1. Java on CRaC
Presented by Simon Ritter, Deputy CTO | Azul

2. 2
Why Is Java So Popular?
• It's a great language
o Easy to write, easy to read
• It has great libraries
o Pretty much anything you can think off, almost always a FOSS version as well as commercial
• It has a great community
o JUGs, Champions, conferences, etc, etc
o Easy to find Java programmers
• But really, it's the Java Virtual Machine
o Write once, run anywhere
o Excellent backwards compatibility
o A managed runtime environment

3. 3
JVM Performance Warmup
• Classfiles contain bytecodes (instructions for a Virtual Machine)
• Initially, these are interpreted
o Each bytecode is converted to equivalent native instructions
• Frequently used methods (hotspots) are identified and compiled
o Just-in-Time (JIT) compilation
o Uses two compilers, C1 (fast compile, low optimisation) and C2 (slow compile, high optimisation)
• Each time the application is started, the same process begins again
o Profile code looking for hot methods
o Compile using C1 JIT, recompile using C2 JIT when hot enough

4. 4
JVM Performance Graph
Application
Warmup

5. 5
JVM Performance Graph
First run Second run Third run

6. 6
JVM Performance Graph
First run Second run Third run

7. 7
Why Not Use AOT?
• Traditional approach: Ahead of time, static compilation
• No interpreting bytecodes
• No analysis of hotspots
• No runtime compilation of code placing heavy load on CPUs
• Start at full speed, straight away
• This is the Graal native image approach
• Problem solved, right?

8. 8
What About AppCDS?

9. 9
Not So Fast
• AOT is, by definition, static
• And code is compiled before it is run
• The compiler has no knowledge of how the code will actually run
o Profile guided optimisation has been around for a long time and only helps partially

10. 10
Speculative Optimisation Example 1:
Inlining Monomorphic Sites
public class Animal {
private int color;
public int getColor() { return color };
}
myColor = animal.getColor();
can be transformed to:
myColor = animal.color;
As long as only one implementer of getColor() existslic
class Animal {

11. 11
Speculative Optimisation Example 2:
Branch Analysis
int computeMagnitude(int value) {
if (value > 9)
bias = computeBias(value);
else
bias = 1;
return Math.log10(bias + 99);
}
Profiling data shows that value (so far) has never been greater than 9

12. 12
Speculative Optimisation Example 2:
Branch Analysis
Assume that, based on profiling, value will continue to be less than 10
int computeMagnitude(int value) {
if (value > 9)
uncommonTrap(); // Deoptimise
return 2; // Math.log10(100)
}

13. 13
Speculative Optimisations
• Our measurements show over 50% of performance gains in JIT are due to speculative optimisations
• But they only work if you can deoptimise when assumptions prove false
• Deoptimisations are very bad for performance
o Already completed compilation is thrown away (wasted CPU cycles)
o Code must then be recompiled (during which must fallback to interpreter or C1 code)

14. 14
AOT vs JIT Compilation
• AOT
• Class loading prevents method inlining
• No runtime bytecode generation
• Reflection is complicated
• Unable to use speculative optimisations
• Overall performance will typically be lower
• Full speed from the start
• No CPU overhead to compile code at runtime
• JIT
• Can use aggressive method inlining
• Can use runtime byteocde generation
• Reflection is (relatively) simple
• Can use speculative optimisations
• Overall performance will typically be higher
• Requires warmup time
• CPU overhead to compile code at runtime

15. 15
JVM Performance
JIT Compiled Code
AOT Compiled Code
AOT Compiled Code with PGO

16. A Different Approach

17. 17
Co-ordinated Resume In Userspace
• Linux project
• Basic idea
o Freeze a running application
- Pause program counter
o Create a snapshot of the applications state (as a set of files)
o At some later point, use those files to restart the application from the same point
- Potentially, on a different physical machine
Input Output
CPU
Memory
Registers

