This document discusses how to implement live streaming in Android applications using FFmpeg and Vitamio. It describes how RTSP and RTP protocols are used for live streaming. It provides steps for building FFmpeg with H264 and AAC encoders. It explains how to send video and audio streams from an RTSP server to a client using FFmpeg, and how to receive and play those streams on the client using Vitamio and AudioTrack. Code examples are given for setting up the RTSP server and client communication. The document concludes by advertising an upcoming Android developer conference.

2. Live Streaming in Android
Ahmet Oğuz Mermerkaya
Software Developer
Aselsan
@mekya84
ahmetmermerkaya@gmail.com

3. *
Ahmet Oğuz Mermerkaya
● Writer of an Android Application Programming book,
Merhaba Android, in Turkish
● Member of GDG Ankara
● Software Developer in Aselsan, Defense Industry
Company in Turkiye

4. *
Outline
● How live streaming works
● Building FFmpeg(with x264 and fdk-aac)
● Using Vitamio MediaPlayer
● Implementing a RTSP Server
● Sending Previews and Audio From RTSP Server
● Receiving and Playing Audio On Client

5. *
How live streaming works
● RTSP (Real Time Streaming Protocol)
● RTP (Real Time Protocol)

6. *
How live streaming works
● RTSP (Real Time Streaming Protocol)
● RTP (Real Time Protocol)
This is the
part FFmpeg
takes place

7. *
What is FFmpeg?
● Open-source, cross-platform multimedia framework
● Supports almost all codecs and formats(H264, H263,
AAC, AMR, MP4, MP3, AVI)
● Streams Audio and Video
ffmpeg.org

8. *
Building FFmpeg
● Download
o FFmpeg (http://fmpeg.org)
o fdk_aac for using AAC encoder
(http://sourceforge.net/projects/opencore-amr/files/fdk-aac/)
o libx264 source code for H264 encoder
(http://www.videolan.org/developers/x264.html)
o Android NDK for cross compiling(http://developer.android.com)
● Configure & Make

9. *
Building FFmpeg - Configure & Make
export PATH=ANDROID_NDK/toolchains/arm-linux-androideabi-4.4.3/prebuilt/linux-x86/bin:$PATH
#libx264
./configure --cross-prefix=arm-linux-androideabi- enable-pic --disable-cli -enable-static --disable-shared -
-host=arm-linux --extra-cflags="-march=armv7-a -mfloat-abi=softfp" --sysroot=/path/to/android-
ndk/platforms/android-87arch-arm/
make
#fdk-aac
./configure --host=arm-android-eabi-linux --enable-static --prefix=/path/to/fdk-aac/ --disable-shared
make
#ffmpeg
./configure --disable-everything --enable-gpl --enable-libx264 --enable-libfdk-aac --enable-nonfree --
enable-pthreads --cross-prefix=arm-linux-androideabi- --arch=arm --sysroot=/path/to/android-
ndk/platforms/android-8/arch/arm/ --extra-cflags="-march=armv7-a -mfloat-abi=softfp" --extra-cflags="-
I./x264" --extra-cflags="-I./fdk-aac/include/" --extra-ldflags="-L./x264" --extra-ldflags="-L./fdk-aac/lib"
--datadir="/data/ffmpeg/bin/ffpresets" --enable-version3 --enable-decoder=rawvideo --enable-demuxer=rawvideo
--enable-decoder=aarc --enable-demuxer=aac --enable-muxer=h264 --enable-encoder=pcm_s16le --enable-
protocol=rtp --enable-protocol=udp --enable-muxer?rtp --enable-demuxer=image2pipe --enable-muzer=adts --
enable-muxer=pcm_s16le --enable-demuxer=pcm_s16le --enable-demuxer=h264 --enable-filter=scale --enable-
encoder=libx264 --enable-encoder=libfdk_aac -enable-protocol=pipe --enable-decoder=pcm_s16le --enable-
filter=aresample
make

10. *
Using Vitamio Player
● Get it from vitamio.org and extract
Line 1 VideoView videoView = (VideoView) findViewById(R.id.videoView);
Line 2 videoView.setVideoPath("rtsp://IP_OF_ANDROID_STREAM_SERVER:PORT/live.ts");
● To start vitamio play with partial buffer, follow the instructions on http://vitamio.org/topics/104?locale=en
Then we need a RTSP server

