The Query Optimizer is the “brain” of your Postgres database. It interprets SQL queries and determines the fastest method of execution. Using the EXPLAIN command , this presentation shows how the optimizer interprets queries and determines optimal execution. This presentation will give you a better understanding of how Postgres optimally executes their queries and what steps you can take to understand and perhaps improve its behavior in your environment. To listen to the webinar recording, please visit EnterpriseDB.com > Resources > Ondemand Webcasts If you have any questions please email sales@enterprisedb.com

1. Explaining the Postgres Query Optimizer
BRUCE MOMJIAN
January, 2015
The optimizer is the "brain" of the database, interpreting SQL
queries and determining the fastest method of execution. This
talk uses the EXPLAIN command to show how the optimizer
interprets queries and determines optimal execution.
Creative Commons Attribution License http://momjian.us/presentations
1 / 61

2. PostgreSQL the database…
◮ Open Source Object Relational DBMS since 1996
◮ Distributed under the PostgreSQL License
◮ Similar technical heritage as Oracle, SQL Server & DB2
◮ However, a strong adherence to standards (ANSI-SQL 2008)
◮ Highly extensible and adaptable design
◮ Languages, indexing, data types, etc.
◮ E.g. PostGIS, JSONB, SQL/MED
◮ Extensive use throughout the world for applications and
organizations of all types
◮ Bundled into Red Hat Enterprise Linux, Ubuntu, CentOS
and Amazon Linux
Explaining the Postgres Query Optimizer 2 / 61

3. PostgreSQL the community…
◮ Independent community led by a Core Team of six
◮ Large, active and vibrant community
◮ www.postgresql.org
◮ Downloads, Mailing lists, Documentation
◮ Sponsors sampler:
◮ Google, Red Hat, VMWare, Skype, Salesforce, HP and
EnterpriseDB
◮ http://www.postgresql.org/community/
Explaining the Postgres Query Optimizer 3 / 61

4. EnterpriseDB the company…
◮ The worldwide leader of Postgres based products and
services founded in 2004
◮ Customers include 50 of the Fortune 500 and 98 of the
Forbes Global 2000
◮ Enterprise offerings:
◮ PostgreSQL Support, Services and Training
◮ Postgres Plus Advanced Server with Oracle Compatibility
◮ Tools for Monitoring, Replication, HA, Backup & Recovery
Community
◮ Citizenship
◮ Contributor of key features: Materialized Views, JSON, &
more
◮ Nine community members on staff
Explaining the Postgres Query Optimizer 4 / 61

5. EnterpriseDB the company…
Explaining the Postgres Query Optimizer 5 / 61

6. Postgres Query Execution
User
Terminal
Code
Database
Server
Application
Queries
Results
PostgreSQL
Libpq
Explaining the Postgres Query Optimizer 6 / 61

7. Postgres Query Execution
utility
Plan
Optimal Path
Query
Postmaster
Postgres Postgres
Libpq
Main
Generate Plan
Traffic Cop
Generate Paths
Execute Plan
e.g. CREATE TABLE, COPY
SELECT, INSERT, UPDATE, DELETE
Rewrite Query
Parse Statement
Utility
Command
Storage ManagersCatalogUtilities
Access Methods Nodes / Lists
Explaining the Postgres Query Optimizer 7 / 61

8. Postgres Query Execution
utility
Plan
Optimal Path
Query
Generate Plan
Traffic Cop
Generate Paths
Execute Plan
e.g. CREATE TABLE, COPY
SELECT, INSERT, UPDATE, DELETE
Rewrite Query
Parse Statement
Utility
Command
Explaining the Postgres Query Optimizer 8 / 61

9. The Optimizer Is the Brain
http://www.wsmanaging.com/
Explaining the Postgres Query Optimizer 9 / 61

10. What Decisions Does the Optimizer Have to Make?
◮ Scan Method
◮ Join Method
◮ Join Order
Explaining the Postgres Query Optimizer 10 / 61

11. Which Scan Method?
◮ Sequential Scan
◮ Bitmap Index Scan
◮ Index Scan
Explaining the Postgres Query Optimizer 11 / 61