18. 18
Co-ordinated Resume In Userspace
• Mainly implemented in userspace rather than the kernel
o Some kernel support required but integrated to mainline since 3.11
• Main goal is the migration of containers for microservices
• Supports extensive features
o Processes and threads
o Application memory, memory mapped files and shared memory
o Open files, pipes and FIFOs
o Sockets
o Interprocess communication channels
o Timers and signals
• Includes ability to rebuild a TCP connection from one side without the need to exchange packets

19. 19
CRIU Challenges
• What if we move the saved state to a different machine?
o What about open files, shared memory, etc?
• What if we use the same state to restart mutilple instances
o They would work as if each was the original instance
o Could lead to difficult clashes of use of state
• A JVM (and therefore Java code) would assume it was continuing its tasks
o Very difficult to use effectively

20. 20
Co-ordinated Restore at Checkpoint (CRaC)
• Let's make the application aware it is being checkpointed and restored
• CRaC also enforces more restrictions on a checkpointed application
o No open files or sockets
o Checkpoint will be aborted if any are found
Application running Application running
Aware of checkpoint
being created
Aware of restore
happening

21. 21
Using CRaC API
• CRaC uses Resources that can be notified about a Checkpoint and Restore
• Classes in application code implement the Resource interface
o Receive callbacks during checkpoint and restore
o Able to perform necessary actions (close files, etc.)
<<Interface>>
Resource
beforeCheckpoint()
afterRestore()

22. 22
Using CRaC API
• Resource objects need to be registered with a Context so that they can receive notifications
• There is a global Context accessible via the static getGlobalContext() method of the Core class
<<Interface>>
Resource
beforeCheckpoint()
afterRestore()
Core
getGlobalContext()
<<Abstract>>
Context
register(Resource)

23. 23
Using CRaC API
• The global Context maintains a list of Resource objects
• The beforeCheckpoint() methods are called in the order the Resource objects were added
• The afterRestore() methods are called in the reverse order the Resource objects were added
o Predictable restoration of important state

24. 24
Example: Jetty
class ServerManager {
Server server;
public ServerManager(int port, Handler handler) throws Exception {
server = new Server(8080);
server.setHandler(handler);
server.start();
}
}

25. 25
Using CRaC (External Initiation)
$ jcmd target/example-jetty-1.0-SNAPSHOT.jar JDK.checkpoint
80694: Command executed successfully
jdk.crac.impl.CheckpointOpenSocketException:tcp6 localAddr::localPort 8080 remoteAddr
::remotePort 0
at java.base/jdk.crac.Core.translateJVMExceptions(Core.java:80)
at java.base/jdk.crac.Core.checkpointRestore1(Core.java:137) at
java.base/jdk.crac.Core.checkpointRestore(Core.java:177) at
java.base/jdk.crac.Core.lambda$checkpointRestoreInternal$0(Core.java:19 at
java.base/java.lang.Thread.run(Thread.java:832)

26. 26
Example: Jetty
class ServerManager implements Resource {
public ServerManager(int port, Handler handler) throws Exception {
...
Core.getGlobalContext().register(this);
}
@Override
public void beforeCheckpoint(Context<? extends Resource> context) throws Exception {
server.stop();
}
@Override
public void afterRestore(Context<? extends Resource> context) throws Exception {
server.start();
}
}

27. 27
Using CRaC (Programmatic Initiation)
• In the application code, make an explicit call
Core.checkpointRestore();
• This will initiate the checkpoint and return when a restore has been completed
o Can throw either a CheckpointException or RestoreException

28. How Good Is It?

29. 29
Proof Of Concept Results

30. 30
Proof Of Concept Results
Time to complete n operations: Spring Boot

31. 31
Proof Of Concept Results
Time to complete n operations: Quarkus

32. Summary

33. 33
Summary
• CRaC is a way to pause a JVM-based application
• And restore it at some point in the future
o Possibly multiple times
• Benefit is potentially etremely fast time to full performance level
• Eleiminates the need for hotspot identification, method compiles, recompiles and deoptimisations
• Improved throughput from start
o By eliminating JIT compilation overhead
• OpenJDK project
o Get involved!
github.com/CRaC
wiki.openjdk.java.net/display/crac

34. 34
Demo

35. Thank You.
Simon Ritter, Deputy CTO
@speakjava
