INTRODUCING TO AZURE SQL
#SQLsat712
HELLO MY NAME IS STEVE
 Managing Director of StratosTechnology Partners
 SharePoint Consultant
 Microsoft MVP for Office Servers and Services
 Based in Christchurch, New Zealand
Twitter: @nztechtweet
Email: steve@stp.co.nz
MY SQL JOURNEY
• Digital EquipmentCorporationVAX
• VMS Operating System
• Rdb relational database
• Terrible performance
• Extremely expensive
• Green screen (or XTerm)
Oracle said “even if Rdb were
free, you couldn’t afford it”.
They were probably right.
CANWE DOTHIS BETTER?
• 1 CPU – Pentium 90 with 2 x 52MB IDE (IMP52) drives
mirrored
• Performance was almost 10 times theVAX on the same task
• Price was nearly 25 times less!
• I found a bug and Microsoft released a hot fix 
• The solution was affordable for other orgs with smaller
budgets
• The same core software is still in use today, more than 25
years later running on SQL 2016
FUN FACT: DECVMS included LAN
Manager, the forerunner of Windows
NT’s networking
SLIDE FOR MARTIN CATHERALL
Steve, can you tell
me more about
SharePoint?
LETSTALK ABOUTTHE FUTURE
WHAT IS AZURE SQL?
 Managed Service version of SQLserver (PaaS model)
 Available in two pricing models
 Throughput based model (DTU – DatabaseThroughput Units)
 CPU based model (preview)
 Infrastructure as a Service (IaaS)
 SQL Server running on anAzureVirtual Machine
 Essential the same functionality as on-premises but hosted in Azure data centres
 Docker -> https://azure.microsoft.com/en-us/resources/videos/connect-2017-use-sql-
server-2017-in-docker-containers-for-your-ci-cd-process/
MICROSOFT DATA PLATFORM
PRICING MODELS
DATABASETHROUGHPUT UNIT MODEL (DTU)
Basic Standard Premium
Target workload Development and production Development and production Development and production
Uptime SLA 99.99% 99.99% 99.99%
Backup retention 7 days 35 days 35 days
CPU Low Low, Medium, High Medium, High
IO throughput (approximate) 2.5 IOPS per DTU 2.5 IOPS per DTU 48 IOPS per DTU
IO latency (approximate) 5 ms (read), 10 ms (write) 5 ms (read), 10 ms (write) 2 ms (read/write)
Columnstore indexing N/A S3 and above Supported
In-memory OLTP N/A N/A Supported
http://dtucalculator.azurewebsites.net/
DTU STORAGE
Basic Standard Premium
Maximum storage size* 2 GB 1TB 4TB
Maximum DTUs 5 3000 4000
Basic Standard Premium
Maximum storage size per database* 2 GB 1TB 1TB
Maximum storage size per pool* 156 GB 4TB 4TB
Maximum eDTUs per database 5 3000 4000
Maximum eDTUs per pool 1600 3000 4000
Maximum number of databases per pool 500 500 100
Single Database
Elastic Storage Pools
VCORE MODEL (PREVIEW)
 In the vCore-based purchasing model (preview) customers pay for:
 Compute (service tier + number of vCores + generation of hardware)*
 Type and amount of data and log storage
 Number of IOs**
 Backup storage (RA-GRS)**
 * In the initial public preview, the Gen 4 Logical CPUs are based on Intel E5-2673
v3 (Haswell) 2.4-GHz processors
 ** During preview, 7 days of backups and IOs are free
VCORE PERFORMANCE
General Purpose Business Critical
Best for Most business workloads. Offers budget
oriented balanced and scalable compute and
storage options.
Business applications with high IO requirements.
Offers highest resilience to failures using several
isolated replicas.
Compute 1 to 80 vCore, Generation 4 andGeneration 5 1 to 80 vCore, Generation 4 andGeneration 5
Memory 7 GB per core 7 GB per core
Storage Premium remote storage, 5 GB – 4TB Local SSD storage, 5 GB – 4TB
IO throughput (approximate) 500 IOPS per vCore with 7000 maximum IOPS 5000 IOPS per core with 200000 maximum IOPS
Availability 1 replica, no read-scale 3 replicas, 1 read-scale, zone redundant HA
Backups RA-GRS, 7-35 days (7 days by default) RA-GRS, 7-35 days (7 days by default)*
In-Memory N/A Supported
PAAS OR IAAS?
Azure SQL
 New cloud apps
 Need rapid deployment
 Need built in HA and DR
 Don’t want to manage a server
 Databases size up to 4TB
SQL Server on AzureVirtual Machine
 Existing Applications
 Minimal change to applications
 You want to manage, patch and
configure
 Need full administrative rights
 Database size up to 64TB
SECURITY
 Data Protection
 Encryption
 Data Discovery and Classification
 Access Control
 Firewall
 Authentication (SQL andAAD)
 Authorisation (roles)
 Row-level security
 Dynamic Data Masking
 Proactive Monitoring
 Auditing
 Threat Protection
 Compliance
 SQL compliance certifications
 Security Management
 VulnerabilityAssessment
CREATING A DATABASE
MANAGING A DATABASE
MIGRATINGTO AZURE SQL
https://www.microsoft.com/en-us/download/details.aspx?id=53595
TRANSACTIONAL REPLICATION
 If you want to minimise downtime use transactional replication from your existing
on premises SQL server to Azure SQL
 Publish your source database
 Subscription on the destination database
 Everything in the schema appears in the Azure SQL database
 You can replicate a subset of objects or everything
 Once all data has replicated, stop replication and switch your application to the
new datasource
MIGRATINGTO A MANAGED INSTANCE
• Restore of system databases is not supported.To migrate instance level objects (stored in
master or msdb databases), we recommend to script them out and runT-SQL scripts on the
destination instance.
• You can also use BACPAC to copy your source database and import into Azure SQL databases
BACKUP
 Point in time backups every 5-10 mins
 Backup retention:
 Basic service tier – 1 week
 Standard service tier – 5 weeks
 Advanced service tier – 5 weeks
 Long term retention
 Up to 10 years
 Weekly full backups copied to long term storage
 Backups are encrypted ifTDE is enabled on the database
RESTORE
HOW MUCH DOES IT COST?
https://azure.microsoft.com/en-us/pricing/details/sql-database/managed/
BURNING QUESTIONS?
Don’t ask me, I’m an MVP for SharePoint ;)
See people like Simon,Warwick, Shaun and Hamish.These guys live and breath this stuff!
REFERENCES
WWW.GOOGLE.COM
https://docs.microsoft.com/en-us/azure/sql-database/