12. A Simple Example Using pg_class.relname
SELECT relname
FROM pg_class
ORDER BY 1
LIMIT 8;
relname
-----------------------------------
_pg_foreign_data_wrappers
_pg_foreign_servers
_pg_user_mappings
administrable_role_authorizations
applicable_roles
attributes
check_constraint_routine_usage
check_constraints
(8 rows)
Explaining the Postgres Query Optimizer 12 / 61

13. Let’s Use Just the First Letter of pg_class.relname
SELECT substring(relname, 1, 1)
FROM pg_class
ORDER BY 1
LIMIT 8;
substring
-----------
_
_
_
a
a
a
c
c
(8 rows)
Explaining the Postgres Query Optimizer 13 / 61

14. Create a Temporary Table with an Index
CREATE TEMPORARY TABLE sample (letter, junk) AS
SELECT substring(relname, 1, 1), repeat(’x’, 250)
FROM pg_class
ORDER BY random(); -- add rows in random order
SELECT 253
CREATE INDEX i_sample on sample (letter);
CREATE INDEX
All the queries used in this presentation are available at
http://momjian.us/main/writings/pgsql/optimizer.sql.
Explaining the Postgres Query Optimizer 14 / 61

15. Create an EXPLAIN Function
CREATE OR REPLACE FUNCTION lookup_letter(text) RETURNS SETOF text AS $$
BEGIN
RETURN QUERY EXECUTE ’
EXPLAIN SELECT letter
FROM sample
WHERE letter = ’’’ || $1 || ’’’’;
END
$$ LANGUAGE plpgsql;
CREATE FUNCTION
Explaining the Postgres Query Optimizer 15 / 61

16. What is the Distribution of the sample Table?
WITH letters (letter, count) AS (
SELECT letter, COUNT(*)
FROM sample
GROUP BY 1
)
SELECT letter, count, (count * 100.0 / (SUM(count) OVER ()))::numeric(4,1) AS "%"
FROM letters
ORDER BY 2 DESC;
Explaining the Postgres Query Optimizer 16 / 61

17. What is the Distribution of the sample Table?
letter | count | %
--------+-------+------
p | 199 | 78.7
s | 9 | 3.6
c | 8 | 3.2
r | 7 | 2.8
t | 5 | 2.0
v | 4 | 1.6
f | 4 | 1.6
d | 4 | 1.6
u | 3 | 1.2
a | 3 | 1.2
_ | 3 | 1.2
e | 2 | 0.8
i | 1 | 0.4
k | 1 | 0.4
(14 rows)
Explaining the Postgres Query Optimizer 17 / 61

18. Is the Distribution Important?
EXPLAIN SELECT letter
FROM sample
WHERE letter = ’p’;
QUERY PLAN
------------------------------------------------------------------------
Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=32)
Index Cond: (letter = ’p’::text)
(2 rows)
Explaining the Postgres Query Optimizer 18 / 61

19. Is the Distribution Important?
EXPLAIN SELECT letter
FROM sample
WHERE letter = ’d’;
QUERY PLAN
------------------------------------------------------------------------
Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=32)
Index Cond: (letter = ’d’::text)
(2 rows)
Explaining the Postgres Query Optimizer 19 / 61

20. Is the Distribution Important?
EXPLAIN SELECT letter
FROM sample
WHERE letter = ’k’;
QUERY PLAN
------------------------------------------------------------------------
Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=32)
Index Cond: (letter = ’k’::text)
(2 rows)
Explaining the Postgres Query Optimizer 20 / 61

21. Running ANALYZE Causes
a Sequential Scan for a Common Value
ANALYZE sample;
ANALYZE
EXPLAIN SELECT letter
FROM sample
WHERE letter = ’p’;
QUERY PLAN
---------------------------------------------------------
Seq Scan on sample (cost=0.00..13.16 rows=199 width=2)
Filter: (letter = ’p’::text)
(2 rows)
Autovacuum cannot ANALYZE (or VACUUM) temporary tables because
these tables are only visible to the creating session.
Explaining the Postgres Query Optimizer 21 / 61

22. Sequential Scan
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
8K
Heap
A
A
D
T
A
T
A
D
A
T
A
D
A
Explaining the Postgres Query Optimizer 22 / 61

