13. 辞書を用いたワイン製造モデル (2)
x = {}
for j in Blends:
x[j] = model.addVar(vtype="C", name="x[%s]"%j)
model.update()
model.setObjective(quicksum(Profit[j]*x[j] for j in Blends),
GRB.MAXIMIZE)
for i in Grapes:
model.addConstr(quicksum(Use[i,j]*x[j] for j in Blends)
<= Inventory[i], name="use[%s]"%i)
model.optimize()
17. Python での実装(2)
変数オブジェクトの追加
I=range(n) “B” は 0-1 整数 (binary) 変数
J=range(n) ( GRB.BINARY でも良い)
for j in J:
y[j] = model.addVar(vtype="B", name="y[%s]"%j)
for i in I:
x[i,j] =model.addVar( vtype="B",name="x[%s,%s]"%(i,j))
model.update()
目的関数の設定
model.setObjective(quicksum(c[i,j]*x[i,j] for i in I for j in J))
18. Python での実装(3)
for i in I:
model.addConstr(quicksum(x[i,j] for j in J) = = 1, "Assign[%s]"%i)
for j in J:
model.addConstr(x[i,j] <= y[j], "Strong[%s,%s]"%(i,j))
model.addConstr(quicksum(y[j] for j in J) = = k, "k_median")
19. Python での実装(4)
…
model.optimize()
print “Opt.value=”,model.ObjVal
edge=[]
for (i,j) in x:
if x[i,j].X= =1:
edge.append((i,j))
return edge
20. Python での実装(5)
import networkx as NX #networkX module
import matplotlib.pyplot as P #prepare drawing
P.ion()
G = NX.Graph() #graph object
G.add_nodes_from(range(n)) #add nodes
for (i,j) in edge: #add edges
G.add_edge(i,j)
NX.draw(G)
21. 弱い定式化での結果
n=200,k=20
Optimize a model with 401 Rows, 40200 Columns and 80400
NonZeros
中略
Explored 1445 nodes (63581 simplex iterations) in 67.08 seconds
Thread count was 2 (of 2 available processors)
Optimal solution found (tolerance 1.00e-04)
Best objective 1.0180195861e+01, best bound 1.0179189780e+01,
gap 0.0099%
Opt.value= 10.1801958607
23. 強い定式化での結果
Optimize a model with 40401 Rows, 40200 Columns and 160400
NonZeros
中略
Explored 0 nodes (1697 simplex iterations) in 3.33 seconds
( 分枝しないで終了!)
Thread count was 2 (of 2 available processors)
Optimal solution found (tolerance 1.00e-04)
Best objective 1.0180195861e+01, best bound 1.0180195861e+01,
gap 0.0%
Opt.value= 10.1801958607
24. 知見
• Big M を用いない強い定式化が望まし
い.
• この程度の式なら,必要な式のみを切
除平面として追加するような小細工は
必要なし.
(ただし,式の数が増え退化するので
,大規模なLPを高速に解けるソル
バーが前提)
34. AMPL での実装(1)
param n >=0;
set V := 1..n ; # 点集合
set V0 := 2..n; # 出発地点 1 以外の点集合
set A :=V cross V; # 枝集合 = 点集合の直積( 2 つ組)
param c { A } >= 0; # 枝の距離
var x { A } binary ; # 枝を使うとき 1 ,それ以外のとき 0 の 0-1 変
数
var u { V0 } >=1,<=n-1; # 点のポテンシャル
minimize total_cost:
sum {(i,j) in A} c[i,j] * x[i,j];
35. AMPL での実装(2)
Degree1 {i in V}:
sum {(i,j) in A } x[i,j] =1 ; # 出次数制約
Degree2 {i in V}:
sum {(j,i) in A } x[j,i] =1 ; # 入次数制約
MTZ{ (i,j) in A: i != j and j!=1 and i!=1}:
u[i]+1 -(n-1)*(1-x[i,j]) + (n-3)*x[j,i]<=u[j]; # 持ち上げ MTZ 制約
LiftedLB{ i in V0}:
1+(1-x[1,i]) +(n-3)*x[i,1] <= u[i]; # 持ち上げ下界制約
LiftedUB{ i in V0}:
u[i] <=(n-1)-(1-x[i,1])-(n-3)*x[1,i]; # 持ち上げ上界制約
36. 上界と下界の変化
45
(80点, Euclid TSP )
40
強化した式
35
30 でないと...
1日まわして
Obj. Func . Va lue
25
Out of Memory!
20
15
10
5
0
0 50 100 150 200 250 300 350 400
C PU
37. 結果
Optimize a model with 6480 Rows, 6400 Columns and 37762 NonZeros
中略
Cutting planes:
Gomory: 62
Implied bound: 470
MIR: 299
Zero half: 34
Explored 125799 nodes (2799697 simplex iterations) in 359.01 seconds
Optimal solution found (tolerance 1.00e-04)
Best objective 7.4532855108e+00, best bound 7.4525704995e+00, gap 0.0096%
Opt.value= 7.45328551084
44. 上界と下界の変化(標準定式
化) 1 32000
1 30000
1 28000
1 26000
Ob j. Fu n c . Va lu e
1 24000
1 22000
1 20000
1 18000
1 16000
1 14000
1 12000
0 200 400 600 800 1000 1200 1400 1600 1800 2000
C PU
1800 秒で最適解;これ以上大きな問題例は無理!
45. 上界と下界の変化(施設配置定式
1 14050
化)
1 14000
1 13950
Ob j. Fu n c . Va l.
1 13900
1 13850
1 13800
1 13750
1 13700
1 13650
1 13600
0 5 10 15 20 25 30 35 40 45
C PU
40 秒で最適解; T=100 でも大丈夫!
49. Python での実装(1)
from gurobipy import *
model=Model("gcp")
x={}
y={}
for i in range(n):
for k in range(K):
x[i,k]=model.addVar(obj=0, vtype="B",name="x"+str(i)+str(k))
for k in range(K):
y[k]=model.addVar(obj=1,vtype=“B”,name="y"+str(k))
model.update()
50. Python での実装(2)
for i in range(n):
L=LinExpr()
for k in range(K):
L.addTerms(1,x[i,k])
model.addConstr(lhs=L,sense= " = ",rhs=1,name="const"+str(i))
中略
model.optimize()
print "Opt.value=",model.ObjVal
for v in model.getVars():
if v.X>0.001:
print v.VarName,v.X
51. 上界と下界の変化(原定式
化)
12
点数 n=40 ,彩色数上限 Kmax=10
10
Obj. Func . Value
8
6
4
2
0
0 200 400 600 800 1000 1200 1400
CPU Time
Optimize a model with 3820 Rows, 410 Columns and 11740 NonZeros
Explored 17149 nodes (3425130 simplex iterations) in 1321.63 seconds
