OpUtils Free training

Welcome to the
OpUtils free training
session
© 2019, Zoho Corp., ManageEngine - All rights
reserved.

PLEASE CONFIRM BY COMMENTING ON THE CHAT PANEL
Can you hear me?
Can you see the
presentation?
reserved.

reserved.
Trainer
Srikanth V
Product Expert
ManageEngine OpUtils

• Introduction to OpUtils
• IP address and switch port management
• Rogue Device Detection
• Bandwidth monitor tool and config file manager
• Troubleshooting tools in OpUtils
TRAINING AGENDA
reserved.

CHALLENGES FACED BY NETWORK ENGINEERS
reserved.
• No track of IP address or switch ports
• Rogue intrusion and network data breach
• Messy network
• Unable to keep up with organization growth and
• Unable to keep up with the network changes

INTRODUCTION TO
OPUTILS
reserved.

WHAT IS OPUTILS?
• ManageEngine OpUtils is an efficient IP address
and Switch port management software that helps
network engineers to monitor their switches and IP
address space with ease.
• This integrated solution plays a very important role
in detecting rogue device intrusion and block them if
necessary.
• It also has other tools that help in monitoring
bandwidth usage and taking backup of configuration
files(Startup/Running) for CISCO devices.
reserved.

PREREQUISITES FOR INSTALLING
OPUTILS
reserved.
System Requirements
https://www.manageengine.com/products/oputils/help/system-requirements.html

IP ADDRESS
MANAGEMENT
reserved.

IP ADDRESS MANAGER
reserved.
• Provides the real time visibility and the control on IP-Addresses in your network .
• Keeps track of all the IP addresses(available, used and reserved).
• Tracks related IP address details.
• Hierarchically tree view.
• View the status of the IP address at a glance
• Active directory integration with multi-domain controller support.

• Manual Addition
1) IPv4 Address
- Group Name
- Subnet Mask, Subnet Name, Subnet/Network address
2) Switches (In case of Licensed switches, after switch addition IP and
subnets gets added.
3) Microsoft DHCP
• Bulk Addition
- Import from CSV
SUBNET DISCOVERY / ADDITION
reserved.

SWITCH PORT
MANAGEMENT
reserved.

• Identify switch ports connected to a device
• Show MAC and IP's of devices attached to the physical port of the switches.
• Gain visibility into the IP, MAC, VLAN, status and availability of ports.
• View the operational status and speed of each port.
• Audits the track of changes.
• Automatically collects the MAC, IP and DNS details.
SWITCH PORT MAPPER (SPM)
reserved.

• Manual Addition
- Group Name
- Switch Name
• Bulk Addition
- Import from CSV
• Discovery
- Start IP to End IP range
Note: Credentials must be added in advance or must be added while adding
switches. It is of two sub divisions namely
1) SNMP v1/v2[community for SNMP v1 and v2 devices]
2) SNMP v3 [Username and password for monitoring v3 devices]
DISCOVERY AND ADDITION OF SWITCHES/PORTS
reserved.

ROGUE DEVICE
DETECTION
reserved.

ROGUE DEVICE DETECTION
reserved.
• Detect unauthorized access of network resources.
• Periodically scans the routers and subnets
• Lists all the devices discovered in the network.
• The administrator verifies and marks valid systems.
• Ability to mark devices as trusted, guest, and rogue.
• Alerts when status of device changes

ADDING TRUSTED DEVICES
• IP addresses can also be discovered by importing a CSV file containing MAC addresses.
• All MAC addresses imported will be automatically marked as 'Trusted'.

BANDWIDTH MONITOR
AND CONFIG FILE
MANAGER
reserved.

Bandwidth Monitor Tool
• Bandwidth monitor tool provides the real time network traffic of any SNMP device both at interface-
level and at the device-level.
• The bandwidth utilization of the device displays a comparison of the individual traffic of it interfaces.
Configuration File Manager
• Config file manager tool helps to maintain the Startup and Running configurations of the Cisco devices.
(Router/Switch).
• It is used to take backup of the Running and Startup configuration files from the CISCO devices and is
also used to compare the configuration files.
Note : These tools are only present in the Standalone product and not in Add-on.
A GIST OF OTHER FEATURES IN OPUTILS
reserved.

5 SET OF ESSENTIAL TOOLS THAT IS NEEDED
FOR TROUBLESHOOTING YOUR NETWORK
reserved.
* ManageEngine OpUtils has
more than 30 tools and thus
helping in better management of
your network.

SCHEDULE, CONFIGURE AND
REPORT

• One popular method of preventing rogue devices from having
unrestricted access to your network is to scan your office for
wireless devices on a daily, weekly, or monthly basis.
• Hence periodic scanning of network is essential for the safety
of our network.
• Scheduled scanning of the subnets, switch ports, Config file
manager and MAC-to-IP mapping can be done in OpUtils for
maintaining a list of devices enters and leaves our network.
SCHEDULE SCANS USING A SCHEDULER
reserved.

• Configure alert profile in oputils to indicate the change in status of any specific device
Settings > Email Notification > IP Address Manager/ Switch Port Mapper / Rogue detection/Network
monitor / Bandwidth Monitor
• View all alarms and events by severity
• Get notified of faults or change in device status via email.
CONFIGURING ALERTS
reserved.

• Reports section in OpUtils help in
generating reports which helps in
decision making processes.
• It also provides a record of processes.
• In OpUtils, there are a wide variety of
reports which covers a wide record of
processes.
Reports > IP address manager/Switch
port Mapper / Audit
REPORT GENERATION
reserved.

1) Replace your Spreadsheet records
2) Centralized Management and Custom column
3) Global search feature unavailable in Spreadsheet
4) Eliminates the need of manually tracing the network cables.
5) Block/Unblock rogues accordingly
6) Email Alerts to track status change
7) Generation of Reports
8) Capacity Planning tool
HOW DOES OPUTILS HELP YOU WITH
YOUR NETWORK?
reserved.
OpUtils
Uses

reserved.
Wanna know more? Go ahead and check the following
✶ Website : www.oputils.com
✶ Brochure : https://download.manageengine.com/products/oputils/oputils_brochure.pdf
✶ Datasheet : https://download.manageengine.com/products/oputils/oputils_datasheet.pdf
✶ Support : oputils-support@manageengine.com
✶ Help document : help.oputils.com
✶ Live online demo : demo.oputils.com
✶ Knowledge base : https://www.manageengine.com/products/oputils/knowledge-base.html
✶ Forums : https://pitstop.manageengine.com/portal/community/opmanager/oputils
HAS OPUTILS PIQUED YOUR INTEREST?

The art and science of asking
questions is the source of all
knowledge
Have Questions? We have
answers.
Q&A with our product
experts
reserved.

Does Oputils provide a report that has combination of both
IP address manager and Switch port mapper's data ?
reserved.

Can we change the name of subnet groups after adding it in the
heirarchy tree ?
reserved.

What is the use of history tab under subnet summary page ?
reserved.

How is OpUtils Licensed?
reserved.

Can any network devices and Servers be monitored using Bandwidth
monitor?
reserved.

What is the polling interval for network monitor tool ?
reserved.

Can I block a port on particular switch using OpUtils ?
reserved.

How can I add more information such as serial number of switch under sumary
page ?
reserved.

What credentials does an user needs to add a DHCP server ?
reserved.

What is the difference between discovered and trusted devices
under rogue detection tool?
reserved.

Detach yourself from Rogue intrusion
and IP handling problems!
Thank You
reserved.