23. A Less Common Value Causes a Bitmap Index Scan
EXPLAIN SELECT letter
FROM sample
WHERE letter = ’d’;
QUERY PLAN
-----------------------------------------------------------------------
Bitmap Heap Scan on sample (cost=4.28..12.74 rows=4 width=2)
Recheck Cond: (letter = ’d’::text)
-> Bitmap Index Scan on i_sample (cost=0.00..4.28 rows=4 width=0)
Index Cond: (letter = ’d’::text)
(4 rows)
Explaining the Postgres Query Optimizer 23 / 61

24. Bitmap Index Scan
=&
Combined
’A’ AND ’NS’
1
0
1
0
TableIndex 1
col1 = ’A’
Index 2
1
0
0
col2 = ’NS’
1 0
1
0
0
Index
Explaining the Postgres Query Optimizer 24 / 61

25. An Even Rarer Value Causes an Index Scan
EXPLAIN SELECT letter
FROM sample
WHERE letter = ’k’;
QUERY PLAN
-----------------------------------------------------------------------
Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
Index Cond: (letter = ’k’::text)
(2 rows)
Explaining the Postgres Query Optimizer 25 / 61

26. Index Scan
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
< >=Key
< >=Key
Index
Heap
< >=Key
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
Explaining the Postgres Query Optimizer 26 / 61

27. Let’s Look at All Values and their Effects
WITH letter (letter, count) AS (
SELECT letter, COUNT(*)
FROM sample
GROUP BY 1
)
SELECT letter AS l, count, lookup_letter(letter)
FROM letter
ORDER BY 2 DESC;
l | count | lookup_letter
---+-------+-----------------------------------------------------------------------
p | 199 | Seq Scan on sample (cost=0.00..13.16 rows=199 width=2)
p | 199 | Filter: (letter = ’p’::text)
s | 9 | Seq Scan on sample (cost=0.00..13.16 rows=9 width=2)
s | 9 | Filter: (letter = ’s’::text)
c | 8 | Seq Scan on sample (cost=0.00..13.16 rows=8 width=2)
c | 8 | Filter: (letter = ’c’::text)
r | 7 | Seq Scan on sample (cost=0.00..13.16 rows=7 width=2)
r | 7 | Filter: (letter = ’r’::text)
…
Explaining the Postgres Query Optimizer 27 / 61

28. OK, Just the First Lines
WITH letter (letter, count) AS (
SELECT letter, COUNT(*)
FROM sample
GROUP BY 1
)
SELECT letter AS l, count,
(SELECT *
FROM lookup_letter(letter) AS l2
LIMIT 1) AS lookup_letter
FROM letter
ORDER BY 2 DESC;
Explaining the Postgres Query Optimizer 28 / 61

29. Just the First EXPLAIN Lines
l | count | lookup_letter
---+-------+-----------------------------------------------------------------------
p | 199 | Seq Scan on sample (cost=0.00..13.16 rows=199 width=2)
s | 9 | Seq Scan on sample (cost=0.00..13.16 rows=9 width=2)
c | 8 | Seq Scan on sample (cost=0.00..13.16 rows=8 width=2)
r | 7 | Seq Scan on sample (cost=0.00..13.16 rows=7 width=2)
t | 5 | Bitmap Heap Scan on sample (cost=4.29..12.76 rows=5 width=2)
f | 4 | Bitmap Heap Scan on sample (cost=4.28..12.74 rows=4 width=2)
v | 4 | Bitmap Heap Scan on sample (cost=4.28..12.74 rows=4 width=2)
d | 4 | Bitmap Heap Scan on sample (cost=4.28..12.74 rows=4 width=2)
a | 3 | Bitmap Heap Scan on sample (cost=4.27..11.38 rows=3 width=2)
_ | 3 | Bitmap Heap Scan on sample (cost=4.27..11.38 rows=3 width=2)
u | 3 | Bitmap Heap Scan on sample (cost=4.27..11.38 rows=3 width=2)
e | 2 | Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
i | 1 | Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
k | 1 | Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
(14 rows)
Explaining the Postgres Query Optimizer 29 / 61

30. We Can Force an Index Scan
SET enable_seqscan = false;
SET enable_bitmapscan = false;
WITH letter (letter, count) AS (
SELECT letter, COUNT(*)
FROM sample
GROUP BY 1
)
SELECT letter AS l, count,
(SELECT *
FROM lookup_letter(letter) AS l2
LIMIT 1) AS lookup_letter
FROM letter
ORDER BY 2 DESC;
Explaining the Postgres Query Optimizer 30 / 61

