VLAN, Trunk and 802.1q Router Configuration Objectiv.docxdickonsondorris
VLAN, Trunk and 802.1q Router Configuration
Objectives
Initial Configuration
VLAN Trunking Configuration
802.1q Router/Switch trunking
Topology
You can click the Show Lab Content button to download the lab or you can download the l ab from
[email protected] in Content.
VLAN, Trunk and 802.1q Router Configuration
Step 1: Initial Switch Configuration
Configure hostnames on the switches
Configure enable secret, console and vty (Telnet) passwords as uwstout
Configure VLANs 10, 20 and 30 on StoutSW1 and StoutSW2
Configure the ports the PCs are connected to in the proper vlans
Shutdown the fa0/4 interfaces on each switch
Configure an IEEE 802.1Q trunk between StoutSW1 and StoutSW2 using the fa0/1 interfaces
Configure the IP addresses and subnet masks on PC1a, PC1b and PC2 according to the topology
diagram
Verify your configuration before moving on to Step 2
If you need help remembering the commands for the initial configuration steps, try using ? or refer to the
previous labs.
Before moving to Step 2 verify your trunk and VLAN configuration, PC IP addresses and that the switchports
for the PCs are in the correct vlans. Use “show” commands and ipconfig to verify the initial configuration.
VLAN, Trunk and 802.1q Router Configuration
Step 2: Configure 802.1 trunk between Menomonie and StoutSW1
Data from one vlan cannot cross into another vlan without the help of a router to route the data. Currently
the PCs cannot successfully send to each other because they are on different VLANs. In this step you will
configure a trunk between the Menomonie router and the StoutSW1 switch. (This type of configuration is
referred to as “Router-on-a-Stick”) so the router can be used to route traffic between the VLANs. The
physical interface on the router that is connected to StoutSW1 is fastethernet0/1 so you will configure the
trunked sub-interfaces on the fastethernet0/1 interface. Then configure fastethernet0/8 on StoutSW1 to trunk.
Configure the Router:
Configure the hostname on the router to Menomonie:
In global configuration mode type, hostname Menomonie
Configure the first sub-interface on Menomonie to route vlan 10
In global configuration mode type, interface fastethernet0/1.10
In interface configuration mode for fa0/1.10 type, encapsulation dot1q 10
Configure the second sub-interface on Menomonie to route vlan 20
In global configuration mode type, interface fastethernet0/1.20
In interface configuration mode for fa0/1.20 type, encapsulation dot1q 20
Configure the third sub-interface on Menomonie to route vlan 30
In global configuration mode type, interface fastethernet0/1.30
In interface configuration mode for fa0/1.30 type, encapsulation dot1q 30
Now that the virtual trunked interfaces have been configured you can assign an IP address to the
interfaces. The addresses for each inter ...
