This document describes the design of a student formula racing car, including computations and analysis. It discusses the design of key subsystems like the chassis, suspension, transmission, steering, and brakes. Various materials were considered for the chassis, and AISI 1020 steel was selected. Finite element analysis was performed on the chassis design to ensure it can withstand expected loads. Analyses included rear impact, front impact, side impact, and torsional analyses. Natural frequency analysis was also carried out to determine the chassis's fundamental frequencies and mode shapes. The goal of the design was to achieve good drivability, reliability, weight reduction, and manufacturability.