31. Notice the High Cost for Common Values
l | count | lookup_letter
---+-------+-----------------------------------------------------------------------
p | 199 | Index Scan using i_sample on sample (cost=0.00..39.33 rows=199 width=
s | 9 | Index Scan using i_sample on sample (cost=0.00..22.14 rows=9 width=2)
c | 8 | Index Scan using i_sample on sample (cost=0.00..19.84 rows=8 width=2)
r | 7 | Index Scan using i_sample on sample (cost=0.00..19.82 rows=7 width=2)
t | 5 | Index Scan using i_sample on sample (cost=0.00..15.21 rows=5 width=2)
d | 4 | Index Scan using i_sample on sample (cost=0.00..15.19 rows=4 width=2)
v | 4 | Index Scan using i_sample on sample (cost=0.00..15.19 rows=4 width=2)
f | 4 | Index Scan using i_sample on sample (cost=0.00..15.19 rows=4 width=2)
_ | 3 | Index Scan using i_sample on sample (cost=0.00..12.88 rows=3 width=2)
a | 3 | Index Scan using i_sample on sample (cost=0.00..12.88 rows=3 width=2)
u | 3 | Index Scan using i_sample on sample (cost=0.00..12.88 rows=3 width=2)
e | 2 | Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
i | 1 | Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
k | 1 | Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
(14 rows)
RESET ALL;
RESET
Explaining the Postgres Query Optimizer 31 / 61

32. This Was the Optimizer’s Preference
l | count | lookup_letter
---+-------+-----------------------------------------------------------------------
p | 199 | Seq Scan on sample (cost=0.00..13.16 rows=199 width=2)
s | 9 | Seq Scan on sample (cost=0.00..13.16 rows=9 width=2)
c | 8 | Seq Scan on sample (cost=0.00..13.16 rows=8 width=2)
r | 7 | Seq Scan on sample (cost=0.00..13.16 rows=7 width=2)
t | 5 | Bitmap Heap Scan on sample (cost=4.29..12.76 rows=5 width=2)
f | 4 | Bitmap Heap Scan on sample (cost=4.28..12.74 rows=4 width=2)
v | 4 | Bitmap Heap Scan on sample (cost=4.28..12.74 rows=4 width=2)
d | 4 | Bitmap Heap Scan on sample (cost=4.28..12.74 rows=4 width=2)
a | 3 | Bitmap Heap Scan on sample (cost=4.27..11.38 rows=3 width=2)
_ | 3 | Bitmap Heap Scan on sample (cost=4.27..11.38 rows=3 width=2)
u | 3 | Bitmap Heap Scan on sample (cost=4.27..11.38 rows=3 width=2)
e | 2 | Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
i | 1 | Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
k | 1 | Index Scan using i_sample on sample (cost=0.00..8.27 rows=1 width=2)
(14 rows)
Explaining the Postgres Query Optimizer 32 / 61

33. Which Join Method?
◮ Nested Loop
◮ With Inner Sequential Scan
◮ With Inner Index Scan
◮ Hash Join
◮ Merge Join
Explaining the Postgres Query Optimizer 33 / 61

34. What Is in pg_proc.oid?
SELECT oid
FROM pg_proc
ORDER BY 1
LIMIT 8;
oid
-----
31
33
34
35
38
39
40
41
(8 rows)
Explaining the Postgres Query Optimizer 34 / 61

35. Create Temporary Tables
from pg_proc and pg_class
CREATE TEMPORARY TABLE sample1 (id, junk) AS
SELECT oid, repeat(’x’, 250)
FROM pg_proc
ORDER BY random(); -- add rows in random order
SELECT 2256
CREATE TEMPORARY TABLE sample2 (id, junk) AS
SELECT oid, repeat(’x’, 250)
FROM pg_class
ORDER BY random(); -- add rows in random order
SELECT 260
These tables have no indexes and no optimizer statistics.
Explaining the Postgres Query Optimizer 35 / 61

36. Join the Two Tables
with a Tight Restriction
EXPLAIN SELECT sample2.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id)
WHERE sample1.id = 33;
QUERY PLAN
---------------------------------------------------------------------
Nested Loop (cost=0.00..234.68 rows=300 width=32)
-> Seq Scan on sample1 (cost=0.00..205.54 rows=50 width=4)
Filter: (id = 33::oid)
-> Materialize (cost=0.00..25.41 rows=6 width=36)
-> Seq Scan on sample2 (cost=0.00..25.38 rows=6 width=36)
Filter: (id = 33::oid)
(6 rows)
Explaining the Postgres Query Optimizer 36 / 61