11. *
Implementing a RTSP Server
Client (MediaPlayer - Vitamio) RTSP Server

12. *
Sending Previews From RTSP Server
Line 1 public void startVideo(String address, int port) {
Line 2 String videoCommand = "path/to/ffmpeg -analyzeduration 0 -pix_fmt nv21
Line 3 -s 480x360 -vcodec rawvideo -f image2pipe -i - -s 320x240 -crf
18
Line 4 -preset ultrafast -vcodec libx264 -f rtp
rtp://"+address+":"+port;
Line 5 Process ffmpegVideoProcess = Runtime.getRuntime().exec(videoCommand);
Line 6 OutputStream ostream = ffmpegVideoProcess.getOutputStream();
Line 7
Line 8 getCamera().setPreviewCallback(new PreviewCallback(){
Line 9 public void onPreviewFrame(byte[] buffer, Camera cam) {
Line 10 ostream.write(buffer);
Line 11 ostream.flush();
Line 12 }
Line 13 });
Line 14 }

13. *
Sending Audio From RTSP Server
Line 1 public void startAudio(String address, int port) {
Line 2 String audioCommand = "path/to/ffmpeg -analyzeduration 0 -f s16le -ac
Line 3 44100 -ac 1 -i - -ac 1 -acodec libfdk_aac -f adts -vbr
3
Line 4 udp://"+address+ ":" + port +"/";
Line 5 Process ffmpegAudioProcess = Runtime.getRuntime().exec(audioCommand);
Line 6 OutputStream ostream = ffmpegAudioProcess.getOutputStream();
Line 7 prepareAudioRecord();
Line 8 new Thread(){ public void run(){
Line 9 while(true) {
Line 10 int len = audioRecord.read(audioBuffer, 0,
audioBuffer.length);
Line 11 ostream.write(audioBuffer, 0, len);
Line 12 ostream.flush()
Line 13 }
Line 14 }}.start();

14. *
Receiving Audio On Client
Line 1 public void receiveAudio() {
Line 2 String audioCommand = "path/to/ffmpeg -analyzeduration 0 -f aac -strict -2 -
acodec
Line 3 aac -b:a 120k -ac 1 -i - -ac 1 -acodec pcm_s16le -ar 44100 -f s16le -";
Line 5 Process ffmpegAudioProcess = Runtime.getRuntime().exec(audioCommand);
Line 6 OutputStream ostream = ffmpegAudioProcess.getOutputStream();
Line 7 DatagramSocket udpsocket = new DatagramSocket(PORT);
Line 8 DatagramPacket packet = new DatagramPacket(new byte[2048], 2048);
Line 9 new Thread(){ public void run(){
while(true) {
Line 10 udpsocket.receive(packet);
Line 11 ostream.write(datagramPacket.getData(), 0,
datagram.getLength());
Line 12 ostream.flush();
Line 13 }}}.start();

15. *
Playing Audio On Client
Line 1 public void playAudio(final InputStream istream) {
Line 2 byte[] buffer = new byte[2048];
Line 3 int bufferSize = AudioTrack.getMinBufferSize(44100,...);
Line 5 audioTrack = new AudioTrack(AudioManager.STREAM_MUSIC,44100,
Line 6 AudioFormat.CHANNEL_OUT_MONO,
AudioFormat.ENCODING_PCM_16BIT,
Line 7 bufferSize, AudioTrack.MODE_STREAM);
Line 8 audioTrack.play();
Line 9 while (true) {
Line 10 int len = istream.read(buffer, 0, buffer.length);
Line 11 audioTrack.write(buffer, 0, len);
Line 12 audioTrack.flush()
Line 13 }
Line 14 }

16. Demo

17. *
Android Developer Days
● Expected 1500~ participants
● Partner of Droidcon.com
● 15 co-organizers from 7 countries
● Free of charge
● This year more inspiration, more
networking and more fun
● ADD 2012 web site ->
www.androiddeveloperdays.com/2012
Date: June 14, 15 2013
Venue: METU, Ankara, Turkiye
www.androiddeveloperdays.com
