This document describes a new method for 2D and 3D object detection and classification for autonomous vehicles using LiDAR and camera (CCD) sensors. It proposes generating object proposals from LiDAR point cloud data by filtering points, projecting them to 2D, and segmenting edges. The proposals are then classified using R-FCN neural network on the CCD image. Class labels from R-FCN are mapped back to edge points to determine the 3D orientation and expand the bounding box for occluded regions. Evaluation on KITTI dataset shows it achieves accurate and fast object detection compared to previous methods.