37. Nested Loop Join
with Inner Sequential Scan
aag
aar
aay aag
aas
aar
aaa
aay
aai
aag
No Setup Required
aai
Used For Small Tables
Outer Inner
Explaining the Postgres Query Optimizer 37 / 61

38. Pseudocode for Nested Loop Join
with Inner Sequential Scan
for (i = 0; i < length(outer); i++)
for (j = 0; j < length(inner); j++)
if (outer[i] == inner[j])
output(outer[i], inner[j]);
Explaining the Postgres Query Optimizer 38 / 61

39. Join the Two Tables with a Looser Restriction
EXPLAIN SELECT sample1.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id)
WHERE sample2.id > 33;
QUERY PLAN
----------------------------------------------------------------------
Hash Join (cost=30.50..950.88 rows=20424 width=32)
Hash Cond: (sample1.id = sample2.id)
-> Seq Scan on sample1 (cost=0.00..180.63 rows=9963 width=36)
-> Hash (cost=25.38..25.38 rows=410 width=4)
-> Seq Scan on sample2 (cost=0.00..25.38 rows=410 width=4)
Filter: (id > 33::oid)
(6 rows)
Explaining the Postgres Query Optimizer 39 / 61

40. Hash Join
Hashed
Must fit in Main Memory
aak
aar
aak
aay aaraam
aao aaw
aay
aag
aas
Outer Inner
Explaining the Postgres Query Optimizer 40 / 61

41. Pseudocode for Hash Join
for (j = 0; j < length(inner); j++)
hash_key = hash(inner[j]);
append(hash_store[hash_key], inner[j]);
for (i = 0; i < length(outer); i++)
hash_key = hash(outer[i]);
for (j = 0; j < length(hash_store[hash_key]); j++)
if (outer[i] == hash_store[hash_key][j])
output(outer[i], inner[j]);
Explaining the Postgres Query Optimizer 41 / 61

42. Join the Two Tables with No Restriction
EXPLAIN SELECT sample1.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id);
QUERY PLAN
-------------------------------------------------------------------------
Merge Join (cost=927.72..1852.95 rows=61272 width=32)
Merge Cond: (sample2.id = sample1.id)
-> Sort (cost=85.43..88.50 rows=1230 width=4)
Sort Key: sample2.id
-> Seq Scan on sample2 (cost=0.00..22.30 rows=1230 width=4)
-> Sort (cost=842.29..867.20 rows=9963 width=36)
Sort Key: sample1.id
-> Seq Scan on sample1 (cost=0.00..180.63 rows=9963 width=36)
(8 rows)
Explaining the Postgres Query Optimizer 42 / 61

43. Merge Join
Sorted
Sorted
Ideal for Large Tables
An Index Can Be Used to Eliminate the Sort
aaa
aab
aac
aad
aaa
aab
aab
aaf
aaf
aac
aae
Outer Inner
Explaining the Postgres Query Optimizer 43 / 61

44. Pseudocode for Merge Join
sort(outer);
sort(inner);
i = 0;
j = 0;
save_j = 0;
while (i < length(outer))
if (outer[i] == inner[j])
output(outer[i], inner[j]);
if (outer[i] <= inner[j] && j < length(inner))
j++;
if (outer[i] < inner[j])
save_j = j;
else
i++;
j = save_j;
Explaining the Postgres Query Optimizer 44 / 61

45. Order of Joined Relations Is Insignificant
EXPLAIN SELECT sample2.junk
FROM sample2 JOIN sample1 ON (sample2.id = sample1.id);
QUERY PLAN
------------------------------------------------------------------------
Merge Join (cost=927.72..1852.95 rows=61272 width=32)
Merge Cond: (sample2.id = sample1.id)
-> Sort (cost=85.43..88.50 rows=1230 width=36)
Sort Key: sample2.id
-> Seq Scan on sample2 (cost=0.00..22.30 rows=1230 width=36)
-> Sort (cost=842.29..867.20 rows=9963 width=4)
Sort Key: sample1.id
-> Seq Scan on sample1 (cost=0.00..180.63 rows=9963 width=4)
(8 rows)
The most restrictive relation, e.g. sample2, is always on the outer side of
merge joins. All previous merge joins also had sample2 in outer position.
Explaining the Postgres Query Optimizer 45 / 61

