The document discusses Linux security concepts including user accounts, file permissions, groups, auditing, and PAM authentication. It covers the three layers of the Linux OS - the kernel layer, system layer, and user layer. The kernel layer houses core OS resources while the system and user layers provide interfaces and services to users and applications. Access is controlled through permissions assigned to files and directories for different user categories. Security features like auditing and PAM help enforce access controls and authenticate users.

1. Presented by:
Gurpreet Kaur
1-1

2. Linux OS can be represented in the following sphere with
three layers:
• User Layer
• System Layer
• Kernel Layer
Kernel Layer houses all the operating system resources such as file systems,
memory managements, input/output modules and libraries. The outer layer, system
land hosts system resources such as Application System Interface (API).
1-2

3. Problems start when normal users have controlled
or could access the kernel, it is a very bad situation.
By expanding the basic standard security features
we have:
1. User and group separation
2. File system security
3. Audit trails
4. PAM authentication
1-3

4. User accounts are used to verify the identity of the person using a
computer system.
Through username and password credentials, the system is able to
determine if the user is permitted to log into the system and, if so,
which resources the user is allowed to access.
Groups are logical constructs that can be used to group user
accounts together for a particular purpose.
Through group creation and assignment of privileges, access to
restricted resources can be controlled for those who need them and
denied to others.
1-4

5. Access to an application or file is granted based on the permission
settings for the file.
There are three permissions for files, directories, and applications.
Symbol Description
r Indicates that a given category of user can read a file.
w Indicates that a given category of user can write to a file.
x Indicates that a given category of user can execute the file.
- A fourth symbol indicates that no access is permitted.
Each of the three permissions is assigned to three defined categories of users
Category Description
Owner The owner of the file or application.
Group The group that owns the file or application.
Everyone All users with access to the system.
1-5

6. Example:
-rwxrwxr-x 1 kambing kambing 0 Sep 2 12:25 foo
The permissions for this file are listed at the start of the line, starting
with set of rwx.
This first set of symbols defines owner access.
The next set of rwx symbols define group access,
The last set of symbols defining access permitted for all other users.
This listing indicates that the file is readable, writable, and executable by
the user who owns the file (user kambing) as well as the group owning the
file (which is a group named kambing). The file is also world-readable and
world-executable, but not world-writable.
1-6

7. A very true statement of a UNIX/Linux system, everything is a file; if
something is not a file, it is a process.
Symbol Meaning
- Regular file
d Directory
l Link
c Special file
s Socket
p Named pipe
b Block device
For each category of users, read, write and execute permissions can be
granted or denied. Files without permissions don't exist on Linux
1-7

8. ls -l Mine
-rw-rw-r-- 1 mike users 5 Jul 15 12:39 Mine
The file is a regular file Users with user name mike or users belonging to
the group users can read and write (change/move/delete) the file, but they
can't execute it .
All other users are only allowed to read this file, but they can't write or
execute it
ls -l /bin/ls
-rwxr-xr-x 1 root root 45948 Aug 10 15:01 /bin/ls*
Executable file, the difference is everybody can run this program, but you
need to be root to change it.
1-8

9. The security scheme takes care of user access to programs; it can serve files on
a need-to-know basis or least privilege and protect sensitive data such as home
directories and system configuration files.
We can use the chmod command to modify the file permission, changing of the
access mode of a file. The chmod command can be used with alphanumeric or
numeric options
>chmod u+rwx,go-rwx hello
The + and - operators are used to grant or deny a given right to a given group. It
makes the file a private file to user.
1-9

10. A record showing who has accessed a computer system and what operations
he or she has performed during a given period of time.
Linux kernel 2.6 comes with auditd daemon. It’s responsible for writing
audit records to the disk. During startup, the rules in /etc/audit.rules are
read by this daemon.
You can open /etc/audit.rules file and make changes such as setup audit file
log location and other option.
1-10

11. In order to use audit facility you need to use following utilities:
auditctl
A command to assist controlling the kernel’s audit system. You can
get status, and add or delete rules into kernel audit system
ausearch
A command that can query the audit daemon logs based for events
based on different search criteria.
aureport
A tool that produces summary reports of the audit system logs.
1-11

12. Pluggable Authentication Modules (PAM) was invented by SUN Microsystems.
Linux-PAM provides a flexible mechanism for authenticating users.
It consists of a set of libraries that handle the authentication tasks of
applications on the system.
The library provides a stable general interface to which privilege-granting
programs (such as login) defer to perform standard authentication tasks.
Programs supporting PAM must dynamically link themselves to the modules
in charge of authentication.
The administrator is in charge of the configuration and the attachment order
of modules.
All applications using PAM must have a configuration file in /etc/pam.d.
1-12

13. Each file is composed of four columns:
Module type
 auth: user authentication
 account: user restriction (e.g.: hour restriction)
 session: tasks to perform at login and logout e.g.: mounting directories
 password: update of the user authentication token
success control
 required: a least one of the required modules
 requisite: all the requisite modules
 sufficient: only one sufficient module
 optional: a least one of the required modules is necessary if no other has
succeeded
path to the module
Usually /lib/security.
optional arguments -
1-13

14. Proxy servers are software applications that run on your firewall machine in
order to provide indirect Internet access to your network.
The proxy server takes a packet from inside your network and changes the
“from” address to its own address.
It then forwards the packet to the destination host.
The destination host thinks it is talking only to the firewall.
When the firewall receives the response from the destination host, the
proxy server sends the packet back to the original requesting machine.
A proxy server that passes requests and responses unmodified is usually
called a gateway or sometimes tunneling proxy.
1-14

