This document describes the design of an angular way drilling machine. It includes 3 key points:
1) The machine allows for drilling holes at any angle between 0 and 90 degrees, providing more flexibility than traditional vertical drilling machines. It has saddle slide ways that allow the workpiece to be repositioned easily, reducing setting time.
2) The design includes components like lead screws, spur gears, bevel gears, and an angular table that allow the machine head and workpiece to be rotated and positioned in various orientations for angled drilling.
3) Calculations are provided for sizing gears and other components based on design requirements. The overall design is intended to simplify angled drilling and reduce the time required
