This document discusses discrete mathematical structures and propositional logic. It introduces topics like normal forms, negation normal form, disjunctive normal form, and conjunctive normal form. These normal forms are syntactic restrictions on logical formulas. The document provides examples of converting formulas to different normal forms using truth tables. It also describes how to derive the disjunctive and conjunctive normal forms of compound propositions.

1. DISCRETE MATHEMATICAL STRUCTRES
Mr Ch Viswanatha Sarma
M.Sc,M.Phil,M.Tech (Ph.D.)
Asst.Prof
Department of Computer Science and Engineering
Department of Computer Science and Engineering
Course: Discrete Mathematical Structures

2. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
2
❖ Logic
❖ Mathematical Logic
➢ Propositional Logic
■ Syntax of PL
● Statements
● Logical Connectivities
● Truth Tables
◆ Tautology
◆ Contradiction
■ Semantics of PL
■ Logical Equivalences
Summary of Previous Lecture

3. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
3
Normal Forms
❖ A normal form of formulae is a syntactic restriction
such that for every formula of logic, there is an
equivalent formula in the restricted form.
❖ Each formula must use only ¬, ∨, and ∧

4. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
4
Normal Forms
Disjunctive Normal
Form
Negation Normal
Form
Conjunctive Normal
Form
Types

5. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
5
Terminology used in normal forms
❖ Propositional variables are also referred as atom
❖ A literal is either an atom or its negation
❖ A clause is a disjunction of literals.

6. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
6
Negation Normal Form (NNF)
❖ A formula is in NNF if ¬ appears only in front of the
propositional variables.
Example : In NNF: ¬A ∧ ¬B
Not in NNF: ¬(A ∨ B)

7. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
7
Transformation into NNF
Any formula can be transformed into an equivalent
formula in NNF by pushing ¬ inwards.
● ¬¬F ≡ F
● ¬(F ∧ G) ≡ (¬F ∨ ¬G)
● ¬(F ∨ G) ≡ (¬F ∧ ¬G)

8. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
8
Examples of NNF
1. Convert (¬(A ∧ ¬B) ∧ C) in NNF
2. Convert ¬(r V¬(¬p ∧q)) in NNF

9. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
9
Disjunctive Normal Form (DNF)
❖ A minterm is a conjunction of literals in which each
variable is represented exactly once.
Example : Given two simple propositions p and q,
p∧ q, p∧ ¬q, ¬p∧ ¬q, ¬p∧ q are minterms of p and q
❖ Each minterm is true for exactly one assignment.

10. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
10
Disjunctive Normal Form (DNF)
A disjunction of minterms is called Disjunctive
Normal Form.
i.e.; (p∧ q) ∨ (¬p ∧ q ∧ r) ∨ (¬ p∧r )
A disjunction of minterms is true only if at least one
of its constituents minterms is true
Definition

11. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
11
From truth table to DNF
❖ If a function, e.g. F, is given by a truth table,
determine exactly for which assignments it is true.
❖ We can select the minterms that make the function
true and form the disjunction of these minterms.

12. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
12
From truth table to DNF
F is true for three assignments:
DNF of F :
( p∧ q ∧ r ) ∨ ( p ∧ ¬q ∧ r ) ∨
(¬ p ∧ ¬q ∧ r)
p q r F
1 1 1 1
1 1 0 0
1 0 1 1
1 0 0 0
0 1 1 0
0 1 0 0
0 0 1 1
0 0 0 0

13. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
13
Convert the compound proposition p → (q ∧ r ) into DNFExample
p q r q ∧ r p → (q ∧ r )
1 1 1 1 1
1 1 0 0 0
1 0 1 0 0
1 0 0 0 0
0 1 1 1 1
0 1 0 0 1
0 0 1 0 1
0 0 0 0 1

14. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
14
From the above table, we getExample

15. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
15
Find the DNF of the compound proposition ¬ ( p→(q ∧ r))Example

16. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
16
Conjunctive Normal Form (CNF)
❖ A clause is a disjunction of literals in which each
variable is represented exactly once.
Example : Given two simple propositions p and q,
pV q, pV ¬q, ¬pV ¬q, ¬pV q are clauses of p and q
.

17. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
17
Conjunctive Normal Form (CNF)
A conjunction of one or more clauses is called
conjunctive Normal Form.
i.e.; (p ∨q) ∧ (¬p V q V r) ∧ (¬ p V r )
Definition

18. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
18
From truth table to CNF
❖ If a function, e.g. F, is given by a truth table,
determine exactly for which assignments it is False.
❖ We can select the minterms that make the function
false and form the disjunction of these minterms.
❖ Then take the complement of disjunction of these
minterms.

19. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
19
From truth table to CNF
p q r F
1 1 1 1
1 1 0 0
1 0 1 1
1 0 0 0
0 1 1 0
0 1 0 0
0 0 1 1
0 0 0 0

20. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
20
Example:
Find the Conjunctive normal form of compound
proposition (p→q)→(¬r∧q)
Sol :

21. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
21
Example:
Find the Conjunctive normal form of compound
proposition ((p ∧ q) ∨ (r ∧ s)) ∨ (¬q ∧ (p ∨ t))
Sol :

22. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
22
Example:

23. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
23
Example:

24. Department of Computer Science and Engineering
Course: Discrete Mathematical Structures
24
Example:
