Introduction to Computer Graphics ,

1. CSC 307 1.0
Graphics Programming
Budditha Hettige
Department of Statistics and Computer Science

2. Graphics Programming
2Budditha Hettige

3. Common Uses for Computer
Graphics
• Applications for real-time 3D graphics range from
interactive games and simulations to data visualization
for scientific, medical, or business uses
– Military flight simulators
– Computer-aided design (CAD)
– Architectural or civil planning
– Scientific visualization
– Entertainment
3Budditha Hettige

4. Movies
Budditha Hettige 4

5. Games
Budditha Hettige 5

6. Simulation
Budditha Hettige 6

7. CAD-CAM & Design
Budditha Hettige 7

8. Architecture
Budditha Hettige 8

9. Virtual Reality
Budditha Hettige 9

10. Visualization
Budditha Hettige 10

11. Medical Imaging
Budditha Hettige 11

12. Graphics System
12
User ProgramUser Program IO DevicesIO Devices
Graphics API
Graphics
System
Graphics
System
Budditha Hettige

13. Graphics Designing
13Budditha Hettige

14. Graphics: Conceptual Model
Real Object
Real Object
Human Eye
Human Eye
Display
Device
Graphics System
Synthetic
Model
Synthetic
Camera
Real Light
Synthetic
Light Source
Budditha Hettige 14

15. OpenGL
• Standard specification defining a cross-language, cross-
platform API
• Is not a programming language
• Writing applications that produce 2D and 3D computer
graphics
• A software interface to graphics hardware
• Designed and optimized for the display and
manipulation of 3D graphics
• Developed by Silicon Graphics Inc. (SGI) in 1992
15Budditha Hettige

16. OpenGL-Graphics rendering API
• Rendering API
– High-quality color images composed of geometric
and image primitives
– Window system independent
– Operating system independent
• OpenGL Pipeline
16Budditha Hettige

17. OpenGL Architecture
17
Display
List
Polynomial
Evaluator
Per Vertex
Operations &
Primitive
Assembly
Rasterization
Per Fragment
Operations
Frame
Buffer
Texture
Memory
CPU
Pixel
Operations
Budditha Hettige

18. Software & Hardware Interfaces
18
Software Interface Hardware Interface
Budditha Hettige

19. OpenGL and Related APIs
19
GLUT
GLU
GL
GLX, AGL
or WGL
X, Win32, Mac O/S
software and/or hardware
application program
OpenGL Motif
widget or similar
Budditha Hettige

20. Related APIs
• AGL, GLX, WGL
– glue between OpenGL and windowing systems
• GLU (OpenGL Utility Library)
– part of OpenGL
– NURBS, tessellators, quadric shapes, etc.
• GLUT (OpenGL Utility Toolkit)
– portable windowing API
– not officially part of OpenGL
• Initial header inclusions (for Windows)
– #include<windows.h>
– #include<gl/gl.h>
– #include<gl/glu.h>
– #include <GL/glut.h>
20Budditha Hettige

21. Function-Naming Conventions
• All OpenGL functions take the following
format
<Library prefix><Root command><Optional argument
count><Optional argument type>
21Budditha Hettige

22. OpenGL data types
22Budditha Hettige

23. 2D Coordinates
23Budditha Hettige

24. Coordinate Clipping
24Budditha Hettige

25. Viewports
• Mapping Drawing Coordinates to Window
Coordinates
25
viewport defined as twice the size of the clipping area
Budditha Hettige

26. Viewports
26
viewport that matches the clipping area
Budditha Hettige

27. OpenGL 3-D coordinates
• Right-handed system
• From point of view of camera looking out into
scene:
 +X right, -X left
 +Y up, -Y down
 +Z behind camera, -Z in front
• Positive rotations are counterclockwise around
axis of rotation
27Budditha Hettige

28. 28
OpenGL Geometric Primitives
GL_QUAD_STRIP
GL_POLYGON
GL_TRIANGLE_STRIP
GL_TRIANGLE_FAN
GL_POINTS
GL_LINES
GL_LINE_LOOPGL_LINE_STRIP
GL_TRIANGLES
GL_QUADS
Primitives are one- or two-dimensional entities or
surfaces such as points, lines, and polygons
Budditha Hettige

29. The Vertex—A Position in Space
• Each corner of the any primitive is called a
vertex. Ex: three-dimensional cube consists of
six two dimensional squares, each placed on a
separate face
29Budditha Hettige

30. Projections: Getting 3D to 2D
• Orthographic Projections
• Perspective Projections
30Budditha Hettige

31. RGB Color Space
Green
(1,0,0)
Blue
(0,0,1)
Red
(1,0,0)
Yellow
(1,1,0)
Magenta
(1,0,1)
Blk
Cyan
(0,1,1)
White
(1,1,1)
G
B
R
Image: Pixel maps to color
Budditha Hettige 31

32. Common Composite Colors
32Budditha Hettige