15. Advantages
This method is a big advantage when you access FTP sites that do double-
reverse lookups. If the IP address( of the host from DNS server) it receives
from this last lookup does not match the requesting one or if the DNS lookup
failed to find any entries, the server denies access.
When you have to manage several machines across your network,
keeping all the entries up to date can be a daunting task. With a proxy
server in place, your entire network appears to come from the IP
address of the proxy server, thus reducing the total number of properly
configured DNS entries you need.
Another advantage of using a proxy server is that since all outbound traffic
must pass through the firewall, as an administrator, you can monitor which
types of Internet activity are occurring. The proxy server has very robust
logging capabilities which allow you to see who is accessing what on the
Internet. Attempted access from the outside is also logged closely.
1-15

16.  To keep machines behind it anonymous, mainly for security.
 To speed up access to resources (using caching). Web proxies are commonly
used to cache web pages from a web server.
 To apply access policy to network services or content, e.g. to block undesired
sites.
 To access sites prohibited or filtered by your ISP or institution.
 To log / audit usage, i.e. to provide company employee Internet usage reporting.
 To bypass security / parental controls.
 To circumvent Internet filtering to access content otherwise blocked by
governments.
 To scan transmitted content for malware before delivery.
 To scan outbound content, e.g., for data loss prevention.
 To allow a web site to make web requests to externally hosted resources (e.g.
images, music files, etc.) when cross-domain restrictions prohibit the web site from
linking directly to the outside domains.
1-16

17. A proxy server can be placed in the user's local computer or at various points
between the user and the destination servers on the Internet.
Forward proxy
Open proxy
Reverse Proxy
1-17

18. A forward proxy taking requests from an internal network and forwarding them to
the Internet.
Forward proxies are proxies where the client server names the target server to
connect to.
Forward proxies are able to retrieve from a wide range of sources (in most
cases anywhere on the Internet).
User Proxy Internet
1-18 Internal Network

19. An open proxy forwarding requests from and to anywhere on the Internet.
An open proxy is a forwarding proxy server that is accessible by any
Internet user.
An anonymous open proxy allows users to conceal their IP
address while using other Internet services.
Internet Proxy Internet
1-19

20. A reverse proxy (or surrogate) is a proxy server that appears to clients to
be an ordinary server.
Requests are forwarded to one or more origin servers which handle the request.
The response is returned as if it came directly from the proxy server.
A reverse proxy taking requests from the Internet and forwarding them to servers
in an internal network. Those making requests connect to the proxy and may not
be aware of the internal network.
User Proxy Internet
Internal Network
1-20

21. Reverse proxies are installed in the neighborhood of one or more web
servers.
All traffic coming from the Internet and with a destination of one of the
neighborhood's web servers goes through the proxy server.
A reverse proxy is (usually) an Internet-facing proxy used as a front-
end to control and protect access to a server on a private network,
commonly also performing tasks such as load-balancing,
authentication, decryption or caching.
1-21

22. mail - send and receive mail
Mail is an intelligent mail processing system, which has a command
syntax with lines replaced by messages.
This command starts up the mail utility and prints a summary line for
each email message currently in your mail box.
There is now a new prompt (&), at which you can enter any of the mail
commands.
1-22

23. SYNOPSIS
mail [-iInv ] [-s subject ] [-c cc-addr ] [-b bcc-addr ] to-addr...
mail [-iInNv -f ] [name ]
mail [-iInNv [-u user ] ]
-v
Verbose mode. The details of delivery are displayed on the user's
terminal.
-i
Ignore tty interrupt signals. This is particularly useful when using mail on
noisy phone lines.
-I
Forces mail to run in interactive mode even when input isn't a terminal. In
particular, the `~ ' special character when sending mail is only active
in interactive mode.
-n
Inhibits reading /etc/mail.rc upon startup.
-N
Inhibits the initial display of message headers when reading mail or
editing a mail folder.
1-23

24. -s
Specify subject on command line (only the first argument after the -s flag is
used as a subject; be careful to quote subjects containing spaces.)
-c
Send carbon copies to list of users.
-b
Send blind carbon copies to list List should be a comma-separated list of
names.
-f
Read in the contents of your mbox (or the specified file) for processing; when
you quit mail writes undeleted messages back to this file.
-u
Is equivalent to:
mail -f /var/spool/mail/user
1-24

25. Sending mail
To send a message to one or more people, mail can be invoked with
arguments which are the names of people to whom the mail will be sent
& mail goofy@domain.com
Type in your message.
When you are finished you hit Ctrl-d to exit the editor.
The system then gives you the option specify "Cc" recepients.
Hitting "return" will send the message off.
1-25

26. Reading mail
In normal usage mail is given no arguments and checks your mail out of
the post office, then prints out a one line header of each message found.
The current message is initially the first message (numbered 1) and can be
printed using the print command (which can be abbreviated `p ' ) .
You can move among the messages much as you move between lines,
with the commands `+ ' and `- ' moving backwards and forwards, and
simple numbers.
Mail version 8.1.2 01/15/2001. Type ? for help.
"/var/mail/jhaas": 2 messages 2 unread
>U 1 jhaas@beethoven Sun Nov 11 15:31 17/500 test2
U 2 jhaas@beethoven Sun Nov 11 15:34 17/500 test4
&
The following command displays the content of the second message:
&2
You can reply to this message by entering "r" and hitting the return key:
&r
1-26

27. Ending a mail processing session.
You can end a mail session with the quit `q ' ) command. Messages which have
been examined go to your mbox file unless they have been deleted in which
case they are discarded.
1-27