46. Add Optimizer Statistics
ANALYZE sample1;
ANALYZE sample2;
Explaining the Postgres Query Optimizer 46 / 61

47. This Was a Merge Join without Optimizer Statistics
EXPLAIN SELECT sample2.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id);
QUERY PLAN
------------------------------------------------------------------------
Hash Join (cost=15.85..130.47 rows=260 width=254)
Hash Cond: (sample1.id = sample2.id)
-> Seq Scan on sample1 (cost=0.00..103.56 rows=2256 width=4)
-> Hash (cost=12.60..12.60 rows=260 width=258)
-> Seq Scan on sample2 (cost=0.00..12.60 rows=260 width=258)
(5 rows)
Explaining the Postgres Query Optimizer 47 / 61

48. Outer Joins Can Affect Optimizer Join Usage
EXPLAIN SELECT sample1.junk
FROM sample1 RIGHT OUTER JOIN sample2 ON (sample1.id = sample2.id);
QUERY PLAN
--------------------------------------------------------------------------
Hash Left Join (cost=131.76..148.26 rows=260 width=254)
Hash Cond: (sample2.id = sample1.id)
-> Seq Scan on sample2 (cost=0.00..12.60 rows=260 width=4)
-> Hash (cost=103.56..103.56 rows=2256 width=258)
-> Seq Scan on sample1 (cost=0.00..103.56 rows=2256 width=258)
(5 rows)
Use of hashes for outer joins was added in Postgres 9.1.
Explaining the Postgres Query Optimizer 48 / 61

49. Cross Joins Are Nested Loop Joins
without Join Restriction
EXPLAIN SELECT sample1.junk
FROM sample1 CROSS JOIN sample2;
QUERY PLAN
----------------------------------------------------------------------
Nested Loop (cost=0.00..7448.81 rows=586560 width=254)
-> Seq Scan on sample1 (cost=0.00..103.56 rows=2256 width=254)
-> Materialize (cost=0.00..13.90 rows=260 width=0)
-> Seq Scan on sample2 (cost=0.00..12.60 rows=260 width=0)
(4 rows)
Explaining the Postgres Query Optimizer 49 / 61

50. Create Indexes
CREATE INDEX i_sample1 on sample1 (id);
CREATE INDEX i_sample2 on sample2 (id);
Explaining the Postgres Query Optimizer 50 / 61

51. Nested Loop with Inner Index Scan Now Possible
EXPLAIN SELECT sample2.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id)
WHERE sample1.id = 33;
QUERY PLAN
---------------------------------------------------------------------------------
Nested Loop (cost=0.00..16.55 rows=1 width=254)
-> Index Scan using i_sample1 on sample1 (cost=0.00..8.27 rows=1 width=4)
Index Cond: (id = 33::oid)
-> Index Scan using i_sample2 on sample2 (cost=0.00..8.27 rows=1 width=258)
Index Cond: (sample2.id = 33::oid)
(5 rows)
Explaining the Postgres Query Optimizer 51 / 61

52. Nested Loop Join with Inner Index Scan
aag
aar
aai
aay aag
aas
aar
aaa
aay
aai
aag
No Setup Required
Index Lookup
Index Must Already Exist
Outer Inner
Explaining the Postgres Query Optimizer 52 / 61

53. Pseudocode for Nested Loop Join
with Inner Index Scan
for (i = 0; i < length(outer); i++)
index_entry = get_first_match(outer[j])
while (index_entry)
output(outer[i], inner[index_entry]);
index_entry = get_next_match(index_entry);
Explaining the Postgres Query Optimizer 53 / 61

54. Query Restrictions Affect Join Usage
EXPLAIN SELECT sample2.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id)
WHERE sample2.junk ˜ ’^aaa’;
QUERY PLAN
-------------------------------------------------------------------------------
Nested Loop (cost=0.00..21.53 rows=1 width=254)
-> Seq Scan on sample2 (cost=0.00..13.25 rows=1 width=258)
Filter: (junk ˜ ’^aaa’::text)
-> Index Scan using i_sample1 on sample1 (cost=0.00..8.27 rows=1 width=4)
Index Cond: (sample1.id = sample2.id)
(5 rows)
No junk rows begin with ’aaa’.
Explaining the Postgres Query Optimizer 54 / 61

