor interiors & exteriorsApplied with manual or pneumatic machineNo primer Required Permanent Finish /Low MaintenanceExpose Aggregiate PlasterCement & colored aggregatesAggregates when exposed from plasters Gives an attractive natural lookStone or flint aggregates can be white or colored or a mixture, to suit designNo primer RequiredPermanent Finish/Low Maintenance

24. Plaster with ..JK White Cement Your Smile.. Our SatisfactionTextured PlasterTextured coating applied on exterior for decoration & protection.Texture is made by chiseling.( Malad Stone)Variety of colors with pigment addition to white cementPlain PlasterPlain plaster without any texture.Variety of colors with pigment addition to white cement.Plastering is done on grey cement plaster surface which is made rough by combingRoller Finished PlasterSpecial textured rollers are used to give textured & uniform pattern.Immense design variation possibilities.Variety of colors with pigment addition to white cement.

25. Plaster with ..JK White Cement Your Smile.. Our SatisfactionSponge Finished PlasterSponge is used to obtain a special pattern on surface

26. Sponge patterns varies with applied pressure and hardness of sponge

27. Various colors with pigment addition

28. Popular for ceiling jobsDecorative/Utility Uses with.. JK White Cement Your Smile.. Our Satisfaction China MosaicBroken pieces of glazed tiles are fixed with in desired pattern

29. Applied on terrace, parapet walls, swimming pools

30. Water repellency is served Italia MosaicUsed on exteriors walls of building for decoration & protection

31. Also on columns & floors

32. Glass pieces fixed with white cement Area Markers/Road Dividers/Zebra Crossings White color of cement Make it a long term solution for Road Divider ( outer layer).

33. Zebra crossing layed with white cement & other area markers for parking can give permanent service Pointing On Brick Work /Stone Work Pointing means filling of joints between bricks/stones with white cement & colored cement mortar

34. Imparts beauty as well as protectionArchitectural With..JK White Cement Your Smile.. Our SatisfactionOrnamental ArticlesNotable application is in the moulding of sculptures or ornamental motifs.PreCast Panels GRC( Glass Reinforced Cement)New Technology Ready to use panels of any design

35. White or colored panels with different designs and patterns joined together at site to speed up construction

36. Equipment is needed to handle and place the panels

37. Panels of any size and can be smooth or textured as desired.

38. Pillars , Jhalis ,Stone finishes , etc available at a lower cost and in your desired Colour

39. Made to order /Tailor made to suit your requirementJK White Wall Putty Your Smile.. Our Satisfaction

40. TYPES OF WALL PUTTY JK HASJK WALL PUTTY (FINE)JK WALL PUTTY ( COARSE)

41. JK Wall Putty (FINE) Your Smile.. Our SatisfactionJK Wall Putty ( Skim Coats)

42. For luxurious and silky interior/exterior finish

43. Good adhesion with Plastered wall ( Cement to Cement Adhesion)

44. No primer

45. No Flaking and long life

46. Better glaze & lower consumption of paint compared to traditional puttiesWhy JK Wall Putty? Your Smile.. Our SatisfactionWhite Cement BasedProper Adhesion to PlasterBecomes Integral Part of PlasterVery High Durability and Life Imparts additional Strength and prevents Flaking in case of seepageCan be used for Internal as well as external Surfaces

47. Advantages Over Traditional Putty (POP)

48. Properties Your Smile.. Our SatisfactionTransverse Strength - 1.7 Kg/cm2Compressive Strength - 37 Kg/cm2 ( 28 days)Whiteness Index - 93% (28 days) Pot life - 180 MinutesWater demand by volume - 35 to 40 %Surface hardness - 3.0 NMaximum thickness of total - 1.5- 2.5 mm coatsCoverage - 15 Sq Feet/Kg in 2 coats*Subject to wall condition /Roughness and usage

49. JK COARSE PUTTYUSED IN UNDULATED SURFACE THICKNESS – 4 MM MINIMUMMICRO SAND INCLUDED IN THIS PUTTYSPECIAL PRODUCT AVAILABLE IN 20 KG BAGS.FINAL FINISH WITH FINE PUTTY ONLY.WIDELY USED IN TEXTURE FINISHES IN ELEVATIONS.CAN GO UPTO 8MM THICKNESS IN 2 COATS.

50. JK WALL PUTTY..Surface Preparation Your Smile.. Our SatisfactionSurface PreparationThe surface should be cleaned to make it free from dirt, dust, grease, oil and paint. All foreign impurities should be removed with a wire-brush. Wall surfaces should be cured so that the surface is saturated with water yet in ‘touch dry’ condition.Treatment of New Surface The new surface requires only soft treatment such as removal of dust, dirt and foreign matter. In case of cracks, voids and damages; it should be patched up prior to application of J. K. Wall Putty with grey/white cement.Treatment of Old SurfaceAll loose material and/ or organic growth must be removed with Putty blade or brush. In case of old painted surface scrub the surface with coarse emery stone/paper.

