This document provides an introduction to test-driven development (TDD) using FlexUnit, an ActionScript unit testing framework. It discusses the benefits of TDD including enforcing modular design and simplifying integration testing. It then demonstrates a basic "Hello World" example of creating a Calculator class and corresponding test case class with a single test method to test the add() method. The key components of a test case class like setup, teardown, and annotation of test methods are also outlined.

1. Intro to
TDD with FlexUnit
[ Anupom Syam ]

3. TDD Cycle

4. Why?
TDD is like Source Control you don’t know how
much you need it until you start using it.

5. Benefits?
• Test first approach is Aspect Driven
• Enforces the developer to be the first consumer of
their own program
• Makes it easy to Refactor
• Simplifies Integration Testing
• Unit tests are living documentation of the system
• Encourages modular design
• Gives greater level of confidence in the code
• Reduces debugging time

6. Terminology
Assertion Test Case
true false statements that are used to verify the a set of conditions to determine the correctness of some
behavior of the unit functionalities of program
Test Suite Fixture
a set of tests that all share the same fixture all the things that must be in place in order to run a test
Code Coverage Fakes & Mocks
Dummy objects that simulates the behavior of complex,
percentage of a program tested by by a test suite
real objects

7. Phases of a Test
Set Up Exercise
setting up the test interact with the system under
fixture test
Blank State
Tear Down Verify
determine whether the
tear down the test fixture to
expected outcome has been
return to the original state
obtained

9. What?
• A unit testing framework for Flex and
ActionScript.
• Similar to JUnit - the original Java unit testing
framework.
• Comes with a graphical test runner.
• Can test both Flex and AS3 projects

10. Let’s try a “Hello
World” unit test using
FlexUnit

11. 1. Create a new project

12. 1. Create a new project

13. 2. Create a new method
package
{
import flash.display.Sprite;
public class Calculator extends Sprite
{
public function Calculator()
{
}
public function add(x:int, y:int):int
{
return 0;
}
}
}

14. 3. Create a test case class

15. 3. Create a test case class

16. 3. Create a test case class

17. package flexUnitTests
{
import flexunit.framework.Assert;
3. Create a
public class CalculatorTest
{
test case class
[Before]
public function setUp():void
{
}
[After]
public function tearDown():void
{
}
[BeforeClass]
public static function setUpBeforeClass():void
{
}
[AfterClass]
public static function tearDownAfterClass():void
{
}
[Test]
public function testAdd():void
{
Assert.fail("Test method Not yet implemented");
}
}
}

18. package flexUnitTests
{
import flexunit.framework.Assert;
public class CalculatorTest
{
4. Create a
private var calculator:Calculator;
failing test case
[Before]
public function setUp():void
{
calculator = new Calculator();
}
[After]
public function tearDown():void
{
}
[BeforeClass]
public static function setUpBeforeClass():void
{
}
[AfterClass]
public static function tearDownAfterClass():void
{
}
[Test]
public function testAdd():void
{
Assert.assertEquals(calculator.add(2, 3), 5);
}
}

19. 5. Execute the test

20. 5. Execute the test

21. 5. Execute the test

22. 6. Write the body of the method
package
{
import flash.display.Sprite;
public class Calculator extends Sprite
{
public function Calculator()
{
}
public function add(x:int, y:int):int
{
return x+y;
}
}
}

23. 7. Execute the test again

24. 7. Execute the test again

25. 7. Execute the test again

26. Good Job!

27. package flexUnitTests
{
import flexunit.framework.Assert;
public class CalculatorTest
{
Components of
private var calculator:Calculator;
a Test Case Class
[Before]
public function setUp():void
{
calculator = new Calculator();
}
[After]
public function tearDown():void
{
}
[BeforeClass]
public static function setUpBeforeClass():void
{
}
[AfterClass]
public static function tearDownAfterClass():void
{
}
[Test]
public function testAdd():void
{
Assert.assertEquals(calculator.add(2, 3), 5);
}
}

28. package flexUnitTests
{
import flexunit.framework.Assert;
public class CalculatorTest
{
Components of
private var calculator:Calculator;
a Test Case Class
[Before]
public function setUp():void
{
calculator = new Calculator();
}
[After]
public function tearDown():void
{
}
[BeforeClass]
public static function setUpBeforeClass():void
{
}
[AfterClass]
public static function tearDownAfterClass():void
{
}
[Test]
public function testAdd():void
{
Assert.assertEquals(calculator.add(2, 3), 5);
}
}

29. package flexUnitTests
{
import flexunit.framework.Assert;
public class CalculatorTest
{
Components of
private var calculator:Calculator;
a Test Case Class
[Before]
public function setUp():void
{
calculator = new Calculator();
}
[After]
public function tearDown():void
{
}
[BeforeClass]
public static function setUpBeforeClass():void
{
}
[AfterClass]
public static function tearDownAfterClass():void
{
}
[Test]
public function testAdd():void
{
Assert.assertEquals(calculator.add(2, 3), 5);
}
}

30. package flexUnitTests
{
import flexunit.framework.Assert;
public class CalculatorTest
{
Components of
private var calculator:Calculator;
a Test Case Class
[Before]
public function setUp():void
{
calculator = new Calculator();
}
[After]
public function tearDown():void
{
}
[BeforeClass]
public static function setUpBeforeClass():void
{
}
[AfterClass]
public static function tearDownAfterClass():void
{
}
[Test]
public function testAdd():void
{
Assert.assertEquals(calculator.add(2, 3), 5);
}
}

31. Test Suite Class
package flexUnitTests
{
import flexUnitTests.CalculatorTest;
[Suite]
[RunWith("org.flexunit.runners.Suite")]
public class CalculatorTestSuite
{
public var test1:flexUnitTests.CalculatorTest;
}
}

32. Myths
• TDD is a Golden Hammer
• We will not need Testers any more
• TDD eradicates bugs from the code
• TDD ensures that the code is up to the
requirement

33. Facts
• Don’t expect TDD to solve all of your
problems.
• TDD reduces the amount of QA but we will
still need Testers :)
• TDD may reduce number of bugs
• Tests might share the same blind spots as
your code because of misunderstanding of
requirements.

34. Useful Links
• FlexUnit
http://www.flexunit.org/
• FlexUnit 4.0
http://docs.flexunit.org/index.php?title=Main_Page
• A brief and beautiful overview of FlexUnit
http://www.digitalprimates.net/author/codeslinger/2009/05/03/
flexunit-4-in-360-seconds/
• A very good read
http://www.amazon.com/Working-Effectively-Legacy-Michael-
Feathers/dp/0131177052

35. Thank you!