55. All ’junk’ Columns Begin with ’xxx’
EXPLAIN SELECT sample2.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id)
WHERE sample2.junk ˜ ’^xxx’;
QUERY PLAN
------------------------------------------------------------------------
Hash Join (cost=16.50..131.12 rows=260 width=254)
Hash Cond: (sample1.id = sample2.id)
-> Seq Scan on sample1 (cost=0.00..103.56 rows=2256 width=4)
-> Hash (cost=13.25..13.25 rows=260 width=258)
-> Seq Scan on sample2 (cost=0.00..13.25 rows=260 width=258)
Filter: (junk ˜ ’^xxx’::text)
(6 rows)
Hash join was chosen because many more rows are expected. The
smaller table, e.g. sample2, is always hashed.
Explaining the Postgres Query Optimizer 55 / 61

56. Without LIMIT, Hash Is Used
for this Unrestricted Join
EXPLAIN SELECT sample2.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id);
QUERY PLAN
------------------------------------------------------------------------
Hash Join (cost=15.85..130.47 rows=260 width=254)
Hash Cond: (sample1.id = sample2.id)
-> Seq Scan on sample1 (cost=0.00..103.56 rows=2256 width=4)
-> Hash (cost=12.60..12.60 rows=260 width=258)
-> Seq Scan on sample2 (cost=0.00..12.60 rows=260 width=258)
(5 rows)
Explaining the Postgres Query Optimizer 56 / 61

57. LIMIT Can Affect Join Usage
EXPLAIN SELECT sample2.id, sample2.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id)
ORDER BY 1
LIMIT 1;
QUERY PLAN
------------------------------------------------------------------------------------------
Limit (cost=0.00..1.83 rows=1 width=258)
-> Nested Loop (cost=0.00..477.02 rows=260 width=258)
-> Index Scan using i_sample2 on sample2 (cost=0.00..52.15 rows=260 width=258)
-> Index Scan using i_sample1 on sample1 (cost=0.00..1.62 rows=1 width=4)
Index Cond: (sample1.id = sample2.id)
(5 rows)
Explaining the Postgres Query Optimizer 57 / 61

58. LIMIT 10
EXPLAIN SELECT sample2.id, sample2.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id)
ORDER BY 1
LIMIT 10;
QUERY PLAN
------------------------------------------------------------------------------------------
Limit (cost=0.00..18.35 rows=10 width=258)
-> Nested Loop (cost=0.00..477.02 rows=260 width=258)
-> Index Scan using i_sample2 on sample2 (cost=0.00..52.15 rows=260 width=258)
-> Index Scan using i_sample1 on sample1 (cost=0.00..1.62 rows=1 width=4)
Index Cond: (sample1.id = sample2.id)
(5 rows)
Explaining the Postgres Query Optimizer 58 / 61

59. LIMIT 100 Switches to Hash Join
EXPLAIN SELECT sample2.id, sample2.junk
FROM sample1 JOIN sample2 ON (sample1.id = sample2.id)
ORDER BY 1
LIMIT 100;
QUERY PLAN
------------------------------------------------------------------------------------
Limit (cost=140.41..140.66 rows=100 width=258)
-> Sort (cost=140.41..141.06 rows=260 width=258)
Sort Key: sample2.id
-> Hash Join (cost=15.85..130.47 rows=260 width=258)
Hash Cond: (sample1.id = sample2.id)
-> Seq Scan on sample1 (cost=0.00..103.56 rows=2256 width=4)
-> Hash (cost=12.60..12.60 rows=260 width=258)
-> Seq Scan on sample2 (cost=0.00..12.60 rows=260 width=258)
(8 rows)
Explaining the Postgres Query Optimizer 59 / 61

60. Additional Resources…
◮ Postgres Downloads:
◮ www.enterprisedb.com/downloads
◮ Product and Services information:
◮ info@enterprisedb.com
Explaining the Postgres Query Optimizer 60 / 61

61. Conclusion
http://momjian.us/presentations http://www.vivapixel.com/photo/14252
Explaining the Postgres Query Optimizer 61 / 61