51. JK WALL PUTTY..Application Your Smile.. Our SatisfactionPreparation of J.K. Wall Putty PasteJ. K. Wall Putty is a fine powder. Mix slowly J. K. Wall Putty with approx. 40% water by volume to prepare paste of desired consistency. Mix vigorously for 5-10 minutes for making lump free, uniform and smooth putty paste. Product should be mixed in required quantities to be used within 2-3 hrs of its preparation.ApplicationApply uniformly the first coat of J.K. Wall Putty with blade/trowel on the wall from bottom to top. Apply second coat after the first coat has dried completely(Min 6 hrs). Limit the total thickness of 2 coats to 2.5 mm. Allow complete drying and then use fine emery paper to remove the application mark if any. Any kind of paint can be applied on this surface. Use water for curing before applying paint.PrecautionAlthough J.K. Wall Putty does not contain any toxic material, use rubber gloves while mixing, as prolonged exposure with water may soften the skin resulting in fine cuts/legions due to cement particles. Precaution should be taken to avoid dust inhalation while handling the powder putty.StorageStore J.K. Wall Putty in a dry place and open the pack just before use. Keep out of reach of children.

52. Third Party Certification Your Smile.. Our SatisfactionThe Authentication… NCCBM Certification

53. Satisfied Clients ..INDIATextile MillsNuclear Power Project -KudankulamDelhi MetroRelianceIIT KanpurPWDJUSCOIJM Hyderabad Your Smile.. Our SatisfactionMahindra Gesco

54. Pharma Industry

55. Uttar Pradesh State Building Corporation

56. Unitech

57. Marathon

58. Merlin

59. Shipra

60. …………………Recent ProjectsJAIN HOUSINGProjectSunder bansArea-52 Lacs SqftChennai

61. L&TPROJECT-COGNIZANT MEPZAREA-25LACS SQFTARCHITECT- Mr.Karthikeyan & Nagalingam.CONTRACOR-OVIYASLOCATION-TAMBARAM SANITORIUM, CHENNAI

63. CEEBROS PROPERTIES&DEVELOPMENTPROJECT-CEEBROS HOTELSArea-10 LACS SqftNANDANAM, CHENNAI

64. SOUTH INDIAN SHELTERSPROJECT-SAFAAAREA-7.50 LACS SQFTCONTRACTOR-ABSOLUTE MKTGARCHITECT- Akbar Hussain AkbariLOCATION-GUDUVANCHERY, OUTSKIRTS CHENNAI

65. SRM UNIVERSITYAREA-10 LACS SQFTLOCATION-VANDALORE, OUTSKIRTS CHENNAI

66. ARUNEXCELLOPROJECTECSTANCIAAREA-50 LACS SqftCONTRACTORSROYAL DESIGNS&SAIRAM CORPORATIONARCHITECT-NATRAJ&VENKATVELLANCHERRY, OUTSKIRTS CHENNAI

67. EMAARPROJECT-MGF EMAAR AREA-7 LACS SQFTCONTRACTOR-OVIYASARCHITECT-CHAKRAPANIatTONDIARPET, CHENNAI

68. EXPRESS INFRASTRUCTUREEXPRESS AVENUEContractor - Mr. Phillip of IN-DECORS, Exteriorat MOUNT ROAD, CHENNAI

70. NAVINHOUSING,DAYTONHEIGHTSArea-6.5 Lac sqft, Architect Mr.W.Anand, at Nelson Manickam Road Chennai,ContractorMr.Gandhi ofG-ENTERPRISES

71. Some Testimonials Your Smile.. Our Satisfaction

72. Putty Finishes Interiors Your Smile.. Our Satisfaction

73. Putty Finishes Exterior Your Smile.. Our Satisfaction

74. JK Water Proofing Compound Your Smile.. Our Satisfaction

75. Your Smile.. Our SatisfactionIt is a water repellant powder that does not allow water to percolate through the Pores and voids which are prevalent in Normal cement mix caused by capillary actionJK Water Proofing CompoundWhat Does it Do?Without WPCWith WPC

76. Your Smile.. Our SatisfactionJ.K. Waterproof reacts with alkalis in the concrete forming a highly water-repelling compound in the capillaries and throughout the concrete or mortar. In this way, the surface tension, which would normally draw water into the capillaries and micro cracks does not take place and does not allow propagation of Moisture How does it Work?

77. BIS Standards Your Smile.. Our SatisfactionIS- 2645-2003

78. Strength to be >90% of Neat cement 3 Day strength

79. Setting time –Reduction of setting time should not be >25% of Neat Cement

80. Water Permeability should be <50% of Neat Cement

81. Chloride test should be < 2%JK Water Proofing more than meets the BIS Specifications and is IS Certified( IS 4410 ??)

82. Your Smile.. Our Satisfaction Mixing RatioMixed with cement in a ratio of 2% by weight ( 1kg for every 50 kg Bag)

83. Onsite Test For Effective Water Proofing Compound Your Smile.. Our SatisfactionDispersion Test

84. Mercury Test

85. Match stick TestSome Usages of JK Water Proofing Compound Your Smile.. Our SatisfactionJ.K. Waterproof can be used for following construction activities: -1.Under bed of foundation or entire raft foundation.2. At Damp Proof Coarse (DPC) level.3. Concrete Roads 4.All under-ground halls, basements or water storage tanks.5. Swimming pools6. Concreting and masonry work for toilets, bathrooms and kitchens.7. The external plaster of the walls which falls across the normal rain direction of that area.8.Construction in coastal areas.9.Bridges and Fly overs.And where you can think of…………….

86. THANK YOU..Any Questions Please….
